5601250400

Description
RETAINER 4P
CategoryThe connector
File Size1MB,10 Pages
ManufacturerMolex Premise Network
Environmental Compliance
Download Datasheet Parametric Compare View All

5601250400 Overview

RETAINER 4P

5601250400 Parametric

Parameter NameAttribute value
Accessory typeTerminal Positioning Assembly (TPA)
Number of pins4
Supporting products/related productsDuraClik™ Series
characteristic-
APPLICATION SPECIFICATION
2.0mm PITCH W/B CONN. DURACLIK
TM
ISL SERIES APPLICATION GUIDE
[PURPOSE AND SUMMARY]
이 지침서는 한국 몰렉스의 2.0mm PITCH W/B CONN. DURACLIK
TM
ISL (INDEPENDENT
SECONDARY LOCK) SERIES의 HEADER ASSY 제품 및 상대물 FEMALE CONNECTOR에 대한 취급
매뉴얼 목적으로 사용한다. (HEADER ASSY (R/A) : 502352 시리즈, HEADER ASSY (S/T) : 560020
시리즈, FEMALE CONNECTOR : 560123 시리즈, ISL RETAINER : 560125 시리즈, FEMALE
TERMINAL : 560124 시리즈 )
THE PURPOSE OF THIS MANUAL IS TO BE USED FOR USING 2.0mm PITCH W/B CONN.
DURACLIK
TM
ISL (INDEPENDENT SECONDARY LOCK) SERIES, HEADER ASSY PARTS AND COUNTER
PARTS OF FEMALE CONNECTOR (HEADER ASSY (R/A) : 502352 SERIES, HEADER ASSY (S/T) :
560020 SERIES, FEMALE CONNECTOR : 560123 SERIES, ISL RETAINER : 560125 SERIES, FEMALE
TERMINAL : 560124 SERIES )
Table of Contents
Section 1 : Product Introduction
Section 2 : Product Summary (Connector & Terminal Assembly)
Section 3 : Service Instruction (Rework Method)
Section 4 : Precaution During Continuity Inspection
Section 5 : Product Name and Part Number
REVISION:
ECR/ECN INFORMATION:
EC No:
KTR 2016-0063
DATE:
2016 / 03 / 21
CREATED / REVISED BY:
CHECKED BY:
TITLE:
SHEET No.
A
DURACLIK
TM
ISL APPLICATION GUIDE
1
of
10
JY Choi
DOCUMENT NUMBER:
APPROVED BY:
AS-560123-001
SJ Lee
BC Yoon
TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC
