Single-Output LDO Regulators
30V Voltage Resistance
0.1A LDO Regulators
BDxxFA1FP3 series
●General
Description
BDxxFA1FP3 series are LDO regulators with output current capability of 0.1A. The output voltages are 3.3V, 5.0V, 5.4V,
and 12.0V with ±1% accuracy. The SOT89-3K package is most suitable for heat dissipation. As protective function to
prevent IC from destruction, this chip has built-in over current protection circuit to protect the device when output is shorted,
and built-in thermal shutdown circuit to protect the IC during thermal over load conditions. This product can be used in
wide variety of digital appliances. These regulators can use ceramic capacitor, which have smaller size and longer life than
other capacitors.
●Package
SOT89-3K
W(Typ) D(Typ)
H(Max)
4.50mm x 4.095mm x 1.60mm
●Features
High accuracy output voltage
±1.0%
Built-in Over current protection circuit (OCP)
Built-in Temperature protection circuit (TSD)
Soft start function
●Key
Features
Input power supply voltage range: Vo+3.0V to 25.0V
Output voltage:
3.3V, 5.0V, 5.4V, 12.0V
Output current:
0.1A (Max)
Operating temperature range:
Ta= -25°C to +85°C
●Typical
Application Circuit
V
CC
C
IN
V
O
C
OUT
GND
FIN
C
IN
,C
OUT
: Ceramic Capacitor
●Ordering
Information
B
Part
Number
D
x
x
F
A
1
F
Package
P
3
-
Z
T
L
Output voltage Input
Output
Voltage Current
33: 3.3V
50: 5.0V
F:30V A1:0.1A
54: 5.4V
J2: 12V
Manufacturing Packaging and forming
Code
specification
TL : Emboss tape reel
FP3:SOT89-3K
○
Product structure : Silicon monolithic integrated circuit
www.rohm.com
© 2016 ROHM Co., Ltd. All rights reserved.
TSZ22111½14½001
○This
product is not designed to have protection against radioactive rays.
1/14
TSZ02201-0G2G0A600060-1-2
11.Apr.2016 Rev.004
BDxxFA1FP3
●Block
Diagram
Datasheet
V
CC
OCP
SOFT
START
V
O
TSD
GND
Figure. 1 Block Diagram
●Pin
Configuration
SOT89-3K
(TOP VIEW)
FIN
reverse
1
2
3
V
O
GND V
CC
●Pin
Description
Pin No.
1
2
3
reverse
Pin name
Vo
GND
Vcc
FIN
Pin Function
Output pin
GND pin
Input pin
GND (Connected to 2pin)
www.rohm.com
© 2016 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
2/14
TSZ02201-0G2G0A600060-1-2
11.Apr.2016 Rev.004
BDxxFA1FP3
●Absolute
Maximum Ratings (Ta=25°C)
Parameter
Power supply voltage
Output voltage
Power dissipation
SOT89-3K
Operating temperature range
Storage temperature range
Maximum junction temperature
Symbol
V
CC
Vo
Pd*
2
Ta
Tstg
Tjmax
Limits
-0.3 to +30.0 *
-0.3 to +18
1.67 *
2
-25 to +85
-55 to +150
+150
1
Datasheet
Unit
V
V
W
°C
°C
°C
*1 Not to exceed Pd.
*2 In case Ta≧25°C (114.3mm×76.2mm×1.6mm when mounted on a 4-layer PCB based on JEDEC) is reduced by 13.4mW/°C
●Recommended
Operating Conditions (Ta=25°C)
Parameter
Input power supply voltage
Output current
Symbol
V
CC
I
O
Min.
Vo+3.0
0.0
Max.
25.0
0.1
Unit
V
A
●Recommended
Operating Condition
Parameter
Output Capacitor
Symbol
C
OUT
Min
0.3 *
3
Typ
1.0
Max
-
Unit
μF
Conditions
Ceramic capacitor recommended
*3 The minimum value of capacitor must met this specification over full operating conditions. (Ex: Temperature, DC bias)
●Electrical
Characteristics
(Unless otherwise specified, Vcc= Vo+5V, Ta=25°C)
Parameter
Symbol
Limits
Min.
