Fuse modular terminal block - UK 10,3-HESI 1500V - 3062760
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Fuse modular terminal block, Connection method: Screw connection, Cross section: 1.5 mm²- 25 mm²,
AWG: 18 - 3, Nominal current: 32 A, Nominal voltage: 1500 V, Width: 23 mm, Fuse type: gG / gPV / 10.3 x 85,
Mounting type: NS 35/7,5, NS 35/15, Color: black
Key Commercial Data
Packing unit
Minimum order quantity
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
1 pc
5 pc
96.0 g
85369085
Germany
Technical data
General
Number of levels
Number of connections
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Fuse
Rated surge voltage
Pollution degree
Overvoltage category
Insulating material group
Connection in acc. with standard
Maximum load current
Nominal current I
N
Nominal voltage U
N
1
2
25 mm²
black
PA
V0
gG / gPV / 10.3 x 85
6 kV
3
III
IIIa
IEC 60269-1/-2
32 A (the current and voltage are determined by the fuse)
32 A (the current and voltage are determined by the fuse)
1500 V (the current and voltage are determined by the fuse)
10/30/2015 Page 1 / 4
https://www.phoenixcontact.com/us/products/3062760
Fuse modular terminal block - UK 10,3-HESI 1500V - 3062760
Technical data
General
Open side panel
Shock protection test specification
Back of the hand protection
Finger protection
Temperature index, insulating material (DIN EN 60216-1 (VDE 0304-21))
nein
DIN EN 50274 (VDE 0660-514):2002-11
guaranteed
guaranteed
120 °C
Dimensions
Width
Length
Height NS 35/7,5
Height NS 35/15
23 mm
130 mm
65.5 mm
73 mm
Connection data
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule without plastic sleeve max.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, min.
2 conductors with same cross section, stranded, ferrules without plastic
sleeve, max.
1.5 mm²
25 mm²
0.75 mm²
25 mm²
18
3
1.5 mm²
16 mm²
1.5 mm²
16 mm²
1.5 mm²
4 mm²
0.75 mm²
10 mm²
1.5 mm²
4 mm²
2 conductors with same cross section, stranded, TWIN ferrules with plastic
1.5 mm²
sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with plastic
10 mm²
sleeve, max.
Connection method
Stripping length
Internal cylindrical gage
Screw thread
Tightening torque, min
Screw connection
11 mm
A7
M5
2.5 Nm
10/30/2015 Page 2 / 4
