ELECTRIC DOUBLE LAYER CAPACITORS “DYNACAP”
ELECTRIC DOUBLE LAYER CAPACITORS “DYNACAP”
GREEN
CAP
70˚C
Low ESR
φD＋0.5max.
φD＋1max.
F±0.5
Markings
L＋αmax.
15min.
5
min.
L＋2max.
Vent
6.3±1
φD
F
φd
α
6.3
2.5
8
10 12.5
3.5
5.0
0.6
2.0
16
7.5
0.8
18
(‒) Negative terminal
indicated by cross notching
Position of printed
circuit board holes
2.1
Part numbering system (example : 2.5V10F)
DZN
Series code
̶
2R5
Max. operating voltage
symbol
D
Terminal
code
106
Rated capacitance
symbol
(Z6)(S)
Casing
symbol
T ̶
Taping (Forming)
symbol
Part number is refer to the following page.
CAT.No.2015/2016E
214
NOTE : Design, Specifications are subject to change without notice.
It is recommended that you shall obtain technical specifications
from ELNA to ensure that the component is suitable for your use.
7.5
1.5±0.1
6.8
2.6
UPGRADE
EDLC
®
®
High Power Type Capacitors
2.5V
2.7V
Low internal resistance allows boosting charge and heavy-current discharge.
(ampere level)
Pollution-Free ; with no pollutants such as Cd or Pb.
High power
Unlike batteries, excellent charge and
discharge characteristics with no chemical
DZN
DZ
reaction
Marking color : White print on a blue sleeve
Specifications
Item
Category temperature range (℃)
Tolerance at rated capacitance (%)
Performance
ー25 to ＋70
ー20 to ＋80
Refer to the following page
Internal resistance
at 1 kHz
Characteristics at high
and low temperature
Percentage of capacitance change
Internal resistance
Test time
Within
±
30% of the value at 20
℃
Less than five times of the value at 20
℃
1000 hours
Within
±
30% of the initial measured value
Less than four times of the initial specified value
Test time : 1000 hours ; Same as endurance.
Conforms to JIS C5160-1 2009 (IEC 62391-1 2006)
Unit : mm
Endurance (70℃)
Percentage of capacitance change
Internal resistance
Shelf life (70℃)
Applicable standards
Outline Drawing
φ6.3 to φ18
Vent
Sleeve
φd±0.05
copper clad steel wire (tinned)
φ25, 35
Sleeve
2‒φ2
Lug terminal details
0.9±0.1 Thickness : 0.8t
10
10
0.
±
1
®
ELECTRIC DOUBLE LAYER CAPACITORS “DYNACAP”
ELNA Parts No.
DZN-2R5D105F4T
DZN-2R5D105G3T
DZN-2R5D275G5ST
DZN-2R5D335H5T
DZN-2R5D475H5T
DZN-2R5D565H5T
DZN-2R5D685H6T
DZN-2R5D106H8T
DZN-2R5D106Z6ST
DZN-2R5D156Z8ST
DZN-2R5D156J5T
DZN-2R5D226J6T
DZN-2R5D336J8T
DZN-2R5D406K9T
DZN-2R5D506T
DZN-2R5D107S37T
DZN-2R5D207S57T
φD×L (mm)
6.3×14
8×12
8×20
10×20
10×20
10×20
10×25
10×35
12.5×25
12.5×35
16×20
16×25
16×35.5
18×40
25×40
25×50
35×50
Internal resistance
(Ω max.) at 1kHz
Standard Ratings (Series DZN 2.5V)
Max. operating voltage (V) Rated capacitance (F)
Max. Leakage Current (mA) after 24h
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
1
1
2.7
3.3
4.7
5.6
6.8
10
10
15
15
22
33
40
50
100
200
0.1
0.1
0.2
0.2
0.3
0.3
0.4
0.5
0.5
0.7
0.7
0.8
0.8
0.8
1.0
1.0
2.0
0.4
0.3
0.3
0.2
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.03
0.03
0.03
DZN
Internal resistance (mΩ max.)
(DCR)
UPGRADE
1500
1000
500
350
400
350
300
200
200
150
150
120
100
75
60
50
40
We tailor packaged product in series and parallel arrangements according to voltage and capacitance as required.
Standard Ratings (Series DZN 2.7V)
Max. operating voltage (V) Rated capacitance (F)
Max. Leakage Current (mA) after 24h
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
2.7
1
1
2.7
3.3
4.7
5.6
6.8
10
10
15
15
22
33
0.2
0.2
0.3
0.3
0.4
0.4
0.5
0.6
0.6
0.8
0.8
1.0
1.0
ELNA Parts No.
DZN-2R
7
D105F4T
DZN-2R
7
D105G3T
DZN-2R7D275G5ST
DZN-2R7D335H5T
DZN-2R7D475H5T
DZN-2R7D565H5T
DZN-2R7D685H6T
DZN-2R7D106H8T
DZN-2R7D106Z6ST
DZN-2R7D156Z8ST
DZN-2R7D156J6T
DZN-2R7D226J7T
DZN-2R7D336J9T
φD×L (mm)
6.3×14
8×12
8×20
10×20
10×20
10×20
10×25
10×35
12.5×25
12.5×35
16×25
16×31.5
16×40
Internal resistance
(Ω max.) at 1kHz
Internal resistance (mΩ max.)
(DCR)
0.4
0.3
0.3
0.2
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
1500
1000
500
350
400
350
300
200
200
150
150
120
100
We tailor packaged product in series and parallel arrangements according to voltage and capacitance as required.
EDLC
NOTE : Design, Specifications are subject to change without notice.
It is recommended that you shall obtain technical specifications
from ELNA to ensure that the component is suitable for your use.
215
CAT.No.2015/2016E
