LE-0903-04W datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> LE-0903-04W

LE-0903-04W: Description3 LED WEDGE BASE LAMP WHT; CategoryLED optoelectronic/LED; File Size72KB，1 Pages; ManufacturerJKL Components Corporation; Environmental Compliance

Download Datasheet Parametric View All

LE-0903-04W Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	LE-0903-04W	-	-	View	Buy Now

LE-0903-04W Overview

3 LED WEDGE BASE LAMP WHT

LE-0903-04W Parametric

Parameter Name	Attribute value
Replaceable lamp	-
size/dimensions	0.409" diameter x 0.799" height (10.40mm x 20.30mm)
wavelength	6800K
Voltage - Forward (Vf) (Typical)	24V
Substrate type	Wedge
color	white, cool color
millicandela level	-
Configuration	single
application	-

Preview

Download Datasheet

View All

[3] Ø3.0mm REF.

(.12") LEDS

Ø10.4±3mm

(.40±.12")

12.3±5mm

(48±.20")

20.3±5mm

(.80±.20")

COLORED LEAD IS "

COPPER OR RED

9.0±3mm

(.35±.12")

TYPICAL ELECTRICAL & OPTICAL OPERATING CHARACTERISTICS

(Ta = 25 degree C)

PART

NUMBER

LE-0903-04W

EMITTING

COLOR

WHITE

AMPERAGE VOLTAGE

Vdc

24.0

LUMINOUS

INTENSITY Lm

CRI

CCT

DEGREE K

6800

VIEWING ANGLE

DEGREES

120

JKL PART NO.: LE-0903-04W

METRIC

THIRD ANGLE

PROJECTION

DRAWN BY

DIMENSIONS ARE IN

MILLIMETERS (INCH)

TOLERANCE UNLESS

OTHERWISE SPECIFIED

TITLE

COMPONENTS CORPORATION

REV.

NO.

CHANGE POLARITY NOTE

CHANGE TITLE

RELEASED

DESCRIPTION/ECO

NUMBER

4/30/16

2/2/15

12/1/09

APPV'D

DATE

1 PL +/-

2 PL +/-

ANGLE +/-

REF.

T-3 1/4 LOW PROFILE WEDGE BASE LAMP

SIZE

SCALE

APPV'D BY

DATE

L. WENGSTROM L.R.

4/30/16

MANUAL REVISIONS NOT PERMITTED

- CAD DRAWING -

55335

NONE

FSCM NO.

DRAWING

NO.

RELEASED

DATE

LE-0903-04W

12/1/09

REVISION

DATE

4/30/16

REV.

NO.

SHEET
