Laird Technologies' products or subcomponents are not specifically designed or tested by Laird Technologies for use in any medical applications,
surgical applications, medical device manufacturing, or any similar procedure or process requiring approval, testing, or certification by the United States
food and drug administration or other similar Governmental entity. Applications with unusual environmental requirements such as military, medical,
life-support or Life-sustaining equipment are specifically not recommended without additional testing for such application.
3
www.lairdtech.com
QuALITy ASSuRANCE
QuALITy PHILOSOPHy
Customer focus is paramount in our quality program. Our quality philosophy is outlined as follows:
Laird Technologies is a company committed to continuous improvement. We fulfill this commitment by continually improving
the quality of the products and services we provide our customers, both external and internal.
We recognize that our customers define quality. We further recognize that continuous improvement can only result from the
fullest development of our people and technologies.
We believe that to pursue this course, we must set unselfish service as our standard for conduct. Building on the values of
our history, we will raise our standards of performance through continuous improvement and imagination. In addition, our
actions must demonstrate integrity, honesty, excellence and self-discipline.
We believe in teamwork. Our commitment to continuous improvement is fulfilled and maintained by the combined, cohesive
efforts of people with a common goal.
QuALITy mEASuREmENT SySTEm
Laird Technologies’ Quality Management Systems have been certified to the ISO 9001:2000 requirements by Ceramic
Industry Certification Scheme Ltd.
QuALITy TESTING
We test on the following equipment:
Inductance, Loss Factor: Hewlett-Packard 4274A Multi-Frequency LCR Meter
Hewlett-Packard 4275A Multi-Frequency LCR Meter
Hewlett-Packard 4284A Multi-Frequency LCR Meter
Impedance:
Hewlett-Packard 4396B Network/Spectrum Analyzer
Hewlett-Packard 4991A Network/Spectrum Analyzer
4
www.lairdtech.com
PART IDENTIfICATION
PART NumBERS
Part numbers use a ten character alphanumeric
nomenclature providing:
• The material designation
• The product type (shape)
• A basic size description
• A parts modifier series
PRODuCT TyPES
35
T
______ - __ __ __
Transformer and Filter Core Division uses two basic
shape designators:
T for toroidal cores
Example: 35T0100-00P
N for balun cores
Example: 35N0136-00P
P
Parylene
Coating
PART NumBERING SySTEm ExAmPLE
35
T
0100
-0
0
Material Product Part Size
Part
Catalog
Type
Code
Code Thickness
Specification
BASIC SIzE DESCRIPTION
35 T
0100
- __ __ __
A two digit material designator is assigned to materials on the
basis of initial permeability.
Typical Application
material
35
Common mode
filtering
28
25
38
36
DC Bias Ethernet
Transformers
46
56
66
High Perm
for Telecom
42
40*
Initial
Permeability
5000
850
125
1700
4500
4000
5500
3200
7500
10000
mATERIAL DESIGNATOR
35
__
______ - __ __ __
The four digits following the product description provide the
largest dimension of the part in thousandths of an inch. For
toroids and similar shapes, it usually describes the outside or
major diameter of the core.
For other types of parts, it is the largest dimension specified in
the part’s description.
PARTS mODIfIER SERIES
35 T 0100 -
00P
The first of the three digits following the dash refers to the part
thickness. A zero through nine digit refers variations in thickness
from the same tool. The second modifying digit relates to a
custom requirement (electrical testing or physical specification).
The third digit or letter describes a coating or finish.
COATING DESIGNATIONS
P
— Parylene
Hi-Pot Rating 1000 VAC minimum
Nominal Thickness: 0.0005” / 0.0127 mm
H
— Epoxy
Hi-Pot Rating 1000 VAC minimum
Nominal Thickness: 0.003” / 0.0762 mm
* 40 material large toroids are mostly used for very low frequency
