Maximum output power with 13 CFM forced air cooling. See derating curves for full performance details.
Combined output power of main output and fan supply shall not exceed the max power rating.
Ripple is peak to peak with 20 MHz bandwidth and 10 µF tantalum capacitor in parallel with a 0.1 µF capacitor at rated line voltage and load ranges.
Output ripple can be more than 10% of the output voltage at -40°C.
With header type output connector, VOF-350-12 max current is 18.75 A (225 W) and VOF-350-15 max current is 18 A (270 W) with 13 CFM forced air cooling.
All specifications are measured at Ta=25°C, nominal input voltage, and rated output load unless otherwise specified.
PART NUMBER KEY
VMS-350
-
XX
-
X
Base Number
Output Voltage
Output Connections:
“blank” = screw type
1 = header type
cui.com
For more information, please visit the
product page
|
If your application requires forced air, view our
Dc Fans
CUI Inc
│
SERIES:
VMS-350
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
09/05/2017
│
page
2 of 7
INPUT
parameter
voltage
frequency
current
inrush current
leakage current
touch current
power factor
no load power consumption
input fuse
6.3 A/250 V time delay fuse (included)
at full load
0.95
0.5
W
at 115 Vac, full load
at 230 Vac, full load
at 230 Vac, cold start
at 230 Vac
0.3
0.1
conditions/description
min
90
47
3.6
1.8
45
typ
max
264
63
units
Vac
Hz
A
A
A
mA
mA
OUTPUT
parameter
initial set point accuracy
line regulation
load regulation
start-up delay time
rise time
hold-up time
adjustability
switching frequency
transient response
temperature coefficient
fan output
1
Notes:
conditions/description
min
typ
±1
±0.5
max
units
%
%
%
s
ms
ms
%
from 100% to 10% load
at 115/230 Vac
at 115/230 Vac
built in trim pot
50
25% step load change, at 0.1 A/µS slew rate, 50%
duty cycle, 50/60 Hz, max excursion 4%, recovery
time 5 ms
at 0~50°C
12 Vdc / 500 mA
±0.5
2
55
8
±3
300
kHz
±0.05
%/°C
1. Fan supply output voltage tolerance including set point accuracy, line and load regulation is ±10% and ripple and noise is less than 10%.
PROTECTIONS
parameter
over voltage protection
over current protection
short circuit protection
over temperature protection
conditions/description
hiccup, auto recovery
hiccup, auto recovery
hiccup, auto recovery
goes into hiccup mode when the temperature of
the PCB exceeds 110±10°C, auto recovery
min
110
110
typ
max
140
units
%
%
SAFETY & COMPLIANCE
parameter
isolation voltage
conditions/description
input to output (2 x MOPP)
input to ground (1 x MOPP)
output to ground
IEC 60601-1: 2005 +CORR1:2006
+CORR2:2007 +AM1:2012, EN 60601-1:2006
+A11:2011 +A1:2013, ANSI/AAMI ES 60601-1
(2005+CI:09+A2:10), AMD1:2012 CAN/CSA-
C22.2 No 60601-1 (2008) 60601-1:14 ISO 14971,
2nd edition complies with LVD directive
class I
EN 55011 Class B
min
typ
4,200
1,500
1,500
max
units
Vac
Vac
Vac
safety approvals
safety class
conducted emissions
Notes:
2. The power supply is considered a component which will be installed into final equipment. The final equipment still must be tested to meet the necessary EMC directives.
cui.com
For more information, please visit the
product page
|
If your application requires forced air, view our
Dc Fans
CUI Inc
│
SERIES:
VMS-350
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
09/05/2017
│
page
3 of 7
SAFETY & COMPLIANCE
parameter
radiated emissions
input current harmonics
voltage fluctuation and flicker
ESD immunity
radiated field immunity
electrical fast transient
immunity
surge immunity
conducted immunity
magnetic field immunity
voltage dips, interruptions
MTBF
RoHS
Notes:
conditions/description
min
typ
max
units
EN 55011 Class B (to be controlled in end system with external
core (King core K5B RC 25 x 12 x 15-M in input cable (5 turns))
EN 61000-3-2, class D
EN 61000-3-3, pass
EN 61000-4-2, level 4, criterion A
EN 61000-4-3, level 4, criterion A
EN 61000-4-4, level 4, criterion A
EN 61000-4-5, level 4, criterion A
EN 61000-4-6, level 4, criterion A
EN 61000-4-8, level 4, criterion A
EN 61000-4-11, criterion B
as per Telcordia-SR332-issue 3
2011/65/EU
3,370,000
hours
1. The power supply is considered a component which will be installed into final equipment. The final equipment still must be tested to meet the necessary EMC directives.
ENVIRONMENTAL
parameter
operating temperature
storage temperature
operating humidity
storage humidity
operating altitude
non-condensing
non-condensing
conditions/description
see derating curves
min
-40
-40
20
20
typ
max
70
85
90
90
16,000
units
°C
°C
%
%
ft
DERATING CURVES
Output Power vs. Input Voltage
12 Vdc Output Model
Output Power vs. Ambient Temperature
300
275
250
Output Power (W)
225
200
175
150
125
100
75
50
25
0
-40 -30 -20 -10 0 10 20 30 40 50
Ambient Temperature (°C)
Header Type Forced Air (13 CFM)
Natural Convection
Screw Type Forced Air (13 CFM)
100
90
Output Power (%)
80
70
60
50
40
30
20
10
0
90
95 100 105 110 115 120 125 255 260 264
Input Voltage (Vac)
60
70
cui.com
For more information, please visit the
product page
|
If your application requires forced air, view our
Dc Fans
CUI Inc
│
SERIES:
VMS-350
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
09/05/2017
│
page
4 of 7
DERATING CURVES (CONTINUED)
15 Vdc Output Model
Output Power vs. Ambient Temperature
325
300
275
250
Output Power (W)
225
200
175
150
125
100
75
50
25
0
-40 -30 -20 -10 0 10 20 30 40
Ambient Temperature (°C)
Natural Convection
Header Type Forced Air (13 CFM)
Output Power (W)
All other Output Models
Output Power vs. Ambient Temperature
350
325
300
275
250
225
200
175
150
125
100
75
50
25
0
-40 -30 -20 -10 0 10 20 30 40
Ambient Temperature (°C)
Natural Convection
Forced Air (13 CFM)
Screw Type Forced Air (13 CFM)
50
60
70
50
60
70
cui.com
For more information, please visit the
product page
|
If your application requires forced air, view our
Dc Fans
CUI Inc
│
SERIES:
VMS-350
│
DESCRIPTION:
AC-DC POWER SUPPLY
date
09/05/2017
│
page
5 of 7
MECHANICAL
parameter
dimensions
weight
cooling
J1 input connector
J2 output connector
J3 fan connector
external fan
Mates with JST housing VHR-3M; pins SVH-41T-P1.1 or equivalent
Screw Type: Accepts ring tongue terminal AMP 8-31886-1 for max 16 AWG wire up to 11 A. Use
multiple terminals for higher currents.
Header Type: Mates with JST housing VHR-8M; pins SVH-41T-P1.1 or equivalent
京公网安备 11010802033920号
