Feed-through terminal block - UK 3-RETURN - 3002513
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Universal terminal block with screw connection, cross section: 0,2- 2.5 mm², AWG: 24- 12, width: 5.2 mm,
color: Gray
Key Commercial Data
Packing unit
GTIN
GTIN
4017918090289
50 pc
Technical data
General
Number of levels
Number of connections
Potentials
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Maximum power dissipation for nominal condition
Maximum load current
Nominal current I
N
Nominal voltage U
N
Open side panel
Shock protection test specification
2
2
1
2.5 mm²
gray
PA
V2
6 kV
3
III
I
0.77 W (the value is multiplied when connecting multiple levels)
32 A (with 4 mm² conductor cross section)
32 A
500 V
Yes
DIN EN 50274 (VDE 0660-514):2002-11
11/11/2018 Page 1 / 5
https://www.phoenixcontact.com/pi/products/3002513
Feed-through terminal block - UK 3-RETURN - 3002513
Technical data
General
Back of the hand protection
Finger protection
Result of surge voltage test
Surge voltage test setpoint
Result of power-frequency withstand voltage test
Result of the test for mechanical stability of terminal points (5 x
conductor connection)
Result of bending test
Bending test rotation speed
Bending test turns
Bending test conductor cross section/weight
guaranteed
guaranteed
Test passed
7.3 kV
Test passed
Test passed
Test passed
10 rpm
135
0.2 mm² / 0.2 kg
2.5 mm² / 0.7 kg
4 mm² / 0.9 kg
Tensile test result
Conductor cross section tensile test
Tractive force setpoint
Conductor cross section tensile test
Tractive force setpoint
Conductor cross section tensile test
Tractive force setpoint
Result of tight fit on support
Tight fit on carrier
Setpoint
Result of voltage-drop test
Requirements, voltage drop
Result of temperature-rise test
Short circuit stability result
Conductor cross section short circuit testing
Short-time current
Conductor cross section short circuit testing
Short-time current
Result of thermal test
Proof of thermal characteristics (needle flame) effective duration
Relative insulation material temperature index (Elec., UL 746 B)
Temperature index of insulation material (DIN EN 60216-1 (VDE
0304-21))
Test passed
0.2 mm²
20 N
2.5 mm²
100 N
4 mm²
120 N
Test passed
NS 32/NS 35
1N
Test passed
≤ 3.2 mV
Test passed
Test passed
2.5 mm²
0.3 kA
4 mm²
0.48 kA
Test passed
30 s
125 °C
125 °C
Dimensions
Width
Length
Height NS 35/7,5
Height NS 35/15
5.2 mm
47.5 mm
58.5 mm
66 mm
11/11/2018 Page 2 / 5
https://www.phoenixcontact.com/pi/products/3002513
Feed-through terminal block - UK 3-RETURN - 3002513
Technical data
Dimensions
Height NS 32
63.5 mm
Connection data
Connection method
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Min. AWG conductor cross section, flexible
Max. AWG conductor cross section, flexible
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
Cross section with insertion bridge, solid max.
Cross section with insertion bridge, stranded max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
Connection in acc. with standard
Conductor cross section AWG min.
Conductor cross section AWG max.
Stripping length
Screw thread
Tightening torque, min
Tightening torque max
Screw connection
IEC / EN
0.2 mm²
4 mm²
24
12
0.2 mm²
2.5 mm²
24
14
0.25 mm²
0.25 mm²
1.5 mm²
4 mm²
2.5 mm²
0.2 mm²
1 mm²
0.2 mm²
1 mm²
0.5 mm²
1 mm²
0.25 mm²
1 mm²
UL
30
12
8 mm
M3
0.6 Nm
0.8 Nm
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
CSA
IEC / EN
V2
Environmental Product Compliance
11/11/2018 Page 3 / 5
https://www.phoenixcontact.com/pi/products/3002513
Feed-through terminal block - UK 3-RETURN - 3002513
Technical data
Environmental Product Compliance
China RoHS
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Approvals
Approvals
Approvals
CSA / UL Recognized / EAC
Ex Approvals
Approval details
CSA
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www.csagroup.org/services-industries/product-listing/
300 V
25 A
28-12
13631
UL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
300 V
20 A
30-12
FILE E 60425
EAC
EAC-Zulassung
