WS128K32N-55G2TCEA

Description
128Kx32 SRAM MULTICHIP PACKAGE, RADIATION TOLLERANT
Categorystorage    storage
File Size323KB，6 Pages
ManufacturerWhite Electronic Designs Corporation
Websitehttp://www.wedc.com/
Download Datasheet Parametric View All

WS128K32N-55G2TCEA Overview

128Kx32 SRAM MULTICHIP PACKAGE, RADIATION TOLLERANT

WS128K32N-55G2TCEA Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerWhite Electronic Designs Corporation
package instruction22.4 X 22.4 MM, CERAMIC, QFP-68
Reach Compliance Codeunknown
Maximum access time55 ns
JESD-30 codeS-CQFP-G68
length22.36 mm
memory density4194304 bit
Memory IC TypeSRAM MODULE
memory width32
Number of functions1
Number of terminals68
word count131072 words
character code128000
Operating modeASYNCHRONOUS
Maximum operating temperature70 °C
Minimum operating temperature
organize128KX32
Package body materialCERAMIC, METAL-SEALED COFIRED
encapsulated codeQFP
Package shapeSQUARE
Package formFLATPACK
Parallel/SerialPARALLEL
Peak Reflow Temperature (Celsius)225
Certification statusNot Qualified
Maximum seat height4.57 mm
Maximum supply voltage (Vsup)5.5 V
Minimum supply voltage (Vsup)4.5 V
Nominal supply voltage (Vsup)5 V
surface mountYES
technologyCMOS
Temperature levelCOMMERCIAL
Terminal formGULL WING
Terminal pitch1.27 mm
Terminal locationQUAD
Maximum time at peak reflow temperature30
width22.36 mm

