TM
970 Series
Ø 0.313” (8.0mm) Snap - Mount
Panel Mount Indicator Lights
970 Series non-relampable snap mount indicator lights feature molded
plastic flex arms which ensure easy front panel installation into a 5/16”
diameter hole.
Approval
Specifications
REACH/RoHS/cURus (”No Lens” - Body Only - assembly is not cURus)
Housing: White nylon (standard), black optional, other color available to special order.
Bezel: Chrome-plated finish standard. Black anodized, clear anodized, or gold iridite finish available
to special order. Bezel are required on all lens styles except Type 92 ( Flat cylindrical faceted).
Terminations: Wire leads: Black # 18 gauge, PVC plastic insulated. UL-CSA rated at 105°C. 6” long,
1/2 stripped.
Terminals: Brass, Tin-plated. 125” quick-connect.
Incandescent AC or DC voltage options: 6 to 28 volts.
High brightness Neon AC Voltage options: 125 to 250 volts.
Blue or Green Neon AC or DC Voltage options: 125 to 250 volts.
LED DC voltage options: 1.8 to 28 volts.
Lens: Heat resistant, high strength polycarbonate.
Lens Marking: Flat lenses may be marked. Contact factory.
Mounting: Designed to snap securely into a .312”/.318” diameter hole. Panel thickness ranges from
.040” to .100”.
your first call for illuminated components
www.vcclite.com
1
1.800.522.5546
06/17 Rev 1
Ordering Data
ORDERING INFORMATION:
INCANDESCENT AND NEON LAMPS
EXAMPLE: 971
6 12 X
01 W RT
Chrome Plated
Bezel
Wire Leads
6.3 Volt Incandescent Lamp
No Resistor
Series
Number
970
2
No Bezel
971
Chrome
Plated Bezel
972
Black Anodized
Bezel
973
ClearAnodized
Bezel
Termination
6
6” Wire
Leads
9
.125” Q.C.
Terminals
Lamp
Code
03
04
Volts
14.0
28.0
MA
80
40
Life (Hrs)
15,000
7,000
Long Stovepipe
Lens
White Housing
Red Translucent
Lens
Resistor
Lens Type
Housing
Color
Lens Color
Neon (High Brightness)
70
71
3
56
4
56
4
57
5
57
5
3
01
Long Stovepipe
X
(Smooth)
None
(No Resistor
02
Flat Cylindrical
required with
(Smooth)
Incandescent
03
Short Cylindrical
Lamps)
A
22K OHM
T
150K OHM
B
30K OHM
E
100K OHM
B
30K OHM
E
100K OHM
White
(Standard)
w
125
250
125
250
125
250
1/3 W
1/3 W
1/3 W
1/3 W
1/3 W
1/3 W
10,000
10,000
10,000
10,000
10,000
10,000
(Smooth)
(Smooth)
(Fresnel)
(Fluted)
04
Long Cylindrical
06
6
Short Stovepipe
07
6
Short Cylindrical
92
6,7
Flat Cylindrical
(Faceted)
(Fresnel)
Black
(Optional)
B
AN
Amber
BN
Blue
CN
Colorless
GN
Green
RN
Red
WN
White
(cloudy)
YN
Yellow
2
3
4
5
6
7
8
Use only with lens type 92.
Standard Neon. Use with lens color AN, CN, RN, WN, or YN.
Green Neon. Use with lens color CN, GN, or WN.
Blue Neon. Use with lens color BN, CN, or WN.
Nondiffusing lens colors.
No Bezel Required.
Not recommended for use with neon lamps.
93
6
Short Cylindrical
EXAMPLE:
LED LAMPS
971 6 60 U
03 W RN
Chrome Plated
Bezel
Wire Leads
Red LED
Built-In
200 OHM Resistor
Short Cylindrical Lens
White Housing
Series
Number
970
2
No Bezel
971
Chrome
Plated Bezel
972
Black Anodized
Bezel
973
ClearAnodized
Bezel
974
Gold Iridite
Bezel
Termination
Lamp
Code
Resistor
Red Translucent
Lens
Code
X
U
J
W
Y
K
G
L
V
M
P
Z
N
H
Current
Nominal 10 MA
No Resistor
200 OHM
330 OHM
430 OHM
820 OHM
1000 OHM
1200 OHM
2700 OHM
Nominal 20 MA
100 OHM
180 OHM
220 OHM
390 OHM
620 OHM
1300 OHM
Volts
1.8
3.6
5.0
6.0
10.0
12.0
14.0
28.0
3.6
5.0
6.0
10.0
14.0
28.0
Lens Type
Housing
Color
Lens Color
6
6” Wire
Leads
60
Red LED
66
Green LED
68
Yellow LED
03
Short Cylindrical
(Smooth)
(Fresnel)
(Fluted)
06
Short Stovepipe
07
Short Cylindrical
92
11
Flat Cylindrical
(Faceted)
(Fresnel)
White
(Standard)
w
CN
Colorless
WN
White
(60,66,68)
12
(60,66,68)
12
9
.125” Q.C.
Terminals
93
Short Cylindrical
Black
12
(Optional)
GN
Green (66)
B
AN
Amber (68)
12
RN
Red (60)
12
YN
Yellow (68)
12
9
11
12
Use only with lens type 92.
No Bezel Required.
Lamp Code Number. When specifying lens color, Use only with lamp codes shown.
your first call for illuminated components
www.vcclite.com
2
1.800.522.5546
06/17 Rev 1
Product Specifications
+
1/2
_
6
1-3/8
17/32
TYP
+
1/2
_
6
1-3/8
5/32
TYP
.405 TYP
.380 TYP
TYPE 04
LONG CYLINDRICAL LENS
+
1/2
_
6
1-3/8
5/16 TYP
TYPE 02
FLAT CYLINDRICAL LENS
TYPE 92
FLAT CYLINDRICAL FACETED LENS
+
1/2
_
6
1-3/8
17/32 TYP
.405 TYP
.405 TYP
TYPE 03
SHORT CYLINDRICAL LENS
TYPE 07
SHORT CYLINDRICAL FLUTED LENS
+
1/2
_
TYPE 01
LONG STOVEPIPE LENS
5/16 TYP
+
1/2
_
6
6
1-3/8
1-3/8
5/16 TYP
.405 TYP
.405 TYP
TYPE 06
SHORT STOVEPIPE FRESNEL LENS
3/4
5/16
TYPE 93
SHORT CYLINDRICAL FRESNEL LENS
OPTIONAL TERMINATION
(Projection back of panel - 1-1/4)
1/16D.
125 Q.C. TERMINALS
Dimensions in inches
Compliances and Approvals
your first call for illuminated components
www.vcclite.com
3
1.800.522.5546
06/17 Rev 1
