Halogen and Antimony Free. “Green” Device (Note 3)
PPAP Capable (Note 4)
Applications
Automotive Interior Lamps
Automotive Parking Lights
Instrumentation Illumination
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Automotive products are AEC-Q100 qualified and are PPAP capable. Refer to http://www.diodes.com/quality/product_compliance_definitions/.
Typical Applications Circuit
PowerDI is a registered trademark of Diodes Incorporated.
Stresses greater than the 'Absolute Maximum Ratings' specified above, may cause permanent damage to the device. These are stress ratings only;
functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability may be
affected by exposure to absolute maximum rating conditions for extended periods of time.
Semiconductor devices are ESD sensitive and may be damaged by exposure to ESD events. Suitable ESD precautions should be taken when
handling and transporting these devices.
Package Thermal Data
Package
PowerDI123 (Type B)
PowerDI123 (Type B)
Notes:
θ
JC
Thermal Resistance
Junction-to-Case
27.15°C/W
17.81°C/W
θ
JA
Thermal Resistance
Junction-to-Ambient
148.6°C/W (Note 5)
81.4°C/W (Note 6)
P
DIS
T
A
= +25°C, T
J
= +150°C
0.84W
1.53W
5. Test condition for PowerDI123 (Type B): Device mounted on 25.4mm x 25.4mm FR-4 PCB (10mm x 10mm 1oz copper, minimum recommended pad
layout on top layer and thermal vias to bottom layer ground plane). For better thermal performance, larger copper pad for heatsink is needed.
6. When mounted on 50.8mm x 50.8mm GETEK PCB with 25.4mm x 25.4mm copper pads.
Recommended Operating Conditions
(Note 8)
Symbol
V
INOUT
I
INOUT
t
PWM(ON)
t
PWM(OFF)
T
J
T
A
T
A
Parameter
“IN” Voltage Range Relative to “OUT” Pin (Notes 7 and 8)
LED Current (Note 9)
PWM pulse width in dimming mode on-time
PWM pulse width in dimming mode on-time
Operating Junction Temperature Range (Note 8)
Operating Ambient Temperature Range AEC-Q100 Grade 3 (Note 8)
Operating Ambient Temperature Range AEC-Q100 Grade 1 (Note 8)