WS128K32N-55G2TCEA Preview

White Electronic Designs
WS128K32-XG2TXE
ADVANCED*
128Kx32 SRAM MULTICHIP PACKAGE, RADIATION TOLLERANT
FEATURES
Access Times of 35, 45, 55ns
Packaging
• 68 lead, 22.4mm CQFP (G2T), 4.57mm (0.180"),
(Package 509)
Organized as 128Kx32; User Configurable as
256Kx16 or 512Kx8
Low Power Data Retention
Commercial, Industrial and Military Temperature
Ranges
5V Power Supply
Low Power CMOS
* This product is under development, is not qualified or characterized and is subject to
change or cancellation without notice.
TTL Compatible Inputs and Outputs
Built in Decoupling Caps and Multiple Ground Pins
for Low Noise Operation
Weight
WS128K32-XG2TXE – 8 grams typical
Radiation tolerant with epitaxial layer on die.
6T memory cells provide excellent protection
against soft errors
FIGURE 1 – PIN CONFIGURATION FOR WS128K32N-XG2TXE
Top View
NC
A
0
A
1
A
2
A
3
A
4
A
5
CS
3
#
GND
CS
4
#
WE
1
#
A
6
A
7
A
8
A
9
A
10
V
CC
Pin Description
I/O
0-31
A
0-16
WE
1-4
#
CS
1-4
#
OE#
V
CC
GND
NC
Data Inputs/Outputs
Address Inputs
Write Enables
Chip Selects
Output Enable
Power Supply
Ground
Not Connected
9 8 7 6 5 4
I/O
0
I/O
1
I/O
2
I/O
3
I/O
4
I/O
5
I/O
6
I/O
7
GND
I/O
8
I/O
9
I/O
10
I/O
11
I/O
12
I/O
13
I/O
14
I/O
15
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
3 2 1 68 67 66 65 64 63 62 61
I/O
16
I/O
17
I/O
18
I/O
19
I/O
20
I/O
21
I/O
22
I/O
23
GND
I/O
24
I/O
25
I/O
26
I/O
27
I/O
28
I/O
29
I/O
30
I/O
31
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43
The White 68 lead G2T CQFP fills
the same fit and function as the
JEDEC 68 lead CQFJ or 68 PLCC.
But the G2T has the TCE and lead
inspection advantage of the CQFP
form.
OE#
A
0-16
Block Diagram
WE
1
# CS
1
#
WE
2
# CS
2
#
WE
3
# CS
3
#
WE
4
# CS
4
#
V
CC
A
11
A
12
A
13
A
14
A
15
A
16
CS
1
#
OE#
CS
2
#
NC
WE
2
#
WE
3
#
WE
4
#
NC
NC
NC
128K x 8
128K x 8
128K x 8
128K x 8
8
8
8
8
I/O
0-7
I/O
8-15
I/O
16-23
I/O
24-31
December 2000
Rev. 0
1
White Electronic Designs Corporation • (602) 437-1520 • www.wedc.com
White Electronic Designs
ABSOLUTE MAXIMUM RATINGS
Parameter
Operating Temperature
Storage Temperature
Signal Voltage Relative to GND
Junction Temperature
Supply Voltage
Symbol
T
A
T
STG
V
G
T
J
V
CC
Min
-55
-65
-0.5
-0.5
Max
+125
+150
V
CC
+0.5
150
7.0
Unit
°C
°C
V
°C
V
CS#
H
L
L
L
OE#
X
L
X
H
WE#
X
H
L
H
WS128K32-XG2TXE
ADVANCED
TRUTH TABLE
Mode
Standby
Read
Write
Out Disable
Data I/O
High Z
Data Out
Data In
High Z
Power
Standby
Active
Active
Active
RECOMMENDED OPERATING CONDITIONS
Parameter
Supply Voltage
Input High Voltage
Input Low Voltage
Opertating Temp. (MIL)
Symbol
V
CC
V
IH
V
IL
T
A
Min
4.5
2.2
-0.3
-55
Max
5.5
V
CC
+ 0.3
+0.8
+125
Unit
V
V
V
°C
CAPACITANCE
T
A
= +25°C
Parameter
OE# capacitance
WE
1-4
# capacitance
CQFP G2T
CS
1-4
# capacitance
Data# I/O capacitance
Address input capacitance
Symbol
Conditions
C
OE
V
IN
= 0V, f = 1.0 MHz
C
WE
V
IN
= 0V, f = 1.0 MHz
C
CS
C
I/O
C
AD
Max Unit
50 pF
pF
20
V
IN
= 0V, f = 1.0 MHz 20 pF
V
I/O
= 0V, f = 1.0 MHz 20 pF
V
IN
= 0V, f = 1.0 MHz 50 pF
RADIATION CHARACTERISTICS
Total Dose
(TM1019.5)
Functional
(Krads)
30
Parametric
(Krads)
30
Latch-up
25°C
V
CC
Max
This parameter is guaranteed by design but not tested.
SEU LET
Threshold
(V
CC
MIN)
Cross
Section
/BIT
(E-6 cm2)
Typical Iccsb (mA
)
(MeV/mg/cm2) (MeV/mg/cm2)
1.2
>100
2
0.2
DC CHARACTERISTICS
V
CC
= 5.0V, V
SS
= 0V, -55°C
≤
T
A
≤
+125°C
Parameter
Input Leakage Current
Output Leakage Current
Operating Supply Current
Standby Current
Output Low Voltage
Output High Voltage
NOTE: DC test conditions: V
IH
= V
CC
-0.3V, V
IL
= 0.3V
Sym
I
LI
I
LO
I
CC
I
SB
V
OL
V
OH
Conditions
V
CC
= 5.5, V
IN
= GND to V
CC
CS# = V
IH
, OE# = V
IH
, V
OUT
= GND to V
CC
CS# = V
IL
, OE# = V
IH
, f = 5MHz, V
CC
= 5.5
CS# = V
IH
, OE# = V
IH
, f = 5MHz, V
CC
= 5.5
I
