BUK7E5R2-100E,127

Description
MOSFET N-CH 100V 120A I2PAK
Categorysemiconductor    Discrete semiconductor
File Size712KB,13 Pages
ManufacturerNexperia
Websitehttps://www.nexperia.com
Environmental Compliance
Download Datasheet Parametric View All

BUK7E5R2-100E,127 Overview

MOSFET N-CH 100V 120A I2PAK

BUK7E5R2-100E,127 Parametric

Parameter NameAttribute value
FET typeN channel
technologyMOSFET (metal oxide)
Drain-source voltage (Vdss)100V
Current - Continuous Drain (Id) at 25°C120A(Tc)
Drive voltage (maximum Rds On, minimum Rds On)10V
Rds On (maximum value) when different Id, Vgs5.2 milliohms @ 25A, 10V
Vgs (th) (maximum value) when different Id4V @ 1mA
Gate charge (Qg) at different Vgs (maximum value)180nC @ 10V
Vgs (maximum value)±20V
Input capacitance (Ciss) at different Vds (maximum value)11810pF @ 25V
FET function-
Power dissipation (maximum)349W(Tc)
Operating temperature-55°C ~ 175°C(TJ)
Installation typeThrough hole
Supplier device packagingI2PAK
Package/casingTO-262-3, long lead, I²Pak, TO-262AA
BUK7E5R2-100E
11 September 2012
N-channel TrenchMOS standard level FET
Product data sheet
1. Product profile
1.1 General description
Standard level N-channel MOSFET in a SOT226 package using TrenchMOS technology.
This product has been designed and qualified to AEC Q101 standard for use in high
performance automotive applications.
1.2 Features and benefits
AEC Q101 compliant
Repetitive avalanche rated
Suitable for thermally demanding environments due to 175 °C rating
True standard level gate with VGS(th) rating of greater than 1V at 175 °C
1.3 Applications
12V, 24V and 48V Automotive systems
Electric and electro-hydraulic power steering
Motors, lamps and solenoid control
Start-Stop micro-hybrid applications
Transmission control
Ultra high performance power switching
1.4 Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
R
DSon
Quick reference data
Parameter
drain-source voltage
drain current
total power dissipation
Conditions
T
j
≥ 25 °C; T
j
≤ 175 °C
V
GS
= 10 V; T
mb
= 25 °C;
Fig. 1
T
mb
= 25 °C;
Fig. 2
V
GS
= 10 V; I
D
= 25 A; T
j
= 25 °C;
Fig. 11
V
GS
= 10 V; I
D
= 25 A; V
DS
= 80 V;
T
j
= 25 °C;
Fig. 13; Fig. 14
[1]
Continuous current is limited by package.
[1]
Min
-
-
-
Typ
-
-
-
Max
100
120
349
Unit
V
A
W
Static characteristics
drain-source on-state
resistance
-
4.1
5.2
Dynamic characteristics
Q
GD
gate-drain charge
-
65
-
nC
