EPCOS Sample Kit 2015
SMD PTC Thermistors
for Overcurrent Protection
www.epcos.com
Features of SMD PTC thermistors
¼
Qualification based on AEC-Q200, Rev. D for
selected types. See table “Product range”.
¼
Suitable for reflow (all types) and wave soldering
(EIA case sizes 3225 and 4032 only)
¼
Lead-free tinned terminations
¼
RoHS-compatible
¼
Tolerance of R
R
±25%
(except B59907A*: ±35%)
Dimensional drawings in mm
EIA case size 0402
Solder pad
Recommended maximum dimensions
EIA case size 0603
Solder pad
Recommended maximum dimensions
Components
A606
30 V, 90 mA
A607
30 V, 70 mA
A407
32 V, 13 mA
A622
60 V, 22 mA
A623
80 V, 15 mA
A707
80 V, 50 mA
A807
265 V, 15 mA
A907
400 V, 12 mA
P1301
30 V, 205 mA
P1201
30 V, 165 mA
P1101
30 V, 90 mA
P1301
30 V, 310 mA
P1201
30 V, 265 mA
P1101
30 V, 170 mA
P1315
80 V, 80 mA
P1215
80 V, 65 mA
P1115
80 V, 40 mA
P1315
80 V, 150 mA
P1215
80 V, 100 mA
P1115
80 V, 70 mA
Product range
Electrical specifications and ordering codes
EIA
case
size
1210
1210
0402
0603
0603
1210
1210
1210
4032
3225
3225
4032
3225
3225
4032
3225
3225
4032
3225
3225
1)
Type
I
R
[mA]
I
S
[mA]
180
130
32
47
33
90
40
22
420
340
185
640
545
355
165
135
85
310
210
145
I
Smax
R
R
(V = V
max
)
[A]
[V]
0.50
0.40
0.12
0.22
0.15
0.30
0.20
0.15
1.60
1.00
0.70
1.60
1.00
0.70
1.60
1.00
0.70
1.60
1.00
0.70
27
55
470
220
470
125
400
1500
3.1
4.6
13.0
3.1
4.6
13.0
16.0
25.0
55.0
16.0
25.0
55.0
R
min
[V]
17
30
265
150
300
75
200
640
1.85
2.70
7.80
1.85
2.70
7.80
9.60
15.00
32.20
9.60
15.00
32.20
AEC-
Q200
1)
Ordering code
V
max
= 30 V DC or V AC, V
R
= 24 V DC or V AC
A606
A607
A407
A622
A623
A707
A807
A907
P1301
P1201
P1101
P1301
P1201
P1101
P1315
P1215
P1115
P1315
P1215
P1115
90
70
13
22
15
50
15
12
205
165
90
310
265
170
80
65
40
150
100
70
–
B59606A0110A062
B59607A0120A062
B59407A0115A062
B59622A0090A062
B59623A0090A062
B59707A0120A062
B59807A0090A062
B59907A0120A062
B59301P1080A062
B59201P1080A062
B59101P1080A062
B59301P1120A062
B59201P1120A062
B59101P1120A062
B59315P1080A062
B59215P1080A062
B59115P1080A062
B59315P1120A062
B59215P1120A062
B59115P1120A062
V
max
= 32 V DC or V AC, V
R
= 24 V DC or V AC
V
max
= 60 V DC or V AC, V
R
= 42 V DC or V AC
–
–
–
–
V
max
= 80 V DC or V AC, V
R
= 63 V DC or V AC
V
max
= 265 V DC or V AC, V
R
= 230 V DC or V AC
V
max
= 400 V DC or V AC, V
R
= 230 V DC or V AC
V
max
= 30 V DC or V AC, V
R
= 24 V DC or V AC
V
max
= 80 V DC or V AC, V
R
= 63 V DC or V AC
Qualification based on AEC-Q200, Rev. D.
Important information:
Some parts of this publication contain statements about the suitability of our products for certain areas of application. These
statements are based on our knowledge of typical requirements that are often placed on our products. We expressly point out that these statements
cannot be regarded as binding statements about the suitability of our products for a particular customer application. It is incumbent on the customer
to check and decide whether a product is suitable for use in a particular application. This publication is only a brief product survey which may be
changed from time to time. Our products are described in detail in our data sheets. The
Important notes
(www.epcos.com / ImportantNotes) and the
product-specific
Cautions and warnings
must be observed. All relevant information is available through our sales offices.
Dimensional drawings in mm
EIA case size 1210
Solder pad
Recommended maximum dimensions
EIA case sizes 3225 and 4032
Case size h ±0.5
3225
4032
3.3
3.3
w ±0.5
6.3
8.0
l ±0.5
8.0
10.0
a ±0.3
1.7
2.3
Solder pads
EIA case size 3225
EIA case size 4032
Recommended maximum dimensions
