QTLP670CETR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> QTLP670CETR

QTLP670CETR: DescriptionLED ORANGE CLEAR 2PLCC SMD; CategoryLED optoelectronic/LED; File Size176KB，8 Pages; ManufacturerON Semiconductor; Websitehttp://www.onsemi.cn; Environmental Compliance

Download Datasheet Parametric Compare View All

QTLP670CETR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	QTLP670CETR	-	-	View	Buy Now

QTLP670CETR Overview

LED ORANGE CLEAR 2PLCC SMD

QTLP670CETR Parametric

Parameter Name	Attribute value
color	orange color
Lens color	colorless
Lens transparency	transparent
millicandela level	65mcd
Lens style/size	Round, with flat top, 2.40mm
Voltage - Forward (Vf) (Typical)	2V
Current - Test	20mA
perspective	120°
Installation type	surface mount
Wavelength - Main	615nm
Wavelength - Peak	620nm
characteristic	-
Package/casing	2-PLCC
Supplier device packaging	2-PLCC
size/dimensions	3.20mm length x 2.80mm width
Height (maximum value)	2.10mm

Preview

Download Datasheet

View All

SURFACE MOUNT LED LAMP

SUPER BRIGHT PLCC-2

QTLP670C-T

Red

QTLP670C-E

Orange

QTLP670C-AG

Yellow-Green

QTLP670C-IW

White

QTLP670C-S

Red

QTLP670C-O

Yellow-Orange

QTLP670C-IG

True Green

QTLP670C-R

Red

QTLP670C-Y

Yellow

QTLP670C-IB

Blue

PACKAGE DIMENSIONS

0.130 (3.3)

0.114 (2.9)

Ø0.094 [Ø2.4]

0.118 (3.0)

0.102 (2.6)

0.091 (2.3)

0.083 (2.1)

TOP

CATHODE

0.024 (0.6)

0.016 (0.4)

0.083 (2.1)

0.067 (1.7)

0.146 (3.7)

0.130 (3.3)

0.006 (0.15)

SIDE

0.032 (0.8)

CATHODE

BOTTOM

POLARITY

APPLICATIONS

NOTE:

Dimensions for all drawings are in inches (mm).

• Automotive interior lighting

• Status indication for consumer electronics and office

equipment

DESCRIPTION

These surface mount LEDs are designed with flat top and sides for the ease of pick-and-place by automatic placement equipment.

They are compatible with convective IR and vapor phase reflow soldering. The package size and configuration conform to EIA-535

BAAC standard specification for case size 3528 tantalum capacitor. These LEDs are ideal for backlighting and optical coupling into

light pipes.

FEATURES

• AllnGaP technology for -T, -S, -R, -E, -O, -Y and -AG

• InGaN/SiC technology for -IG, -IB and -IW

• Wide viewing angle of 120°



2001 Fairchild Semiconductor Corporation

DS300236

8/31/01

• Water clear optics

• Available in 0.315” (8mm) width tape on

7” (178mm) diameter reel; 2,000 units per reel

1 OF 8

www.fairchildsemi.com

QTLP670CETR Related Products

	QTLP670CETR	QTLP670CBTR	QTLP670CRTR	QTLP670CWTR	QTLP670CYTR
Description	LED ORANGE CLEAR 2PLCC SMD	LED BLUE CLEAR 2PLCC SMD	LED RED CLEAR 2PLCC SMD	LED WHITE CLEAR 2PLCC SMD	LED YELLOW CLEAR 2PLCC SMD
color	orange color	blue	red	White	yellow
Lens color	colorless	colorless	colorless	colorless	colorless
Lens transparency	transparent	transparent	transparent	transparent	transparent
millicandela level	65mcd	30mcd	65mcd	250mcd	65mcd
Lens style/size	Round, with flat top, 2.40mm	Round, with flat top, 2.40mm	Round, with flat top, 2.40mm	Round, with flat top, 2.40mm	Round, with flat top, 2.40mm
Voltage - Forward (Vf) (Typical)	2V	3.8V	2V	3.5V	2V
Current - Test	20mA	20mA	20mA	20mA	20mA
perspective	120°	120°	120°	120°	120°
Installation type	surface mount	surface mount	surface mount	surface mount	surface mount
Wavelength - Main	615nm	465nm	624nm	-	589nm
Wavelength - Peak	620nm	430nm	630nm	-	590nm
Package/casing	2-PLCC	2-PLCC	2-PLCC	2-PLCC	2-PLCC
Supplier device packaging	2-PLCC	2-PLCC	2-PLCC	2-PLCC	2-PLCC
size/dimensions	3.20mm length x 2.80mm width	3.20mm length x 2.80mm width	3.20mm length x 2.80mm width	3.20mm length x 2.80mm width	3.20mm length x 2.80mm width
Height (maximum value)	2.10mm	2.10mm	2.10mm	2.10mm	2.10mm
