Series 126
Dual-in-line sockets
Open frame
Wire-wrap posts with solder tails
71
This socket is equipped
with contacts combining
two connection tech-
niques: up to three-level
wrapping plus PCB sold-
ering
Also suitable for use as an
interconnect socket with
intermediate wire-wrap
connections. Custom
lengths on request
Insertion characteristics:
4-finger standard
Platings
93
Sleeve
5
µm
Sn Pb
Clip
0.75
µm
Au
Pin
Ordering information
For complete part number see Order Codes list below
No.
of
poles
Order Codes
Plating 93
B
L = 5.9
1 Level
Plating 93
B
L = 8.9
2 Level
126-93-210-41-002
126-93-304-41-002
126-93-306-41-002
126-93-308-41-002
126-93-310-41-002
126-93-312-41-002
126-93-314-41-002
126-93-316-41-002
126-93-318-41-002
126-93-320-41-002
126-93-322-41-002
126-93-324-41-002
126-93-328-41-002
126-93-420-41-002
126-93-422-41-002
126-93-424-41-002
126-93-428-41-002
126-93-432-41-002
126-93-610-41-002
126-93-624-41-002
126-93-628-41-002
126-93-632-41-002
126-93-636-41-002
126-93-640-41-002
126-93-642-41-002
126-93-648-41-002
126-93-650-41-002
126-93-652-41-002
126-93-950-41-002
126-93-952-41-002
126-93-964-41-002
Plating 93
B
L = 11.9
3 Level
126-93-210-41-003
126-93-304-41-003
126-93-306-41-003
126-93-308-41-003
126-93-310-41-003
126-93-312-41-003
126-93-314-41-003
126-93-316-41-003
126-93-318-41-003
126-93-320-41-003
126-93-322-41-003
126-93-324-41-003
126-93-328-41-003
126-93-420-41-003
126-93-422-41-003
126-93-424-41-003
126-93-428-41-003
126-93-432-41-003
126-93-610-41-003
126-93-624-41-003
126-93-628-41-003
126-93-632-41-003
126-93-636-41-003
126-93-640-41-003
126-93-642-41-003
126-93-648-41-003
126-93-650-41-003
126-93-652-41-003
126-93-950-41-003
126-93-952-41-003
126-93-964-41-003
Insulator
dimen-
sions
See
page 50
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
aFig.
5a
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12
aFig.
12a
Fig. 13
Fig. 14
Fig. 15
Fig. 16
aFig.
16a
Fig. 17
Fig. 18
Fig. 19
Fig. 20
Fig. 21
Fig. 22
Fig. 23
Fig. 24
Fig. 25
Fig. 26
Fig. 27
Fig. 28
A
12.6
5.0
7.6
10.1
12.6
15.2
17.7
20.3
22.8
25.3
27.8
30.4
35.5
25.3
27.8
30.4
35.5
40.6
12.6
30.4
35.5
40.6
45.7
50.6
53.2
60.9
63.4
65.9
B
5.08
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
10.16
10.16
10.16
10.16
10.16
15.24
15.24
15.24
15.24
15.24
15.24
15.24
15.24
15.24
15.24
C
7.6
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
12.6
12.6
12.6
12.6
12.6
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
10
4
6
8
10
12
14
16
18
20
22
24
28
20
22
24
28
32
10
24
28
32
36
40
42
48
50
52
50
52
64
126-93-210-41-001
126-93-304-41-001
126-93-306-41-001
126-93-308-41-001
126-93-310-41-001
126-93-312-41-001
126-93-314-41-001
126-93-316-41-001
126-93-318-41-001
126-93-320-41-001
126-93-322-41-001
126-93-324-41-001
126-93-328-41-001
126-93-420-41-001
126-93-422-41-001
126-93-424-41-001
126-93-428-41-001
126-93-432-41-001
126-93-610-41-001
126-93-624-41-001
126-93-628-41-001
126-93-632-41-001
126-93-636-41-001
126-93-640-41-001
126-93-642-41-001
126-93-648-41-001
126-93-650-41-001
126-93-652-41-001
126-93-950-41-001
126-93-952-41-001
126-93-964-41-001
63.4 22.86 25.3
65.9 22.86 25.3
81.1 22.86 25.3
B
Products not available from stock. Please consult PRECI-DIP.
