2 mm pitch connectors
Right-angle DIP type male connector for PCBs
LPC-( )(T )ML( )
●
Configuration of product Part No.
For PCBs
Right-angle DIP
LPC- ( ) (T ) ML ( )
➀
➁
➂
➃
➀
Series name
➁
No. of contacts: 1-30
➂
Length No. of contact:
Refer to the table of dimensions below.
➃
Contact plating
Blank: Tin/Lead plating
G
: Gold plating
B
A
2
2
●
Dimensions
E
Part No.
LPC-1(T )ML( )
LPC-2(T )ML( )
LPC-3(T )ML( )
LPC-4(T )ML( )
LPC-5(T )ML( )
LPC-6(T )ML( )
LPC-7(T )ML( )
LPC-8(T )ML( )
œ0.5
LPC-9(T )ML( )
LPC-10(T )ML( )
C
LPC-11(T )ML( )
LPC-12(T )ML( )
LPC-13(T )ML( )
2
LPC-14(T )ML( )
LPC-15(T )ML( )
LPC-16(T )ML( )
LPC-17(T )ML( )
D
A
-
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
B
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
54
56
58
60
¡
™
LPC-18(T )ML( )
LPC-19(T )ML( )
LPC-20(T )ML( )
LPC-21(T )ML( )
Part No.
LPC-( )ML( )
LPC-( )T4ML( )
LPC-( )T5ML( )
LPC-( )T6ML( )
LPC-( )T8ML( )
LPC-( )T9ML( )
LPC-( )T12ML( )
LPC-( )T14ML( )
C
3
6.5
3.5
3
1.9
3
0.4
D
1
1.8
1.5
E
3
2.4
2.7
3
2
3
0.9
3
LPC-22(T )ML( )
LPC-23(T )ML( )
LPC-24(T )ML( )
LPC-25(T )ML( )
LPC-26(T )ML( )
LPC-27(T )ML( )
LPC-28(T )ML( )
LPC-29(T )ML( )
LPC-30(T )ML( )
●
Components
➀
Insulator
➁
Contacts
Because some combinations of
“Configurations of Product Part
No.”, are under consideration
for development, please contact
us for availability details.
1
Mating connectors:
LPC series of female connectors or shunt plugs
DIP
SMT
Press-in
IDC
Wire
Soldering Crimping wrapping
Others
