Feed-through terminal block - UT 16 YE - 3044198
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Feed-through terminal block, nom. voltage: 1000 V, nominal current: 76 A, connection method: Screw
connection, number of connections: 2, cross section:1.5 mm² - 25 mm², AWG: 16 - 4, width: 12.2 mm, height:
54.4 mm, color: yellow, mounting type: NS 35/7,5, NS 35/15
Your advantages
The reducing bridges can be used to connect terminal blocks with different connection technologies, e.g., UT 35 screw terminal block with Push-
in technology 2,5 Push-in terminal blocks, to form power blocks
Easy and time-saving potential supply and distribution of large currents and cross sections up to 35 mm² with reducing bridges
The flexible options for reducing bridging in the CLIPLINE complete system can be found in "Accessories for the CLIPLINE complete modular
terminal block system"
Tested for railway applications
Key Commercial Data
Packing unit
GTIN
GTIN
4046356891226
50 pc
Technical data
General
Number of levels
Number of connections
Potentials
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Area of application
1
2
1
16 mm²
yellow
PA
V0
Railway industry
Machine building
Plant engineering
11/09/2018 Page 1 / 6
https://www.phoenixcontact.com/pi/products/3044198
Feed-through terminal block - UT 16 YE - 3044198
Technical data
General
Process industry
Rated surge voltage
Degree of pollution
Overvoltage category
Insulating material group
Maximum power dissipation for nominal condition
Maximum load current
Nominal current I
N
Nominal voltage U
N
Open side panel
Relative insulation material temperature index (Elec., UL 746 B)
Temperature index of insulation material (DIN EN 60216-1 (VDE
0304-21))
Static insulating material application in cold
Behavior in fire for rail vehicles (DIN 5510-2)
Flame test method (DIN EN 60695-11-10)
Oxygen index (DIN EN ISO 4589-2)
NF F16-101, NF F10-102 Class I
NF F16-101, NF F10-102 Class F
Surface flammability NFPA 130 (ASTM E 162)
Specific optical density of smoke NFPA 130 (ASTM E 662)
Smoke gas toxicity NFPA 130 (SMP 800C)
Calorimetric heat release NFPA 130 (ASTM E 1354)
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
8 kV
3
III
I
2.43 W
101 A (with 25 mm² conductor cross section)
76 A
1000 V
Yes
130 °C
130 °C
-60 °C
Test passed
V0
>32 %
2
2
passed
passed
passed
28 MJ/kg
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
HL 1 - HL 3
Dimensions
Width
End cover width
Length
Height
Height NS 35/7,5
Height NS 35/15
12.2 mm
2.2 mm
55.5 mm
54.4 mm
55 mm
62.5 mm
Connection data
Connection method
Connection in acc. with standard
Note
Conductor cross section solid min.
Screw connection
IEC 60947-7-1
Note: Product releases, connection cross sections and notes on
connecting aluminum cables can be found in the download area.
1.5 mm²
11/09/2018 Page 2 / 6
https://www.phoenixcontact.com/pi/products/3044198
Feed-through terminal block - UT 16 YE - 3044198
Technical data
Connection data
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Min. AWG conductor cross section, flexible
Max. AWG conductor cross section, flexible
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Tightening torque max
25 mm²
16
4
1.5 mm²
25 mm²
16
4
1 mm²
1 mm²
16 mm²
1 mm²
6 mm²
1 mm²
6 mm²
0.75 mm²
10 mm²
1 mm²
6 mm²
IEC/EN 60079-7
1.5 mm²
25 mm²
16
4
1.5 mm²
16 mm²
14 mm
A7
M5
2.5 Nm
3 Nm
Conductor cross section flexible, with ferrule without plastic sleeve max. 16 mm²
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
CUL
IEC 60947-7-1
V0
HL 1 - HL 3
HL 1 - HL 3
11/09/2018 Page 3 / 6
https://www.phoenixcontact.com/pi/products/3044198
Feed-through terminal block - UT 16 YE - 3044198
Technical data
Standards and Regulations
Fire protection for rail vehicles (DIN EN 45545-2) R24
Fire protection for rail vehicles (DIN EN 45545-2) R26
HL 1 - HL 3
HL 1 - HL 3
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Drawings
Circuit diagram
Approvals
Approvals
Approvals
PRS / UL Recognized / cUL Recognized / IECEE CB Scheme / VDE Zeichengenehmigung / EAC / EAC / cULus Recognized
Ex Approvals
IECEx / ATEX / EAC Ex
Approval details
PRS
B
600 V
85 A
16-4
http://www.prs.pl/
TE/2156/880590/17
UL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
85 A
16-4
FILE E 60425
11/09/2018 Page 4 / 6
https://www.phoenixcontact.com/pi/products/3044198
Feed-through terminal block - UT 16 YE - 3044198
Approvals
cUL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
85 A
16-4
FILE E 60425
600 V
85 A
16-4
IECEE CB Scheme
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www.iecee.org/
DE-56827
1000 V
76 A
1.5-16
VDE Zeichengenehmigung
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www2.vde.com/de/Institut/Online-Service/
VDE-gepruefteProdukte/Seiten/Online-Suche.aspx
1000 V
76 A
1.5-16
40020166
EAC
EAC-Zulassung
EAC
RU C-
DE.A*30.B.01742
cULus Recognized
11/09/2018 Page 5 / 6
