Abracon ASxxx Series of
High Performance MEMS Differential Clock Oscillator
Features
ASxxx Series of devices are miniature MEMS based, PLL clock oscillators optimized to meet the requirements of high
speed serial data communication channels. These differential devices are available in single and dual output formats
including CMOS, LV-PECL, LVDS, and HCSL.
What the ASxxx can do for your design…..
• Devices are available in standard pin-pin compatible
[7.0 x5.0mm], [5.0x3.2mm], [3.2x2.5mm], and
[2.5x2.0mm] footprints.
• Devices are Lead Free & RoHS compliant.
• Jitter optimized for high speed serial data formats.
• High Reliability, with 20 times better MTTF than
quartz oscillators
• Devices operate from +2.5, to +3.6 Volt supplies
• -40 to +85C operating temperature range, and
extended Automotive Grade temperature stability at
-55 to +125°C, ±25ppm
• Multiple output formats: CMOS, LVPECL, LVDS,
HCSL, including Dual Output configurations.
• High Stability with ± 10ppm, ±25ppm, ±50 ppm
available.
• Short lead Time: 2 weeks
• Shock & Vibration Immunity MIL-STD-883
• 50 dBc Power Supply Rejection Ratio
• Field programmable production devices are available
The ASxxx series saves PCB area. Combine a small device
footprint and minimal external components to get the
smallest solution footprint.
The ASxxx series is optimized to exceed Jitter requirements
of high speed serial data formats. Integrated jitter 100KHz
-20MHz < 400fs, and 200KHz – 20 MHz < 300 fs.
ASxxx series is more cost efficient vs. quartz competitors.
As device dimensions shrink, quartz resonator costs
increase. The 0.2 mm2 MEMS device cost decreases with
package size.
Quartz in Ceramic
MEMS in Plastic
7.0 x 5.0
5.0 x 3.2
3.2 x 2.5
2.5 x 2.0
2.0 x 1.6
1.6 x 1.2
Highly reliability designs such as Enterprise SSD Memory
cannot meet their performance targets without highly reliable
components such as the ASxxx clock oscillators.
http://www.eetimes.com/design/memory-design/4412418/W
hy-flash-storage-needs-MEMS
MEMS Part Number / Key Performance list
Applications
Storage Area Networks
» SATA, SAS, Fibre Channel, PCIe
Passive Optical Networks
» EPON, 10G-EPON, GPON, 10G-PON
Ethernet
» 1G, 10GBASE-T/KR/LR/SR, FCoE
Video
» HD, SD, SDI
Supply Voltage: 2.25V to 3.6 V
Package Sizes: ASVMP (7.0 x 5.0 x 0.85mm, ASFLMP 5.0 x 3.2 x 0.85 mm
ASDMP 2.5 x 2.0 x 0.85mm & All others 3.2 x 2.5 x 0.85 mm
Part
Differential
Supply
Frequency
Integrated
Stability
Number
Output Type
Current
Range
Phase Jitter
(J
PH)
Typically,
ASEMCLP LVPECL
56.5mA typ
< 400fs
/
ASEMCLV LVDS
29mA typ
~ 10 – 460MHz
+/-10ppm
(100KHz –
ASEMCHC HCSL
40mA typ
over -40 /
20MHz)
ASEMDHC Dual HCSL
60mA typ
85C
ASEMDLP Dual LVPECL 89mA typ
and
ASEMDLV Dual LVDS
89mA typ
< 300fs
/
ASEMP
CMOS,
31mA typ
(200KHz –
LVPECL,
51mA typ
CMOS
20MHz
LVDS,
29mA typ
~ 10 – 170MHz
HCSL
40mA typ
+/-10ppm
(Typical Ref
over
LVPECL /
156MHz clock
ASDMP
CMOS,
31mA typ
-20/70C
LVDS / HCSL
o/p)
LVPECL,
56.5mA typ
~ 10 – 460MHz
LVDS,
29mA typ
and
HCSL
40mA typ
ASFLMP
CMOS,
LVPECL,
LVDS,
HCSL
CMOS,
LVPECL,
LVDS,
HCSL
31mA typ
51mA typ
29mA typ
40mA typ
31mA typ
51mA typ
29mA typ
40mA typ
CMOS
~ 10 – 170MHz
LVPECL /
LVDS / HCSL
~ 10 – 425MHz
ABRACON DIFFERENTIAL MEMS
(100KHz –
20MHz)
Typically,
< 550fs
/
+/-50ppm
over -55/
+125C
ASVMP
Application Output Configurations
V
DD
V
DD
V
DD
< 350fs
/
(200KHz –
20MHz
and
V
DD
130
Ω
V
DD
0.1uF
0.1uF
2
130
Ω
6
5
4
0.1uF
0.1uF
6
Rs = 0
Ω
for test
Rs
100
Ω
Rs
6
2
3
5
4
3
100
Ω
6
2
82
Ω
82
Ω
2
3
5
4
5
4
3
100
Ω
100
Ω
C
L
CMOS load
capacitance
Rs serves to match the trace
50
Ω
impedances. Depending on
board layout, the value may
range from 0 to 30 ohms.
50
Ω
Links and Resources- MEMS data sheets:
http://www.abracon.com/oscillators.htm#memsoscoscillators.htm#memsosc:
Tel:001.949.546.8000