OL
= 8mA, V
CC
= 4.5
I
OH
= -40mA, V
CC
= 4.5
Min
Max
10
10
520
8
0.4
Units
µA
µA
mA
mA
V
V
2.4
DATA RETENTION CHARACTERISTICS
-55°C
≤
T
A
≤
+125°C
Characteristic
Data Retention Voltage
Data Retention Quiescent Current
Chip Disable to Data Retention Time (1)
Operation Recovery Time (1)
NOTE: Parameter guaranteed, but not tested.
December 2000
Rev. 0
2
White Electronic Designs Corporation • (602) 437-1520 • www.wedc.com
Sym
V
CC
I
CCDR
T
CDR
T
R
Conditions
V
CC
= 2.0V
CS ≥ V
CC
-0.2V
V
IN
≥ V
CC
-0.2V
or V
IN
≤ 0.2V
Min
2
—
0
T
RC
Max
—
1
—
—
Units
V
mA
ns
ns
White Electronic Designs
AC CHARACTERISTICS
V
CC
= 5.0V, GND = 0V, -55°C
≤
T
A
≤
+125°C
Parameter
Read Cycle
Read Cycle Time
Address Access Time
Output Hold from Address Change
Chip Select Access Time
Output Enable to Output Valid
Chip Select to Output in Low Z
Output Enable to Output in Low Z
Chip Disable to Output in High Z
Output Disable to Output in High Z
Symbol
t
RC
t
AA
t
OH
t
ACS
t
OE
t
CLZ
1
t
OLZ
1
t
CHZ
1
t
OHZ
1
Min
35
3
35
15
3
0
20
12
3
0
20
15
-35
Max
35
3
45
20
Min
45
-45
Max
45
WS128K32-XG2TXE
ADVANCED
-55
Min
55
3
55
30
3
0
20
20
Max
55
Units
ns
ns
ns
ns
ns
ns
ns
ns
ns
1. This parameter is guaranteed by design but not tested.
AC CHARACTERISTICS
V
CC
= 5.0V, GND = 0V, -55°C
≤
T
A
≤
+125°C
Parameter
Write Cycle
Write Cycle Time
Chip Select to End of Write
Address Valid to End of Write
Data Valid to End of Write
Write Pulse Width
Address Setup Time
Address Hold Time
Output Active from End of Write
Write Enable to Output in High Z
Data Hold Time
Symbol
t
WC
t
CW
t
AW
t
DW
t
WP
t
AS
t
AH
t
OW
1
t
WHZ
1
t
DH
Min
35
25
25
20
25
0
0
0
0
-35
Max
Min
45
35
35
25
35
0
0
0
0
-45
Max
Min
55
45
45
25
45
0
0
0
0
-55
Max
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
Units
10
15
20
1. This parameter is guaranteed by design but not tested.
FIGURE 2 – AC TEST CIRCUIT
AC Test Conditions
I
OL
Current Source
D.U.T.
C
eff
= 50 pf
V
Z
1.5V
Parameter
Input Pulse Levels
Input Rise and Fall
Input and Output Reference Level
Output Timing Reference Level
Typ
V
IL
= 0, V
IH
= 3.0
5
1.5
1.5
Unit
V
ns
V
V
(Bipolar Supply)
I
OH
Current Source
Notes:
V
Z
is programmable from -2V to +7V.
I
OL
& I
OH
programmable from 0 to 16mA.
Tester Impedance Z0 = 75Ω.
V
Z
is typically the midpoint of V
OH
and V
OL
.
I
OL
& I
OH
are adjusted to simulate a typical resistive load circuit.
ATE tester includes jig capacitance.
December 2000
Rev. 0
3
White Electronic Designs Corporation • (602) 437-1520 • www.wedc.com
White Electronic Designs
WS128K32-XG2TXE
ADVANCED
FIGURE 3 – TIMING WAVEFORM - READ CYCLE
CS#
OE#
READ CYCLE 1, (CS# = OE# = V
IL
, WE# = V
IH
)
READ CYCLE 2 (WE# = V
IH
)
FIGURE 4 – WRITE CYCLE - WE# CONTROLLED
CS#
WE#
WRITE CYCLE 1, WE# CONTROLLED
FIGURE 5 – WRITE CYCLE - CS# CONTROLLED
WS32K32-XHX
CS#
WE#
WRITE CYCLE 2, CS# CONTROLLED
December 2000
Rev. 0
4
White Electronic Designs Corporation • (602) 437-1520 • www.wedc.com
White Electronic Designs
WS128K32-XG2TXE
ADVANCED
PACKAGE 510: 68 LEAD, CERAMIC QUAD FLAT PACK, CQFP (G2T)
25.15 (0.990) ± 0.26 (0.010) SQ
22.36 (0.880) ± 0.26 (0.010) SQ
4.57 (0.180) MAX
0.27 (0.011) ± 0.04 (0.002)
Pin 1
0.25 (0.010) REF
24.03 (0.946)
± 0.26 (0.010)
1° / 7°
1.0 (0.040)
± 0.127 (0.005)
R 0.25
(0.010)
0.19 (0.007)
± 0.06 (0.002)
23.87
(0.940) REF
DETAIL A
1.27
(0.050)
TYP
SEE DETAIL "A"
0.38 (0.015) ± 0.05 (0.002)
20.3 (0.800) REF
The White 68 lead G2T CQFP
fills the same fit and function
as the JEDEC 68 lead CQFJ
or 68 PLCC. But the G2T has
the TCE and lead inspection
advantage of the CQFP form.
0.940"
TYP
ALL LINEAR DIMENSIONS ARE MILLIMETERS AND PARENTHETICALLY IN INCHES
December 2000
Rev. 0
5
White Electronic Designs Corporation • (602) 437-1520 • www.wedc.com
More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >

