Power Inductors - Shielded
ctparts.com
CTCDRH74 Series
From 10 µH to 1,000 µH
Part
Number
SPECIFICATIONS
Please specify tolerance code when ordering.
CTCDRH74-100_
J = ±5%, K = ±10% L = ±15%
M = ±20%, N = ±30%
CTCDRH74F
Please specify “F” for RoHS Compliant
Inductance
(µH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
L Test
Freq.
(kHz)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
DCR
Max.
Ω
(Ω)
.05
.06
.08
.09
.11
.15
.17
.23
.26
.35
.38
.43
.61
.66
.88
.98
1.2
1.6
1.9
2.9
3.0
3.6
4.6
5.2
6.0
IDC
Max.
(A)
1.9
1.7
1.5
1.3
1.2
1.1
.96
.91
.88
.75
.69
.61
.60
.52
.46
.42
.36
.34
.32
.29
.26
.23
.22
.20
.18
ENGINEERING KIT #24F
Not shown at actual size.
Compliant
Available
RoHS
CTCDRH74_-100_
CTCDRH74_-120_
CTCDRH74_-150_
CTCDRH74_-180_
CTCDRH74_-220_
CTCDRH74_-270_
CTCDRH74_-330_
CTCDRH74_-390_
CTCDRH74_-470_
CTCDRH74_-560_
CTCDRH74_-680_
CTCDRH74_-820_
CTCDRH74_-101_
CTCDRH74_-121_
CTCDRH74_-151_
CTCDRH74_-181_
CTCDRH74_-221_
CTCDRH74_-271_
CTCDRH74_-331_
CTCDRH74_-391_
CTCDRH74_-471_
CTCDRH74_-561_
CTCDRH74_-681_
CTCDRH74_-821_
CTCDRH74_-102_
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
Power supplies for VTR, OA equipment, LCD
televisions, PC notebooks, portable communication equipment,
DC/DC converters, etc.
Operating Temperature:
-25°C to +80°C
Inductance Tolerance:
±5%, ±10%, ±15%, ±20%, ±30%
Testing:
Inductance is tested on an HP4284A at 1.0 kHz
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant available.
Magnetically shielded
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
7.3±0.5
0.3±0.02
B
7.3±0.5
0.3±0.02
C
Max.
4.5
0.18
D
1.8±0.5
0.07±0.02
E
5.4±0.5
0.21±0.02
F
7.2±0.5
0.28±0.02
05.19.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
