78163 SL005 datasheet, PDF - EEWORLD Datasheet

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 78163

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

(1) Color Code

Pair

1

c) Pair

(1) Twists:

2) Cable Assembly

a) Twists:

b) Orientation:

c) Core Wrap

3) Shield:

a) Foil Direction

b) Drain Wire

4) Jacket

a) Color(s)

b) Ripcord

Color

WHITE-BLACK

3 X 1 PAIR

26 (19/38) AWG Tinned Copper

0.007" Wall, Nom. Modified Polyphenylene

Ether-PE

Alpha Wire Color Code B

Pair

2

Color

WHITE-BROWN

Pair

3

Color

WHITE-RED

0.020

0.034

2/Cond Cabled Together

12.0 Twists/foot (min)

3 Components Cabled

6.9 Twists/foot (min)

Components to be arranged from INSIDE

LAYER to OUTSIDE LAYER

Nonwoven Polyester Tape, 25% Overlap, Min.

Alum/Mylar Tape, 25% Overlap, Min.

Foil Facing In

26 (7/34) AWG Tinned Copper

0.015" Wall, Nom.,Modified Polyphenylene

Ether-PE

SLATE

1 End 810 Denier Nylon

ALPHA WIRE-* P/N 78163 3PR 26 AWG

ECOCABLE(R) MINI RU AWM 21460 80C 300V VW-1

C(RU) AWM I A/B FT1 80C 300V

CE ROHS (SEQ FOOTAGE)

* = Factory Code

0.158 (0.169 Max.)

c) Print

Applicable Specifications

1) UL

AWM/STYLE 21460

VW-1

2) CSA International

3) Other

C(RU) AWM I A/B FT1

Halogen-Free

NFPA 79 - 2015 Compliant

4) CE:

EU Low Voltage Directive 2014/35/EC

80°C / 300 VRMS

Environmental

1) CE: EU Directive 2011/65/EU(RoHS2):

This product complies with European Directive 2011/65/EU (RoHS Directive) of the European

Parliament and of the Council of 8 June 2011and the amending Directive 2015/863/EU of 4 June

2015 . No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web

site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

Electrical Properties

1) Voltage Rating

2) Mutual Capacitance

3) Ground Capacitance

4) Characteristic Impedance

5) Inductance

6) Conductor DCR

7) OA Shield DCR

-40 to 80°C

10X Cable Diameter

16.5 Lbs, Maximum

(For Engineering purposes only)

300 VRMS

20.3 pF/ft @1 kHz, Nominal

37 pF/ft @1 kHz, Nominal

81 Ω

0.18 µH/ft, Nominal

38 Ω/1000ft @20°C, Nominal

20.8 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 100 FT

c) Bulk(Made-to-order)

Flange x Traverse x Barrel (inches)

12 x 4.5 x 3.5 Continuous length

6.5 x 2 x 1.9 Continuous length

[Spool dimensions may vary slightly]

www.alphawire.com

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742)

Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications

described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not

ensure product availability.

Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or

implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,

even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out

of or in connection with the use, or inability to use, the information or specifications described herein.

ALPHA WIRE - CONFIDENTIAL AND PROPRIETARY

Notice to persons receiving this document and/or technical information. This document is confidential and is the exclusive property of ALPHA WIRE,

and is merely on loan and subject to recall by ALPHA WIRE at any time. By taking possession of this document, the recipient acknowledges and

agrees that this document cannot be used in any manner adverse to the interests of ALPHA WIRE, and that no portion of this document may be

copied or otherwise reproduced without the prior written consent of ALPHA WIRE. In the case of conflicting contractual provisions, this notice shall

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: 78163

78163 , RoHS-Compliant Commencing With 7/22/2014 Production

Note: all colors and put-ups

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive (commonly known as RoHS 2), with regards to restrictions of the use of certain hazardous

substances used in the manufacture of electrical and electronic equipment. This certification extends to amending Directive 2015/863/EU which

expanded the list of restricted substances to 10 items (commonly known as RoHS 3) The reader is referred to these Directives for the specific

definitions and extents of the Directives. No Exemptions are required for RoHS Compliance on this item. Additionally, Alpha certifies that the listed

part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-2014.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

Bis(2-ethylhexyl) phthalate (DEHP)

Butyl benzyl phthalate (BBP)

Dibutyl phthalate (DBP)

Diisobutyl phthalate (DIBP)

0.1% by weight (1000 ppm)

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire:

Dave Watson, Director of Engineering & QA

Alpha Wire

711 Lidgerwood Ave.

Elizabeth, NJ 07207

Tel: 1-908-925-8000

11/7/2018

Parameter Name	Attribute value
Cable type	Multiple pairs
Number of conductors	6 (3 twisted pairs)
Wire gauge	26 AWG
Number of wire strands	19/38
conductor material	Copper, tin plated
Sheath (insulation) material	Polyphenylene ether, modified (mPPE)
Sheath (insulation) diameter	0.158"（4.01mm）
Shield type	foil
length	100.0'（30.5m）
Casing color	slate color
grade	ISO 10993, UL type 21460
characteristic	Biocompatible, drain wire, drawstring
Voltage	300V
Operating temperature	-40°C ~ 80°C
use	-
Sheath (insulation) thickness	0.0150"（0.381mm）
conductor insulation	Polyphenylene ether, modified (mPPE)
shielding material	aluminum
Shielding range	100%