-
-
-
-
-1
-1.5
-
Vo×0.99
Typ.
300
300
300
400
0.5
0.5
1.0
Vo
Max.
450
450
450
600
1
1.5
3.0
Vo×1.01
Unit
μA
μA
μA
μA
%
%
V
V
Conditions
I
O
=0A, Vo=3.3V
I
O
=0A, Vo=5.0V
I
O
=0A, Vo=5.4V
I
O
=0A, Vo=12.0V
V
CC
=( Vo+3V )→25.0V
I
O
=0→0.1A
I
O
=0.1A
I
O
=0A
Bias current
I
CC
Line Regulation
Load Regulation
Minimum dropout voltage
Output voltage
Reg.I
Reg I
O
V
CO
V
O
www.rohm.com
© 2016 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
3/14
TSZ02201-0G2G0A600060-1-2
11.Apr.2016 Rev.004
BDxxFA1FP3
●Performance
Curve (Reference Data)
■
BD54FA1FP3
(Unless otherwise specified, Ta=25°C, Vcc=Vo+5V, C
IN
=C
OUT
=1μF)
Datasheet
6
8
7
Vcc
6
5V/div
Output Voltage: Vo [V]
5
4
3
2
1
0
0
2
4
6
8 10 12 14 16 18 20 22 24 26
5
0V
4
3
Vo
2
2V/div
1
0V
0
0 100 200 300 400 500 600 700 800
100μs/div
9001000
100us/div
Supply Voltage: Vcc [V]
Figure 2. Vcc - Vo
Figure 3. Input sequence
(C
OUT
= 1μF)
10
Io
9
5
0mA/
8
div
10
Io
9
5
0mA/
8
0mA
7
6
5
div
7
6
5
4
0mA
Vo
4
/
50mV
3
div
5.4V
Vo
/
50mV
3
div
5.4V
2
1
0
0
1us/div
10 20 30 40 50 60 70 80
1μs/div
90 100
1μs/div
2
1
0
0
100us/div
10 20 30 40 50 60 70 80 90 100
100μs/div
Figure 4. Transient Response
(Io = 0A→0.1A)
(C
OUT
= 1μF)
Figure 5. Transient Response
(Io = 0.1A→0A)
(C
OUT
= 1μF)
www.rohm.com
© 2016 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
4/14
TSZ02201-0G2G0A600060-1-2
11.Apr.2016 Rev.004
BDxxFA1FP3
●Performance
Curve (Reference Data)
■
BD54FA1FP3
(Unless otherwise specified, Ta=25°C, Vcc=Vo+5V, C
IN
=C
OUT
=1μF)
Datasheet
5.45
450
400
Output Voltage: Vo [V]
Bias Current: Icc [μA]
5.43
5.41
5.39
5.37
5.35
-30 -20 -10 0 10 20 30 40 50 60 70 80 90
350
300
250
200
150
100
50
0
-30 -20 -10 0
10 20 30 40 50 60 70 80 90
Temperature: Ta [℃]
Figure 6. Ta - Vo
(Io = 0mA)
Temperature: Ta [℃]
Figure 7. Ta - Icc
600
6
400
300
200
100
0
0
10
20
30
40
50
60
70
80
90
100
Output Voltage: Vo [V]
Bias Current: Icc [μA]
500
5
4
3
2
1
0
0
20
40
60
80
100
Output Current: Io [mA]
Figure 8. Io - Icc
Output Current: Io [mA]
Figure 9. Io - Vo
www.rohm.com
© 2016 ROHM Co., Ltd. All rights reserved.
TSZ22111½15½001
5/14
TSZ02201-0G2G0A600060-1-2
11.Apr.2016 Rev.004
