Skywire
®
M1 Development Kit
User Manual
NimbeLink Corp
Updated: August 2018
PN 30192 rev 10
© NimbeLink Corp. 2018. All rights reserved.
1
Table of Contents
Introduction
Overview
Orderable Parts
Firmware Changes
Archive of Critical Engineering Sample Notes
Engineering Sample
Modem Firmware
AT Commands - Addressed in firmware 32902
Lower Power Modes - Available in firmware 32902
SMS Messaging - Available in firmware 32902
Supported LTE Bands
"Assertion failed" Errors - Fixed in firmware 32902
Real-Time Clock Error - Fixed in firmware 32902
Command Mode Socket Dials - Hex - Fixed in firmware 32902
AT Interface Lockup Issues - Fixed in firmware 32902
Network Registration Issues - Fixed in firmware 32902
SIM Cards
Getting Started
Kit Contents
Hardware Setup
SIM Card Installation
Skywire Installation
Jumper Installation
Antenna Installation
Software Setup
Terminal Program
Baudrate
Activate LTE CAT M1 SIM Data plan
Hardware Verification
Introduction
Insert USB Cable
Apply Power
Verify COM Port Enumeration
Connect to the Skywire
3
3
4
4
5
5
5
5
5
5
5
6
6
6
6
6
7
7
7
8
8
9
10
10
11
12
12
12
13
13
13
13
14
14
PN 30192 rev 10
© NimbeLink Corp. 2018. All rights reserved.
2
AT Commands
Verify AT Command Communications
Enable Command Echo
Check Firmware Version
Set Your APN
Enable Cellular Functionality
Verify Auto-Attach
Verify Cellular Signal Strength
Verify Network Registration
Next Steps
Additional Resources
Troubleshooting
Introduction
Communications with the Skywire
Serial Communications on macOS
Network Registration
Technical Support
15
16
16
16
17
17
18
18
20
20
21
21
22
22
22
23
23
PN 30192 rev 10
© NimbeLink Corp. 2018. All rights reserved.
3
1. Introduction
1.1 Overview
This document is the User Manual for the NL-M1DK, NL-SW-LTE-SVZM20-ES,
and NL-SW-LTE-SVZM20 family of Skywire® modems. The procedure outlined in
this guide walks through installing the Skywire modem, setting up your
workstation, issuing basic commands, and registering on the Verizon network.
1.2 Orderable Parts
Table 1.1 Orderable Parts
Number
Description
Firmware
Manufacturer
Carrier
NL-M1DK
NL-SW-LTE-SVZM20-ES
NL-SW-LTE-SVZM20
NL-SW-LTE-SVZM20-B
NL-SIM-VER-M1
TG.30.8113
TG.08.0113
Skywire 4G LTE CAT M1
Development Kit
Skywire 4G LTE CAT M1
Cellular Modem
Skywire 4G LTE CAT M1
Cellular Modem
Skywire 4G LTE CAT M1
Cellular Modem
3FF Verizon LTE CAT M1 Sim
Card
Dipole Cellular Antenna
Monopole Cellular Antenna
NimbeLink
30850
32110
37120
NimbeLink
NimbeLink
NimbeLink
NimbeLink
Taoglas
Taoglas
Verizon
Verizon
Verizon
Verizon
Verizon
1.3 Firmware Changes
The chipset manufacturer has released a new version of firmware - firmware version
37120 - that makes available some features and fixes many issues. Here is a brief
description of the firmware changes:
-
More AT command are enabled and functioning. We have an AT command
manual available on our website:
http://nimbelink.com/Documentation/Skywire/4G_LTE_Cat_M1/1001534_NL-SW-
LTE-SVZM_AT_COMMAND_MANUAL.pdf
-
Low power modes are enabled, and an application note explaining the process is
located here:
https://nimbelink.com/https://nimbelink.com/skywire-4g-lte-cat-m1/1001779_NL-S
W-LTE-SVZM20_LowPowerAppNote.pdf
-
-
-
Bug fixes and lockup fixes
Addition of a client to communicate with Verizon Thingspace
The USB port can now be used as an AT command port.
PN 30192 rev 10
© NimbeLink Corp. 2018. All rights reserved.
4
For more information, please see the Product Change Notification for the
NL-SW-LTE-SVZM20:
https://nimbelink.com/Documentation/Skywire/4G_LTE_Cat_M1/1001767_NL-SW-LTE-
SVZM20-X_PCN.pdf
There are still outstanding notes from Section 1.4, as well as an additional issue, to
keep in mind:
-
-
-
-
CATM1 still only uses Band 13
CATM1 devices still require a CAT-M1 SIM card.
CATM1 SMS is still only between CATM1 devices.
The Sequans VZM20 module will default to an AT+CFUN=1 mode at boot. If no
SIM card is installed, it may cause the module to continuously reboot.
Additionally, a firmware update procedure may fail. For more information, please
see document 1001810 Device Errata Skywire NL-SW-LTE-SVMZ20 Modem:
https://nimbelink.com/Documentation/Skywire/4G_LTE_Cat_M1/1001xxx_NL-SW
-LTE-SVZM20_Errata.pdf
1.4 Archive of Critical Engineering Sample Notes
1.4.1 Engineering Sample
The NL-M1DK-ES are Engineering Sample products. This means that there is
some functionality not enabled yet, and there will be numerous software and
firmware changed and updates in the near future as these features mature.
1.4.2 Modem Firmware
The firmware in the modem may have some limited functionality, but you will
need to update the firmware as part of the out-of-the-box experience.
1.4.3 AT Commands - Addressed in firmware 32902
Not all AT commands listed in the AT Commands Manual are enabled. The
associated Application Notes will reference commands and sequences that are
available at the time of writing and known to be working. If you receive an
ERROR response when trying to use one of the commands not listed in an
Application Note, you can expect that the implementation is not complete for that
feature.
1.4.4 Lower Power Modes - Available in firmware 32902
We do not advise performing any advanced power testing at this time. Low
power modes (and power-save modes) are not available in current firmware so
results are not representative of the product’s true capabilities yet.
1.4.5 SMS Messaging - Available in firmware 32902
SMS messages are not available at this time.
PN 30192 rev 10
© NimbeLink Corp. 2018. All rights reserved.
5
