ALUMINUM ELECTROLYTIC CAPACITORS
UB
Chip Type, High Reliability
series
WH
High
Temperature
Chip type, high temperature range, for +125°C use.
Applicable to automatic mounting machine using carrier tape.
Adapted to the RoHS directive (2002/95/EC).
Reflow
CJ
Added ESR specification
at – 40°C
UB
High
Temperature
UX
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
Performance Characteristics
– 40 ~ +125°C
10 ~ 50V
10 ~ 330µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage, leakage current is not more than 0.03CV or 4(µA) , whichever is greater.
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
10
0.32
16
0.24
10
12
25
0.21
16
8
25
6
35
0.18
35
4
50
0.18
50
4
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio
ZT / Z20 (MAX.)
Z– 40°C / Z+20°C
Endurance
After 2000 hours' (φ8
×
6.2 : 1000 hours) application
of rated voltage at 125°C, capacitors meet the
characteristic requirements listed at right.
Capacitance change
tan
δ
Leakage current
Within ±30% of initial value
300% or less of intial specified value
Initial specified value or less
Shelf Life
Resistance to soldering
heat
Marking
After storing the capacitors under no load at 125°C for 1000 hours, and after performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they will meet the specified value for endurance characteristics listed above.
The capacitors shall be kept on the hot plate maintained at 250°C
Capacitance change
Within ±10% of initial value
for 30 seconds. After removing from the hot plate and restored
tan
δ
Initial specified value or less
at room temperature, they meet the characteristic requirements
Leakage current
Initial specified value or less
listed at right.
Black print on the case top.
(φ8
×
6.2)
Chip Type
A±0.2 A±0.2
125¡C Marking
Capacitance
Lot No.
C±0.2
0.5MAX.
Plastic platform
0.3MAX.
Voltage
D±0.5
Positive
Type numbering system (Example : 10V 100
µ
F)
UUB 1 A 1 0 1 MCL 1GS
Configuration
Capacitance tolerance (±20%)
f
D
´
L Code
Rated Capacitance (100
m
F) 8
´
6.2 CL
8
´
10 NL
Rated voltage (10V) 10
´
10 NL
Series name
Type
Taping code
1 2 3 4 5 6 7 8 9 10 11 12 13 14
B±0.2
A2E
100
10V
Trade mark
f
L±0.3
(φ8
×
10,
φ10 ×
10)
H
C±0.2
A±0.2 A±0.2
125¡C Marking Capacitance
Lot No.
Voltage
Trade mark
D±0.5
0.5MAX.
Plastic platform
0.3MAX.
B±0.2
E
Negative
Positive
f ´
L±0.5
Pressure relief vent
Dimensions
Cap.(µF)
V
Code
H
Negative
A
B
C
E
L
H
D L
8
´
6.2
8
´
10 10
´
10
3.3 2.9 3.2
8.3 8.3 10.3
8.3 8.3 10.3
2.3 3.1 4.5
6.2 10 10
0.5 ~ 0.8 0.8 ~ 1.1 0.8 ~ 1.1
25
1E
(mm)
A2E
330
10V
f
10
1A
E
16
1C
35
1V
8
×
6.2
8
×
6.2
8
×
10
10
×
10
50
1H
24
38
46
58
Rated
ripple
10
22
33
47
100
220
330
100
220
330
470
101
221
331
8
×
6.2
8
×
10
10
×
10
58
90
112
8
×
10
10
×
10
66
102
8
×
6.2
8
×
10
10
×
10
48
74
116
8
×
6.2
8
×
10
10
×
10
44
52
80
Case size
φ
D
×
L (mm)
Rated Ripple (mArms) at 125°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz~
1.50
Taping specifications are given in page 24.
Recommended land size, soldering by reflow are given in page 25, 26.
Please select UH(p.78) series if high CV products are required.
Please refer to page 3 for the minimum order quantity.
CAT.8100V