Recommended Resources

Ignite fluorescent lamp circuit at low temperature and low pressure

base amplitude modulation circuit

Lithium battery fast charger circuit diagram

Divider circuit composed of multiplier MPY600

AC/DC clock circuit

Gate overvoltage protection circuit

Please give me some advice, thanks.
I learned MCU in college but I haven't used it for a long time. Now I want to work in this industry, but the emergence of embedded ARM makes me very annoyed, because I want to go for training, but I d...
yanchao05 Embedded System
【R7F0C809】Detailed explanation of the "lazy" wireless computer remote control project (1)
[align=left][font=宋体]First of all, the first question is, has this thing been made? The answer is yes, the project documents will be released in batches later, hehe! [/font][/align][align=left] [/alig...
youki12345 Renesas Electronics MCUs
[Energia Development Environment] MSP430 LAUNCHPAD Study Notes 1--Lab1 Blinking a LED
[align=left]【Energi[/font][font=宋体]Development[/font]Software】MSP430 LAUNCHPAD[/font][font=宋体]Study Notes[/font][font=Times New Roman]1--Lab1 Blinking a LED[/font] [/align][align=left] [/align][align=...
qinkaiabc Microcontroller MCU
Diode
What is the function of the voltage regulator diode in the picture?...
zhonghuadianzie Analog electronics
100% Earn E-Coins or Red Packets: Tektronix will help you solve USB development and testing problems. Download, complain/share experiences to win good gifts
[align=center][size=5]{:1_123:}How many challenges are there in USB development and testing? Tektronix will help you break through~ [/size][/align][align=left][size=5][b]Activity content [/b][/size] [...
EEWORLD社区 Test/Measurement
Is it difficult to draw a switch power board?
I plan to draw switching power supplies and adapter boards ranging from tens to 500W. I wonder if I can learn a lot of knowledge, and can I draw high-power power supplies?...
605179640 PCB Design
Shortcut:   S0 S1 S2 S3 S4 S5 S6 S7 S8 S9 SA SB SC SD SE SF SG SH SI SJ SK SL SM SN SO SP SQ SR SS ST SU SV SW SX SY SZ T0 T1 T2 T3 T4 T5 T6 T7 T8 T9 TA TB TC TD TE TF TG TH TI TJ TK TL TM TN TO TP TQ TR TS TT TU TV TW TX TY TZ U0 U1 U2 U3 U4 U6 U7 U8 UA UB UC UD UE UF UG UH UI UJ UK UL UM UN UP UQ UR US UT UU UV UW UX UZ V0 V1 V2 V3 V4 V5 V6 V7 V8 V9 VA VB VC VD VE VF VG VH VI VJ VK VL VM VN VO VP VQ VR VS VT VU VV VW VX VY VZ W0 W1 W2 W3 W4 W5 W6 W7 W8 W9 WA WB WC WD WE WF WG WH WI WJ WK WL WM WN WO WP WR WS WT WU WV WW WY X0 X1 X2 X3 X4 X5 X7 X8 X9 XA XB XC XD XE XF XG XH XK XL XM XN XO XP XQ XR XS XT XU XV XW XX XY XZ Y0 Y1 Y2 Y4 Y5 Y6 Y9 YA YB YC YD YE YF YG YH YK YL YM YN YP YQ YR YS YT YX Z0 Z1 Z2 Z3 Z4 Z5 Z6 Z8 ZA ZB ZC ZD ZE ZF ZG ZH ZJ ZL ZM ZN ZP ZR ZS ZT ZU ZV ZW ZX ZY

