ZM3102
Z-Wave
®
Integrated Wireless Module
for Home Control
Target Markets
•
Home control
•
Home security and monitoring
•
Home energy management
Benefits
•
Integration of home, entertainment,
security, and energy management control
with metadata support
•
Seamless interoperability between multiple
vendors and applications
•
Robust and reliable whole-home coverage
through mesh networking
•
Z-Wave
®
protocol over IP (Internet
Protocol) networks, such as home network
and Internet
•
Supports unicast, multicast, and
broadcast messages
•
Low power consumption for multi-year
battery life
Features
Integrated CPU and RF transceiver
32KB flash, 2KB SRAM
Triac controller
4-ch 12-bit rail-to-rail ADC
Integrated GPIO, SPI, UART, PWM
Ultra-low power sleep mode
40 kbps data rates, low latency
Uses the unlicensed Short-Range Device
(SRD) frequency bands
•
Battery monitor and built-in supply
regulators
•
Power supply: 2.1-3.6V
•
12.5x13.6mm module, 18 pins
•
•
•
•
•
•
•
•
The ZM3102 represents the third-generation of Z-Wave
®
wireless technology, and is ideal
for easily adding Z-Wave
®
control and status capabilities to home control, home security
monitoring, and home energy management products. The ZM3102 module includes a Z-Wave
®
chip and external components required to implement a complete, drop-in solution.
The wireless mesh network technology automatically routes the RF signal from one Z-Wave
®
node
to the next, around obstacles and radio dead spots, resulting in high reliability and assured whole-
home coverage.
The ability to also use the Z-Wave
®
protocol over IP (Internet Protocol) networks allows Z-Wave
®
enabled products to connect seamlessly using the wireless mesh network, the home network, and
the Internet.
Z-Wave
®
allows both manufacturers and consumers the security of knowing that Z-Wave
®
certified
products, regardless of brand, will work together.
Powering the new digital home
Set-Top
Boxes
Consumer
Electronics
AV
Networks
Home
Control
Commercial
Systems
ZM3102
Z-Wave
®
Integrated Wireless Module
for Home Control
ZM3102
U.S. Sales Offices
Reset/
Brown
32 KB Flash Memory
Z-Wave SW API
User Application SW
System
Clock
General
Purpose
Timer
SigMa DeSignS, inc.
Tel: +1.201.981.3009
(OPTIONAL)
Antenna
Timer 0/1
Watchdog
8/12 Bit
ADC
international Sales Offices
aUSTRaLia, inDia, inDOneSia,
KORea, MaLaYSia, SingaPORe
Sigma Designs Technology Singapore
8 Kallang Sector
Level 10, East Wing
Singapore 349282
Singapore
Tel: +65.6749.1877
Fax: +65.6749.1844
2 KB
SRAM
128 bytes
SRAM
WUT
RF Transceiver
UART
8051
Debug
8051
CPU
Frame
Handler
Triac
Ctrl
Power
Mgt.
Modem
china
Interrupt
Ctrl
SPI
Ctrl
I/O Interfaces
Sigma Designs China
Unit 7C1, TianXiang Bldg.
Tian’An Cyber Zone,
Futian District,
Shenzhen, PRC
Postcode 518048
Tel: +86.755.83435669
Fax: +86.755.83435629
PWM
Triac Out
SPI
UART
Analog In
eUROPe
Z-WAVE
®
HOME CONTROL MODULE SELECTION GUIDE
Sigma Designs Denmark ApS
Emdrupvej 26 A, 1.,
2100 Copenhagen O
Denmark
Tel: +45.7020.9940
Fax: +45.7020.9950
ZM4102
779…956 MHz
64 KB OTP
16 KB
64 B
10
1
1
•
ZM3102
Frequency
Program Memory
SRAM
NVRAM
GPIO
Keyboard Scan
UARTs
SPI Ports
USB
AES Security
IR Transmitter
IR Learning
Data Rate
40 kbps
1
1
10
868.40…921.42 MHz
32 KB flash
2 KB
ZM4101
779…956 MHz
64 KB OTP
16 KB
64 B
32
128 keys
2
2
•
•
•
•
100 kbps
hOng KOng
Sigma Designs (Asia) Ltd.
Unit 4001B, Tower 2,
Metroplaza
223 Hing Fong Road
Kwai Fong, N.T. Hong Kong
Tel: +852.2401.7388
Fax: +852.2610.2177
iSRaeL, eaSTeRn eUROPe
Sigma Designs Israel
38 Habarzel St.
69710 Tel Aviv
Israel
Tel: +972.3.769.6222
Fax: +972.3.644.6253
JaPan
100 kbps
Sigma Designs Japan, KK
KDX381 Building 2F
3-8-11 Shin-Yokohama
Kohoku Yokohama Kanagawa
222-0033, Japan
Tel: +81.45.470.5877
Fax: +81.45.470.5876
TaiWan
international Sales Distributors
DigiKeY
Z-Wave Product Specialist
701 Brooks Ave. South
Thief River Falls, MN 56701
Tel: +1.800.338.4105 x 163
scott.raeker@digikey.com
Sigma Designs (Asia) Ltd.
Far East World Center,
C Tower
6F-6, No. 79, Sec 1
Hsin Tai Wu Road
Hsichih, Taipei Hsien, Taiwan
Tel: +886.2.7708.6818
Fax: +886.2.2653.2278
Features subject to change without notice. Sigma Designs, Z-Wave, the Sigma Designs logo, and the Z-Wave logo are either registered trademarks or trademarks of Sigma Designs, Inc. and its subsidiaries in the United
States and other countries. All other trademarks or registered trademarks are the property of their respective owners. Copyright © 2012 Sigma Designs, Inc. All rights reserved. Rev. 05.02.12
