74HC05D datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Buffer and line drives> 74HC05D

74HC05D: DescriptionBuffer/Driver 6-CH Inverting Open Drain CMOS 14-Pin SOIC T/R; CategoryBuffer and line drives; File Size184KB，8 Pages; ManufacturerToshiba Semiconductor; Websitehttp://toshiba-semicon-storage.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

74HC05D Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	74HC05D	-	-	View	Buy Now

74HC05D Overview

Buffer/Driver 6-CH Inverting Open Drain CMOS 14-Pin SOIC T/R

74HC05D Parametric

Parameter Name	Attribute value
EU restricts the use of certain hazardous substances	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Logic Family	HC
Logic Function	Buffer/Driver
Number of Elements per Chip	6
Number of Channels per Chip	6
Number of Inputs per Chip	6
Number of Input Enables per Chip	0
Number of Outputs per Chip	6
Number of Output Enables per Chip	0
Bus Hold	No
Polarity	Inverting
Absolute Propagation Delay Time (ns)	135
Process Technology	CMOS
Input Signal Type	Single-Ended
Output Type	Open Drain
Maximum Low Level Output Current (mA)	5.2
Minimum Operating Supply Voltage (V)	2
Typical Operating Supply Voltage (V)	5
Maximum Operating Supply Voltage (V)	6
Maximum Quiescent Current (uA)	2
Propagation Delay Test Condition (pF)	50
Maximum Power Dissipation (mW)	500
Minimum Operating Temperature (°C)	-40
Maximum Operating Temperature (°C)	125
Packaging	Tape and Reel
Standard Package Name	SOP
Supplier Package	SOIC
Pin Count	14
Mounting	Surface Mount
Package Height	1.38
Package Length	8.95(Max)
Package Width	3.9
PCB changed	14
Lead Shape	Gull-wing

Preview

Download Datasheet

View All

74HC05D

CMOS Digital Integrated Circuits Silicon Monolithic

74HC05D

1. Functional Description

•

Hex Inverter (Open Drain)

2. General

The 74HC05D is a high speed CMOS INVERTER fabricated with silicon gate C

MOS technology.

It achieves the high speed operation similar to equivalent LSTTL while maintaining the CMOS low power

dissipation.

Pin configuration and function are the same as the 74HC04D, but the 74HC05D has high performance MOS N-

channel transistor (open-drain) outputs.

This device can, therefore, with a suitable pull-up resistors, be used in wired-AND, LED drive and other

applications.

All inputs are equipped with protection circuits against static discharge or transient excess voltage.

3. Features

(1)

(2)

(3)

(4)

High speed: t

= 8 ns (typ.) at V

= 5 V

Low power dissipation: I

= 1.0

µA

(max) at T

= 25



Wide operating voltage range: V

CC(opr)

= 2.0 to 6.0 V

Open drain structure

4. Packaging

SOIC14

Start of commercial production

2016-05

2016-08-04

Rev.3.0

74HC05D Related Products

	74HC05D	74HC05D(BJ)
Description	Buffer/Driver 6-CH Inverting Open Drain CMOS 14-Pin SOIC T/R	Buffer/Driver 6-CH Inverting Open Drain CMOS 14-Pin SOIC T/R
EU restricts the use of certain hazardous substances	Compliant	Compliant
ECCN (US)	EAR99	EAR99
Part Status	Active	Active
HTS	8542.39.00.01	8542.39.00.01
Logic Family	HC	HC
Logic Function	Buffer/Driver	Buffer/Driver
Number of Elements per Chip	6	6
Number of Channels per Chip	6	6
Number of Inputs per Chip	6	6
Number of Outputs per Chip	6	6
Bus Hold	No	No
Polarity	Inverting	Inverting
Absolute Propagation Delay Time (ns)	135	135
Process Technology	CMOS	CMOS
Input Signal Type	Single-Ended	Single-Ended
Output Type	Open Drain	Open Drain
Maximum Low Level Output Current (mA)	5.2	5.2
Minimum Operating Supply Voltage (V)	2	2
Typical Operating Supply Voltage (V)	5	5
Maximum Operating Supply Voltage (V)	6	6
Maximum Quiescent Current (uA)	2	2
Propagation Delay Test Condition (pF)	50	50
Maximum Power Dissipation (mW)	500	500
Minimum Operating Temperature (°C)	-40	-40
Maximum Operating Temperature (°C)	125	125
Packaging	Tape and Reel	Tape and Reel
Standard Package Name	SOP	SOP
Supplier Package	SOIC	SOIC
Pin Count	14	14
Mounting	Surface Mount	Surface Mount
Package Height	1.38	1.38
Package Length	8.95(Max)	8.95(Max)
Package Width	3.9	3.9
PCB changed	14	14
Lead Shape	Gull-wing	Gull-wing