Popular Components

  1. 1200SGH30IPB3UB
  2. VCC1-H0F-68M736
  3. RNC55K2133DRB14
  4. 2PH420UA30
  5. SNSR150J7-27.00000
  6. FP2001681422CCBC
  7. M058SZAN
  8. SR1209NPO103Z16VNT66
  9. A2005HC-N-2x16P-FI
  10. C4201WV-F1-2x12P-V0-BL
  11. CR1206F52K3P05Z
  12. MP2305KGE6XLC

Popular Articles

  1. How to use the Fluke DSX-5000 network cable tester to perform an alien crosstalk test
  2. ZDS2022 Oscilloscope 100 Practical Specials 30: UART Protocol Trigger
  3. Being at the forefront of automotive electronics, where will the automotive industry head?
  4. Large-scale power outage in Dresden, a major wafer manufacturing center in Germany, may affect GlobalFoundries, Infineon Technologies, etc.
  5. Celebrating the 100 millionth EyeQ® chip on the road
  6. The difference between fixed frequency motor and variable frequency motor
  7. It turns out that the main function of the microcontroller is executed here
  8. Analysis of the main features and advantages of Keithley 2600A series digital source meters
  9. Application solution of DS70000 series digital oscilloscope in USB2.0 conformance analysis test

Technical ResourceMore

  1. Programming tool SmartPRO.bkill
  2. Video technical information (video signal principle-analog signal classification)
  3. IC driver module
  4. MATLAB Case 5 Strong Classifier Design Based on BP_Adaboost-Company Financial Early Warning Modeling.rar
  5. Power adapter inspection specifications
  6. Altium Designer schematic library ICD2.SchLib
  7. Altium-Common 3D Package Library (Step) [Common Patch] DO-41Z.rar
  8. Planar Transformer
  9. NCP1562 Active Clamp Driver IC Chinese Instructions
  10. Flyback Circuit Waveform Analysis

EEWorld
subscription
account

EEWorld
service
account

Automotive
development
circle

Robot
development
community

About Us Customer Service Contact Information Datasheet Sitemap LatestNews
Index Files: 1954  2410  2687  2066  114  40  49  55  42  3
Datasheet   0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
Room 1530, 15th Floor, Building B, No. 18 Zhongguancun Street, Haidian District, Beijing Telephone: (010) 82350740 Postal Code: 100190
Copyright © 2005-2026 EEWORLD.com.cn, Inc. All rights reserved 京ICP证060456号 京ICP备10001474号-1 电信业务审批[2006]字第258号函 京公网安备 11010802033920号
