HM30-473590LFTR13

Description
CURRENT SENSE TRANSFORMER
CategoryPower/power management
File Size96KB,1 Pages
ManufacturerTT Electronics
Environmental Compliance
Download Datasheet Parametric View All

HM30-473590LFTR13 Online Shopping

Suppliers Part Number Price MOQ In stock
HM30-473590LFTR13 - - View Buy Now

HM30-473590LFTR13 Overview

CURRENT SENSE TRANSFORMER

HM30-473590LFTR13 Parametric

Parameter NameAttribute value
Frequency Range-
typeIntrusive
inductance750µH
Energy Time (ET)-
Turns Ratio - Primary:Secondary-
Current ratio-
DC resistance (DCR)2.5 milliohms on primary side, 8.3 ohms on secondary side
grade-
Installation type-
size/dimensions0.138" long x 0.185" wide (3.50mm x 4.70mm)
Height - Installation (maximum)0.181"(4.60mm)
weight-
REV-B
Pg 1 of 1
Date : 01 Nov 2011
Electrical / Environmental
HM30
Surface Mount Current Sense
Operating Temperature Range
Dielectric Withstanding Voltage
-40°C to +125°C
500Vac Pri to Sec
Specifications @ 25°C
Turns Ratio
Part
Number
Pri : Sec
Secodary
Inductance
µH
Min.
Primary
mΩ Max.
DCR
Secodary
mΩ Max.
Primary
Current Rating
A
HM30-4735150LF
HM30-4735125LF
HM30-4735100LF
HM30-473590LF
HM30-473580LF
HM30-473570LF
HM30-473550LF
HM30-473540LF
HM30-473530LF
HM30-473520LF
1 : 150
1 : 125
1: 100
1 : 90
1 : 80
1 : 70
1 : 50
1 : 40
1 : 30
1 : 20
2000
1450
930
750
590
450
230
145
80
37
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
21800
16900
13300
8300
6700
6000
2500
1900
1000
600
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
Outline Dimensions (mm)
Top View
Side View
Bottom View
Recommended PCB Layout
Schematic
Ordering Information
HM30 - 4735
Model Series
Case Size
Turn Ratio
XXX
LF
TR13
Tape & 13" Reel
Lead Free
MAGNETIC COMPONENTS SELECTOR GUIDE 2010/11 EDITION
We reserve the right to change specifications without prior notice.
www.bitechnologies.com
