5.11
.201
AT DATUM -D-
H
2.41
.095
REF
DIM. A REF
DIM. B
H
FEATURE MAY BE ON EITHER
SIDE OF THE PART
G
11.33
±
0.51
.446
±
.020
M
±
0.38
±
.015
TYP
SEE NOTE 10
AND DETAIL Z
3.96
.156
REF.
TYP. BETWEEN ANY
2 CONSECUTIVE
CKTS. AT -D-
1.91
.075
AT -D-
CENTERLINE OF PIN AT TIP
NOT TO VARY FROM CENTERLINE
OF PIN AT DATUM -D- BY MORE
THAN 0.20/.008 IN ANY DIRECTION.
GOLD
CIRCUIT NO. 1
SEE NOTE 11
SEE NOTE 9
G
P
F
TYP
REF
SEE DETAIL Z
SEE NOTE 10
3.96
±
0.05
.156
±
.002
TYP
NON-ACCUMULATIVE
5.08
.200
MIN
1.73
±
0.05
DIA TYP
.068
±
.002
F
3.30
±
0.25
.130
±
.010
10.01
±
0.51
.394
±
.020
TIN
-D-
-E-
E
CENTERLINE OF PIN AT TIP
NOT TO VARY FROM CENTERLINE
OF PIN AT DATUM -E- BY MORE
THAN 0.13/.005 IN ANY DIRECTION.
OPTIONAL VOIDED CIRCUIT
SEE CHART FOR LOCATION
7.42
.292
REF
RECOMMENDED P.C.BOARD LAYOUT
6.10
.200
REF
DETAIL Z
SCALE 8:1
D
CIRCUIT
DIM. A
SIZE
7.77
2
.306
11.73
3
.462
DIM. B
SLOT LOCATION
BETWEEN CIRCUITS
NONE
NONE
NONE
NONE
E
C
NOTES:
1. MATERIAL: HOUSING: NYLON, UL94V-1, COLOR: BLACK
PINS: BRASS
2. FINISH:
(197-TIN) = OVERALL REFLOWED MATTE TIN: 0.00152/.000060 MIN.
OVER 0.00127/.000050 MIN. NICKEL OVERALL.
(208) = SELECT GOLD: 0.00038/.000015 MIN,
SELECT MATTE TIN: 0.00254/.000100 MIN,
BOTH OVER 0.00127/.000050 MIN NICKEL.
(228) = SELECT GOLD: 0.00076/.000030 MIN,
SELECT MATTE TIN: 0.00254/.000100 MIN,
BOTH OVER 0.00127/.000050 MIN NICKEL.
4
5
6
16.10
.634
REF
7
8
9
B
A
REV
3. PRODUCT SPECIFICATION: PS-171813-0001, PS-171813-0002
4. PACKAGING INFORMATION: SEE CHARTS.
5. SOLDERABILITY: PER SMES-152.
6. PIN PUSH-OUT FORCE: PRIOR TO SOLDERING, A 3 LB. MINIMUM FORCE IN
EITHER DIRECTION
7. PARTS ARE STACKABLE END TO END ON 3.96/.156 CENTERS.
8. THIS PART CONFORMS TO CLASS B REQUIREMENTS OF COSMETIC
SPECIFICATION PS-45499-002.
9. SLOTS ON BACKWALL ARE BETWEEN CIRCUITS. SEE CHART FOR LOCATION.
10. FEATURE MAY OR MAY NOT EXTEND ACROSS THE ENTIRE FACE OF THE PART.
SEE DETAIL Z.
11. CIRCUIT 1 DESIGNATION IS USED TO DEFINE VOID LOCATION. CIRCUIT 1 MAY
OR MAY NOT LINE UP WITH CIRCUIT 1 ON THE MATING HOUSING.
12. THE PARTS LISTED ON THIS DRAWING ARE CONSTRUCTED TO MEET THE
REQUIREMENT FOR DIRECT SUPPORT OF UNINSULATED LIVE PARTS AS
DESCRIBED IN UL508C.
RELEASE STATUS
FORMAT: Eng-lega-master-tb-prod-C
REVISION: C
DATE: 2016/02/04
10
OPTIONAL PICK AND PLACE CAP
FOR TAPE AND REEL PACKAGING
11
12
15.70
.618
19.66
.774
23.62
.930
27.58
1.086
31.55
1.242
35.51
1.398
39.47
1.554
43.43
1.710
47.40
1.866
11.89
±
0.15
.468
±
.006
15.85
±
0.15
.624
±
.006
19.81
±
0.18
.780
±
.007
23.77
±
0.18
.936
±
.007
27.74
±
0.20
1.092
±
.008
31.70
±
0.20
1.248
±
.008
35.66
±
0.23
1.404
±
.009
39.62
±
0.23
1.560
±
.009
43.59
±
0.25
1.716
±
.010
3.96
±
0.05
.156
±
.002
7.92
±
0.10
.312
±
.004
D
3&4
4&5
4&5
5&6
5&6
6&7
4&5
8&9
B
C
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
2017/02/03
2017/02/06
2017/02/09
DIMENSION UNITS
SCALE
GENERAL TOLERANCES
(UNLESS SPECIFIED)
MM/IN
DRWN BY
DATE
4:1
2012/09/13
DATE
MM
INCH
±
±
0.01
±
0.015
±
±
ADD NOTE 12
4 PLACES
±
±
±
0.25
±
0.38
±
MKIPPER
CHK'D BY
113073
BAPPELDORN
JBELL
FSMITH
3 PLACES
2 PLACES
1 PLACES
0 PLACES
SSOUSEK
APPR BY
DATE
2012/09/13
2013/06/11
THIRD ANGLE PROJECTION
KK RPC 156 FRICTION LOCK
VERTICAL HEADER ASSEMBLY SOLID BODY W/O
PEGS
PRODUCT CUSTOMER DRAWING
SERIES
MATERIAL NUMBER
CUSTOMER
FSMITH
DRAWING SIZE
A
EC NO:
DRWN:
CHK'D:
APPR:
ANGULAR TOL
±
0.5
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
12
RELEASE DATE
11
10
9
8
7
6
B1
C
3
171813
DOCUMENT NUMBER
SEE CHART
GENERAL MARKET
DOC TYPE
DOC PART
SHEET NUMBER
5
4
SD-171813-0001
2
PSD
000
1
1 OF *
