HM72A-06R22LFTR13 datasheet, PDF

Datasheet> All Categories > Passive components> inductor> HM72A-06R22LFTR13

HM72A-06R22LFTR13: Description1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 2827, ROHS COMPLIANT; CategoryPassive components inductor; File Size571KB，4 Pages; ManufacturerTT Electronics; Environmental Compliance

Download Datasheet Parametric View All

HM72A-06R22LFTR13 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	HM72A-06R22LFTR13	-	-	View	Buy Now

HM72A-06R22LFTR13 Overview

1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 2827, ROHS COMPLIANT

HM72A-06R22LFTR13 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1808559450
package instruction	2827
Reach Compliance Code	compliant
ECCN code	EAR99
uppercase and lowercase codes	2827
structure	Molded
DC Resistance	0.0028 Ω
Nominal inductance(L)	0.22 µH
Inductor Applications	POWER INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e1
Number of functions	1
Number of terminals	2
Maximum operating temperature	130 °C
Minimum operating temperature	-40 °C
Package height	3 mm
Package length	7.23 mm
Package form	SMT
Package width	6.8 mm
method of packing	TR, Embossed Plastic, 13 Inch
Maximum rated current	20.3 A
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	0.1 MHz

Preview

Download Datasheet

View All

Magnetics

Make Possible

High Power High Performance

Molded Surface Mount Inductors

Model HM72A Series

Features

Operating Temperature Range -40°C to +130°C

Temperature Rise, Maximum 50°C

Operating Frequency Up to 3MHz

RoHS Compliant

Specifications @ 25°C

Part Number

HM72A-06R10LF

HM72A-06R15LF

HM72A-06R20LF

HM72A-06R22LF

HM72A-06R33LF

HM72A-06R47LF

HM72A-06R68LF

HM72A-06R82LF

HM72A-061R0LF

HM72A-061R5LF

HM72A-062R2LF

HM72A-063R3LF

HM72A-064R7LF

HM72A-066R8LF

HM72A-06100LF

HM72A-06220LF

HM72A-06330LF

HM72A-10R15LF

HM72A-10R19LF

HM72A-10R24LF

HM72A-10R36LF

HM72A-10R47LF

HM72A-10R56LF

HM72A-101R0LF

HM72A-101R5LF

HM72A-101R8LF

HM72A-103R3LF

HM72A-104R7LF

HM72A-12R47LF

HMA72-12R50LF

HMA72-12R56LF

HM72A-121R0LF

HM72A-121R5LF

Min.

0.08

0.12

0.16

0.18

0.26

0.38

0.54

0.66

0.80

1.20

1.76

2.64

3.76

5.44

8.00

17.6

26.4

0.12

0.15

0.19

0.29

0.38

0.45

0.80

1.20

1.44

2.64

3.76

0.38

0.40

0.45

0.80

1.20

Inductance, Lo

@ 100 kHz, 0Adc (μH)

Typ.

0.10

0.15

0.20

0.22

0.33

0.47

0.68

0.82

1.00

1.50

2.20

3.30

4.70

6.80

10.00

22.0

33.0

0.15

0.19

0.24

0.36

0.47

0.56

1.00

1.50

1.80

3.30

4.70

0.47

0.50

0.56

1.00

1.50

Max.

0.12

0.18

0.24

0.26

0.40

0.56

0.82

0.98

1.20

1.80

2.64

3.96

5.64

8.16

12.00

26.4

39.6

0.18

0.23

0.29

0.43

0.56

0.67

1.20

1.80

2.16

3.96

5.64

0.56

0.60

0.67

1.20

1.80

Heating

Current

(1)

(Adc)

26.2

23.3

21.2

20.3

18.0

16.1

14.4

12.0

10.3

8.4

8.3

6.6

5.4

4.1

3.2

2.2

1.8

33.0

33.7

31.6

27.5

24.8

21.6

18.0

12.0

13.0

8.0

7.3

40.5

39.0

34.0

26.0

20.0

sat

(2)

(Adc)

13.5

4.5

3.5

27.5

18.6

DC Resistance (mΩ)

Typ.

1.50

1.90

2.30

2.50

3.20

4.00

5.00

7.20

9.00

14.50

15.00

26.50

35.00

62.00

100.00

219.00

302.00

0.75

0.70

0.80

1.30

1.70

2.56

5.50

4.50

12.50

15.00

1.10

1.30

2.20

3.60

Max.

1.70

2.50

3.00

2.80

3.90

4.20

5.50

8.00

10.00

15.00

20.00

28.00

40.00

68.00

105.00

241.00

332.00

0.82

0.80

0.90

1.40

1.80

2.75

5.80

5.00

13.75

16.50

1.30

1.50

2.50

4.10

Height C

(mm)

3.0

4.0

5.0

Figure

General Note

TT Electronics reserves the right to make changes in product specification without notice or liability.

All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.

www.ttelectronicsmagnetics.com

Rev. 01
