* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
* Compliant with RoHS.
Dual-row construction allows high density
mounting.
• Secure locking device
• Reliable contacts
• Insertion guide mechanism
• Polarizing boss
Standards ––––––––––––––––––––––
1
Certified LR20812
2
R50053749
0
Recognized E60389
PC board layout and Assembly layout
Top entry type
A
2
±0.05
±0.05
Side entry type
A
±0.05
1.3
±0.05
1.6
±0.05
2
±0.05
＋0.1
φ1.1
0
1.6
±0.05
2
±0.05
Even number circuits
Odd number circuits
φ0.7
＋0.1
0
Even number circuits
1.4
±0.05
Odd number circuits
＋0.1
φ0.7
0
＋0.1
φ1
0
（10）
2.5
±0.05
（15.4）
（12.4）
2
10.7
Note: 1. The above figure is the figure viewed from the connector mounting side.
2. Tolerances are non-cumulative:
±
0.05 mm for all centers.
3. Hole dimensions differ according to the type of PC board and piercing method. If PC boards made of hard material are used, the hole dimensions should
be larger. The dimensions above should serve as a guideline. Contact JST for details.
1
（11）
2
Circuit No.1
Circuit No.1
±0.05
PAD CONNECTOR
Contact
Model No.
5.7
2.85
2.05
1
Applicable wire
mm
2
0.13∼0.33
0.08∼0.22
AWG#
26∼22
28∼24
Insulation O.D.
(mm)
1.0∼1.5
0.8∼1.5
Q't y/
reel
8,000
SPH-001T-P0.5L
SPH-002T-P0.5L
2.08
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
1.5
RoHS compliance
Model No.
7.5
3
3.9
1.5
Applicable wire
mm
2
0.13∼0.33
0.08∼0.22
AWG#
26∼22
28∼24
Insulation O.D.
(mm)
1.0∼1.5
0.8∼1.5
Q't y/
reel
8,000
SPND-001T-C0.5
SPND-002T-C0.5
Material and Finish
2.08
Copper alloy, tin-plated (reflow treatment)
RoHS compliance
Note: SPND-( )T-C0.5 is low insertion/withdrawal force type contact, in order
to improve the work of insertion/withdrawal.
Contact
SPH-001T-P0.5L
AP-K2N
Crimping
machine Crimp applicator
MKS-L
−
MKS-L
*MKS-SC
Applicator
Dies
−
Crimp applicator with dies
−
Contact
SPND-001T-C0.5
Crimping
machine Crimp applicator
MKS-L
AP-K2N
−
MKS-L
−
Applicator
Dies
−
−
Crimp applicator with dies
−
−
MK/SPH-001-05L APLMK SPH001-05L
MK/SPH-002-05L APLMK SPH002-05L
SC/SPH-002-05L APLSC SPH002-05L
MK/SPND-001-05 APLMK SPND001-05
MK/SPAD/ND-002-05 APLMK SPAD/ND002-05
SPH-002T-P0.5L
SPND-002T-C0.5
Note: *Strip-crimp applicator
Housing
<14 circuits or less>
B
A
2
10
Circuit No.1 mark
Circuits
10
12
14
16
6.85
Model No.
PADP-10V-1-S
PADP-12V-1-S
PADP-14V-1-S
PADP-16V-1-S
PADP-20V-1-S
PADP-22V-1-S
PADP-24V-1-S
PADP-40V-1-S
Material
Dimensions (mm)
A
B
8.0
10.0
12.0
14.0
18.0
20.0
22.0
38.0
12.0
14.0
16.0
18.0
22.0
24.0
26.0
42.0
Q'ty/
bag
1,000
1,000
1,000
1,000
1,000
1,000
1,000
500
20
22
11
24
*40
2
PA 66, UL94V-0, natural (white)
<16 circuits or more>
B
A
2
10
Circuit No.1 mark
RoHS compliance
Note: *Marked product is not TÜV approved.
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
