Bluetooth
®
AT Data Module
BTM410/411
The BTM410 and BTM411 Bluetooth
®
modules from Laird have been designed to meet the
needs of developers who wish to add robust, short range Bluetooth data connectivity to
their products. They are based on the market leading Cambridge Silicon Radio BC04
chipset, providing exceptionally low power consumption with outstanding range. They
support the latest Bluetooth Version 2.1 Specification, providing the important advantage of
Secure Simple Pairing, which improves security and enhances the ease of use for end
customers.
With a footprint as small as 12.5 mm x 18.0 mm for the BTM410 and best of class, low-
power operation, these modules are the ideal choice for applications where designers need
both performance and minimum size. For maximum flexibility in systems integration, the
modules are designed to support a separate power supply for I/O.
To aid product development and integration, Laird has integrated a complete Bluetooth
protocol stack within the modules, including support for the Bluetooth Serial Port Profile.
The modules are fully qualified as Bluetooth End Products, allowing designers to integrate
them within their own products with no further Bluetooth Qualification.
A comprehensive AT command interface is included, which simplifies firmware integration.
Combined with a low cost developer’s kit, this ensures that choosing Laird Bluetooth
modules guarantees the fastest route to market.
Features and Benefits
Bluetooth v2.1+EDR
Adaptive frequency hopping to cope with
interference from other wireless devices
Secure Simple Pairing support
External or internal antenna options
Comprehensive AT interface for simple
programming
Bluetooth End Product Qualified
Compact size
Class 2 output – 4 dBm
Low power operation
UART interface
PCM and SCO for external codec
GPIO lines under AT control
Wi-Fi co-existence
Application Areas
Embedded devices
Phone accessories
Security devices
Medical and telehealth devices
Aftermarket automotive
applications
Bluetooth advertising
ePOS
USA: +1.800.492.2320
Europe: +44.1628.858.940
Asia: +852.2923.0610
wirelessinfo@lairdtech.com
www.lairdtech.com/wireless
Bluetooth
®
AT Data Module
BTM410/411
CATEGORIES
Wireless Specification
FEATURE
Bluetooth®
Frequency
Max Transmit Power
IMPLEMENTATION
Version 2.1+EDR
2.402 – 2.480 GHz
Class 2
+4 dBm (at antenna pad – BTM410)
+4 dBm (from integrated antenna – BTM411)
Better than -84 dBm
Up to 30 meters
Up to 2.1 Mbps (over the air)
Greater than 300 Kbps
Supports CTS, RTS, DRT, DSR, DCD and RI
8 lines (shared)
SPP – Serial Port Profile
Voice over SCO via a PCM interface
3.0 V to +3.3 V
1.7 V to +3.6 V (independent of VCC
Less than 40 mA during SCO transmission
Idle (sleep) < 1 mA
2 wire and 3 wire schemes supported
Connection via SMT pad – BTM410
Multilayer ceramic – BTM411
AT Command Set
12.5 mm x 18.0 mm x 3.4 mm (external antenna – BTM410)
12.5 mm x 22.0mm x 3.4 mm (integrated antenna – BTM411)
-40° C to +85° C
-40° C to +85° C
Lead-free and RoHS compliant
1-Year Warranty
Development board and software tools
End Product Approved
BTM410 – Limited Modular Approval
BTM411 – Full Modular Approval
Host Interface
User Interface
Profiles
Supply Voltage
Power Consumption
Coexistence / Compatibility
Connections
Protocols
Physical
Environmental
Miscellaneous
Developmental Tools
Approvals
Receive Sensitivity
Range
Data Rates
UART Data Transfer Rate
UART
GPIO
Supply
I/O
Current Consumption
802.11 (Wi-Fi)
External Antenna
Internal Antenna
Dimensions
Operating Temperature
Storage Temperature
Lead Free
Warranty
Development Kit
Bluetooth
FCC/IC & CE
Ordering Information
BTM410
BTM411
DVK-BTM410
DVK-BTM411
Bluetooth AT Data Module (external antenna)
Bluetooth AT Data Module (with integrated antenna)
Development Kit (external antenna)
Development Kit (with integrated antenna)
The details contained within the document are subject to change. Download the product specification from
www.lairdtech.com/wireless
for the most current specification.
CONN-DS-BTM410-411 v1.0
