BSS138-F085 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> BSS138-F085

BSS138-F085: DescriptionMOSFET N-CH 50V 220MA SOT23; Categorysemiconductor Discrete semiconductor; File Size150KB，1 Pages; ManufacturerON Semiconductor; Websitehttp://www.onsemi.cn; Environmental Compliance

Download Datasheet Parametric View All

BSS138-F085 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BSS138-F085	-	-	View	Buy Now

BSS138-F085 Overview

MOSFET N-CH 50V 220MA SOT23

BSS138-F085 Parametric

Parameter Name	Attribute value
FET type	N channel
technology	MOSFET (metal oxide)
Drain-source voltage (Vdss)	50V
Current - Continuous Drain (Id) at 25°C	220mA（Ta）
Drive voltage (maximum Rds On, minimum Rds On)	4.5V，10V
Rds On (maximum value) when different Id, Vgs	3.5 ohms @ 220mA, 10V
Vgs (th) (maximum value) when different Id	1.5V @ 1mA
Gate charge (Qg) at different Vgs (maximum value)	2.4nC @ 10V
Vgs (maximum value)	±20V
Input capacitance (Ciss) at different Vds (maximum value)	27pF @ 25V
FET function	-
Power dissipation (maximum)	360mW（Ta）
Operating temperature	-55°C ~ 150°C（TJ）
Installation type	surface mount
Supplier device packaging	SOT-23
Package/casing	TO-236-3，SC-59，SOT-23-3

Preview

Download Datasheet

View All

Product Overview

BSS138_F085: N-Channel Logic Level Enhancement Mode Field Effect Transistor

60V, 220mA, 3.5Ω

For complete documentation, see the data sheet.

These N-Channel enhancement mode field effect tran sistors are produced using Fairchild’s proprietary, high cell density, DMOS

technology. These products have been designed to minimize on-state resistance while pro vide rugged, reliable, and fast switching

perfor mance.These products are particularly suited for low voltage, low current applications such as small servo motor control,

power MOSFET gate drivers, and otherswitching applications.

Features

• 0.22 A, 50 V

&emsp;R

DS(ON)

= 3.5Ω @ V

= 10 V

DS(ON)

= 6.0Ω @ V

= 4.5 V

• High density cell design for extremely low R

DS(ON)

• Rugged and Reliable

• Compact industry standard SOT-23 surface mount package

Applications

•

General Low Voltage and Low Current Application

Small Servo Motor Control

Power MOSFET Gate Drivers

General Switching Applications

For more information please contact your local sales support at www.onsemi.com.

Created on: 10/7/2018
