Dimensions: [mm]
Recommended Land Pattern: [mm]
51,5
37,5
Material:
Base Material
Plating
Version
Steel
Tin
SMD Frame
detail B
50,0 ±0,1
27,5
17,5
7,5
3,3
2,6
2,1
2,9
17,5
27,5
37,5
50,0 ±0,1
0,2 ±0,05
1,0
A
50,4
sectional drawing A-A
7,5 ±0,1
7,5 ±0,1
17,5 ±0,1
27,5 ±0,1
37,5 ±0,1
3,3
Scale - 1:2
B
Assembly with SMD Frame:
A
17,5 ±0,1
27,5 ±0,1
37,5 ±0,1
51,5
7,5
2,5
typ.
General Information:
Storage Temperature (in original
packaging)
Top Cover
Frame
r
0,15 circular
50,4 ±0,1
-20 °C up to +60 °C
-40 °C up to +125 °C
Operating Temperature
Test conditions of Electrical Properties: +20°C, 33% RH if not specified differently
Scale - 1:2
Scale - 1:2
Würth Elektronik eiSos GmbH & Co. KG
EMC & Inductive Solutions
Max-Eyth-Str. 1
74638 Waldenburg
Germany
Tel. +49 (0) 79 42 945 - 0
www.we-online.com
eiSos@we-online.com
CREATED
CHECKED
GENERAL TOLERANCE
PROJECTION
METHOD
KaS
DESCRIPTION
JoV
DIN ISO 2768-1m
WE-SHC Shielding Cabinet
ORDER CODE
36103505S
REVISION
STATUS
DATE (YYYY-MM-DD)
BUSINESS UNIT
PAGE
001.000
Valid
2017-06-21
eiSos
1/2
