Broadband Blocks - C04/C06/C08
Description
•
Resonance free DC Blocking / Decoupling
•
Less than 0.25 db loss @ 4 GHz (typical)
•
Surface mountable
Functional Applications
•
Fiber Optic Links
•
High Isolation Decoupling
•
LAN’s, VCO Frequency Stabilization
•
Diplexers
•
RF/Microwave Modules
•
Instruments
•
Test Equipments
Mechanical Specification
Product
Code
C04BL
C06 BL
C08 BL
C18BL
Body Dimensions
Length
(L)
Width
(W)
Thickness
(T)
0.028" Max
0.036" Max
0.061" Max
0.100” Max
Band Dimensions
(B)
Min
0.003"
0.006"
0.012"
0.008”
Max
0.019"
0.03"
0.0468"
0.045”
T
B
W
L
0.040"
0.020"
± 0.008" ± 0.006"
0.060"
0.031"
± 0.012" ± 0.009"
0.081"
0.051"
± 0.020" ± 0.013"
0.1200” 0.1100”
± 0.925” ± 0.010”
Part Characteristics
Part Number
C04BL121X-5UN-X0T
C06BL851X-1UN-X0T
C08BL242X-5UN-X0T
C08BL102X-1UN-X0T
C18BL103X-4GN-XOT
Capacitance
Temperature
Maximum
Guaranteed Voltage
Coefficient
Dissipation
Minimum
Rating
-55°C to
Factor
Value
125°C
120pF @
1KHz,.2Vrms
850pF @
1KHz,.2Vrms
2400pF @
1KHz,.2Vrms
1000pF @
1KHz,.2Vrms
10,000pF @
1KHz,.2Vrms
50 Vdc
100 Vdc
50 Vdc
50 Vdc
100 Vdc
500 Vdc
± 15%
Insulation
Resistance
(MΩ
Minimum)
Aging
Rate
Frequency
Range
10MHz –
40GHz
Termination
“U” & “S”
2MHz – 30GHz “U”, “S” & “Z”
3.0%@
1KHz,
.2Vrms
10
4
<=1.5%/
decade 1MHz – 20GHz “U”, “S” & “Z”
hours
1MHz – 20GHz “U”, “S” & “Z”
1MHz – 6GHz
“U”, “S” & “Z”
Performance
0
-0.2
-0.4
-0.6
C06BL851X-1UN-X0T Insertion Loss (S21)
S21 (dB)
-0.8
-1
-1.2
-1.4
-1.6
-1.8
-2
0
2
4
6
8
10
12
14
16
18
20
Frequency (GHz)
The information above represents typical device performance.
www.knowlescapacitors.com
Should be ordered as DLI parts.
