HMC543LC4B
v05.0514
22.5° MMIC 4-BIT DIGITAL
PHASE SHIFTER, 8 - 12 GHz
Typical Applications
The HMC543LC4B is ideal for:
Features
Low RMS Phase Error: 5°
Low Insertion Loss: 6.5 dB
Excellent Flatness
360° Coverage, LSB = 22.5°
24 Lead Ceramic SMT Package: 16mm
2
PHASE SHIFTERS - DIGITAL - SMT
• EW Receivers
• Weather & Military Radar
• Satellite Communications
• Beamforming Modules
Functional Diagram
General Description
The HMC543LC4B is a 4-bit digital phase shifter
which is rated from 8 to 12 GHz, providing 0 to 360
degrees of phase coverage, with a LSB of 22.5
degrees. The HMC543LC4B features very low
RMS phase error of 5 degrees and extremely low
insertion loss variation of ±0.8 dB across all phase
states. This high accuracy phase shifter is controlled
with complementary logic of 0/-3V, and requires no
fixed bias voltage. The HMC543LC4B is housed in
a compact 4x4 mm ceramic leadless SMT package
and is internally matched to 50 Ohms with no external
components. Simple external level shifting circuitry
can be used to convert a positive CMOS control
voltage into complementary negative control signals.
Electrical Specifications,
T
A
= +25° C, 50 Ohm System, Control Voltage = 0/-3V
Parameter
Frequency Range
Insertion Loss*
Input Return Loss*
Output Return Loss*
Phase Error*
RMS Phase Error
Gain Variation*
Input Power for 1 dB Compression
Input Third Order Intercept
Control Voltage Current
*Note: All States Shown
21
Min.
8
6.5
10
10
±10
5
±0.8
24.5
40
0.4
±15
Typ.
Max.
12
8
Units
GHz
dB
dB
dB
deg
deg
dB
dBm
dBm
µA
1
For price, delivery and to place orders: Hittite Microwave Corporation, 2 Elizabeth Drive, Chelmsford, MA 01824
Phone: 978-250-3343
Fax: 978-250-3373
Order On-line at www.hittite.com
Application Support: Phone: 978-250-3343 or apps@hittite.com
HMC543LC4B
v05.0514
22.5° MMIC 4-BIT DIGITAL
PHASE SHIFTER, 8 - 12 GHz
Insertion Loss, All States
0
-2
INSERTION LOSS (dB)
-4
-6
-8
-10
-12
8
9
10
FREQUENCY (GHz)
11
12
Normalized Loss, All States
4
2
1
0
-1
-2
-3
-4
8
9
10
FREQUENCY (GHz)
11
12
Input Return Loss, All States
0
-5
RETURN LOSS (dB)
-10
-15
-20
-25
-30
8
9
10
FREQUENCY (GHz)
11
12
Phase Error, All States
20
15
PHASE ERROR (degrees)
10
5
0
-5
-10
-15
-20
8
9
10
FREQUENCY (GHz)
11
12
Output Return Loss, All States
0
-5
RETURN LOSS (dB)
-10
-15
-20
-25
-30
8
9
10
FREQUENCY (GHz)
11
12
Relative Phase Shift, All States
400
RELATIVE PHASE SHIFT (degrees)
350
300
250
200
150
100
50
0
8
9
10
FREQUENCY (GHz)
11
12
For price, delivery and to place orders: Hittite Microwave Corporation, 2 Elizabeth Drive, Chelmsford, MA 01824
Phone: 978-250-3343
Fax: 978-250-3373
Order On-line at www.hittite.com
Application Support: Phone: 978-250-3343 or apps@hittite.com
PHASE SHIFTERS - DIGITAL - SMT
2
3
NORMALIZED LOSS (dB)
HMC543LC4B
v05.0514
22.5° MMIC 4-BIT DIGITAL
PHASE SHIFTER, 8 - 12 GHz
Relative Phase Shift,
RMS, Average, Max, All States
20
Input IP3, All States
55
50
PHASE SHIFTERS - DIGITAL - SMT
RELATIVE PHASE SHIFT (degrees)
15
10
5
0
-5
-10
8
9
10
FREQUENCY (GHz)
11
12
MAX
RMS
AVERAGE
IP3 (dBm)
45
40
35
30
25
8
9
10
FREQUENCY (GHz)
11
12
Input IP2, All States
100
Input P1dB, All States
30
90
P1dB (dBm)
28
IP2 (dBm)
80
26
70
24
60
22
50
8
9
10
FREQUENCY (GHz)
11
12
20
8
9
10
FREQUENCY (GHz)
11
12
RMS Phase Error vs. Temperature
20
RELATIVE PHASE SHIFT (degrees)
15
10
5
0
-5
-10
8
9
10
FREQUENCY (GHz)
11
12
+25C
+85C
-40C
Insertion Temperature All States
0
-2
INSERTION LOSS (dB)
-4
-6
-8
-10
-12
8
9
10
FREQUENCY (GHz)
11
12
3
For price, delivery and to place orders: Hittite Microwave Corporation, 2 Elizabeth Drive, Chelmsford, MA 01824
Phone: 978-250-3343
Fax: 978-250-3373
Order On-line at www.hittite.com
Application Support: Phone: 978-250-3343 or apps@hittite.com
