700 Series
Solid State Digital Hourmeters & Counters
The Curtis 700 Series are highly reliable solid state hour meters and counters that offer an
unprecedented combination of patented technology, performance, reliability and value.
MODEL 700:
2-Wire Hour Meter, displays only when powered. Available in AC/DC.
MODEL 701:
3-Wire Hour Meter, has a provision or continuous display. Available in AC/DC and DC-only.
MODEL 703:
Pulse Counter. Available in AC/DC and DC-only.
A wide variety of industrial and commercial applications, including scheduled maintenance, warranty
and leasing – for medical equipment, transport and industrial vehicles and other industrial equipment.
FEATURES
▶
▶
All-8’s LCD function test: each digit displays an eight for
one second after power-up.
Attractive 6-digit LCD 5mm or 7mm high digits
(7mm with optional backlighting) are much easier
to read than electromechanical meters, which
have only 3mm high digits.
Silent operation – no moving parts. Eliminates
annoying gear and motor noise.
Exceptional reliability due to nonvolatile memory
(EEPROM) which retains data for 25+ years.
Wide voltage ranges, for example, one unit
can be powered from 75 to 270 VAC anywhere
between 48 and 440 Hz – ideal for distribution
and worldwide markets without having to
stock multiple model types.
Electrical reset (optional).
Available in ten case styles – all fit in standard
hour meter/counter cutouts.
Multiple mountings available – Metal U-bracket, “U” clamp/
stud (D, Q, R and S cases), flange mount with hardware
(F, T, G, J cases), or mounting clip (G, L, Y, Z, cases).
Backlit units allow external illumination control,
i.e., on/off or dimmer (12VDC only).
Flashing hourglass icon indicates when the hour
meter is accumulating time.
Memory will arm only when power has been applied
for five seconds (with no loss of time or counts).
Low power consumption.
UL and CE recognized.
See a 360° view of the 700 Series at:
curtisinstruments.com/360view
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
www.curtisinstruments.com
2
700 Series
Solid State Digital Hourmeters & Counters
SPECIFICATIONS
Case
Style
D
Bezel
Shape
Rectangular
Lens
Material
Acrylic
Case
Material
ABS
IP Rating
Front/
Rear
65/50
Termination
UL5/
CE
Yes
Suggested
Panel
Cutout m
45.0 x 22.2
3/16” Spade
F/T
Hexagonal
Acrylic
ABS
65/65
Spade
7
Yes
36.8 x 24.1
G
Hexagonal
Acrylic
ABS
65/65
1
Packard (2 pin)
2
Yes
36.8 x 24.1
J
Hexagonal
Acrylic
ABS
65/65
1
Packard (4 pin)
3
Yes
36.8 x 24.1
L
Rectangular
Polycarbonate
Polycarbonate
65/40
Molex
4
Yes
36.8 x 24.1
Q
Round
Polycarbonate
Polycarbonate
65/50
6
1/4” Spade
Yes
ø52 (ø2–1/16)
R (5mm)
Round
Glass
Polycarbonate
65/50
3/16” Spade
Yes
ø52 (ø2–1/16)
R (7mm)
Round
Polycarbonate
Polycarbonate
52/50
1/4” Spade
Yes
ø52 (ø2–1/16)
S
Square
ABS
ABS
2.35
1/4” Spade
Yes
45.0 x 45.0
Y
Rectangular
Acrylic
ABS
65/65
1
Packard (4 pin)
3
Yes
36.8 x 24.1
Z
Rectangular
Acrylic
ABS
65/65
1/4” Spade
Yes
36.8 x 24.1
www.curtisinstruments.com
3
700 Series
Solid State Digital Hourmeters & Counters
SPECIFICATIONS
Display
Range & Resolution
Accuracy
Humidity
Operating Temperature
Storage Temperature
Mechanical Shock
Mechanical Vibration
Operating Frequency
(AC powered units)
Memory
6 digit LCD, 5 or 7mm high, 6 o’clock viewing angle
Hour meters: 99,999.9 hours
Counters: ±1 count
0.1%
Counters: ±1 count
95%, non-condensing at 38°C
–40°C to +85°C (–40ºF to +185ºF)
–50°C to +85°C (–58ºF to +185ºF)
SAE J 1378, 55g
SAE J 1378, 20g
48 to 440 Hz
Main power must be applied for 5 seconds to arm memory (with no loss
of time/counts). EEPROM, data retained for 25+ years without power
0.5mA max. @ 5VDC (0512D models)
0.8mA max. @ 12VDC (1248D models)
1.0mA max. @ 120VAC
2.0mA max. @ 230VAC
Counters (703 only): 500 Hz. max., 50% duty cycle
(1ms low, min., between consecutive highs)
Hour meters (701 only): Power must be applied
for 0.5s, min., to accumulate time
50ms min. at operating voltage. Main power must be
applied for a minimum of 250ms prior to reset signal
Current Consumption
(Power Terminals)
Input Signal (DC-only)
Input Signal (AC/DC)
Reset
NOTES:
1. Mating connector must be installed.
2. Equivalent to Delphi-Packard connector P/N 12162000 2-pin.
3. Equivalent to Delphi-Packard connector P/N 15336035 4-pin.
4. Equivalent to Molex connector P/N 43045–0412.
www.curtisinstruments.com
5. UL files AU1841 and E45175.
6. R(5mm) and Q housings also available in a 65/65 version
(see model encodement).
7. F= 1/4”, T= 3/16”
4
700 Series
Solid State Digital Hourmeters & Counters
MODEL NUMBER ENCODING
1
3
5
Case
Style
Additional
Features
Operating
Voltage
Example
700 Series
R
R
Reset Options
2
001
O
Logo
4
0512D0612A
700 SERIES
(2-wire hour
meter,
AC/DC only
(3-wire hour
meter,AC/DC
or DC-only
(3-wire
counter, AC/DC
or DC-only)
CASE
STYLES
1
RESET
OPTIONS
2
3
ADDITIONAL FEATURES
4
LOGO
700
D
F/T
G
J
L
2
Q
R
S
Y
Z
N
2
R
Electrically
resettable
001
091
601
701
5mm, non-backlit display (Standard)
Epoxy filled unit (moisture resistant,
Q, R (5mm), cases only)
7mm, backlit display (R or S case only)
N
2
7mm, non-backlit display (R or S case only)
O
Curtis
Logo
701
703
Non-
resettable
No
Logo
5
OPERATING VOLTAGE
0512D
1248D
48150D
0512D0612A
1248D2060A
5–12VDC nom., 4.75–15VDC abs.
12–48VDC nom., 9–60VDC abs.
48–150VDC nom., 36–185VDC abs.
5–12VDC nom., 4.75–15VDC abs., 6–12VAC nom., 5–15VAC abs.
12–48VDC nom., 9–60VDC abs., 20–60VAC nom., 15–75VAC abs.
48–150VDC nom., 36–185VDC abs., 100–230VAC nom., 75–270VAC abs.
NOTES:
1. Only model offered:
700GN001N1248D2060A
2. Only models offered:
700LN001N1248D2060A,
700LN001N48150D100230A
and 701LN001N1248D
* Custom logos are available.
Backlight available on 7mm
R or S cases only.
48150D100230A
www.curtisinstruments.com
5
