2-1532013-1: Description9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, ROHS COMPLIANT; CategoryThe connector The connector; File Size95KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

2-1532013-1 Overview

9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, ROHS COMPLIANT

2-1532013-1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compli
Connector type	D MICROMINIATURE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	FEMALE
Contact material	COPPER ALLOY
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYPHENYLENE SULFIDE
MIL compliance	NO
Manufacturer's serial number	1532013
Mixed contacts	NO
Installation type	CABLE
Options	GENERAL PURPOSE
Shell surface	NICKEL
Shell material	METAL
Housing size	A
Total number of contacts	9
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Pin & Socket C onnectors

Product Feature Selector

> Product Details

M83513/04-A03N Product Details

Live Product Chat

Microminiature D Connectors

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

M83513/04-A03N

(2-1532013-1)

T E I nternal N umber: 2 - 1 5 3 2 0 1 3 - 1

Product Highlights:

Product Series = MC K (Full Metal)

C able C onnector

Nickel, Electroless Shell Plating

Number of Positions = 9

C ontact Type = Socket

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Superseded

Search for Replacement Parts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

METAL SHELL ''D'' C ONNEC TOR, RC PT MC K PER MIL-C -83513

(PDF, English)

Catalog Pages/Data Sheets:

MIC RODOT C ATALOG

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Series = MC K (Full Metal)

Product Type = C able C onnector

Number of Positions = 9

C omment = Also available in commercial grade.

Mechanical Attachment:

Mounting Hardware = None

Lead Length (mm [in]) = 457.20 [18.000]

Body Related Features:

Shell Plating = Nickel, Electroless

Wire Size (AWG/C M) = 26 AWG

Wire Type = 19 strand per MIL-C -22759/11

Insulation C olor = 10 solid color repeating per M-85513

Contact Related Features:

C ontact Type = Socket

C ontact Style = Wire Termination

C ontact Base Material = C opper Alloy

C ontact Mating Area Plating Material = Gold (50) per MIL-G-45204

Housing Related Features:

Housing Material = Polyphenylene Sulfide

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Other:

Brand = Microdot

Additional Information:

Product Line Information

2-1532013-1 Related Products

	2-1532013-1	M83513/04-A03N
Description	9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, ROHS COMPLIANT	9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, CRIMP, RECEPTACLE, ROHS COMPLIANT
Is it Rohs certified?	conform to	conform to
package instruction	ROHS COMPLIANT	ROHS COMPLIANT
Reach Compliance Code	compli	compliant
Connector type	D MICROMINIATURE CONNECTOR	D MICROMINIATURE CONNECTOR
Contact to complete cooperation	NOT SPECIFIED	NOT SPECIFIED
Contact point gender	FEMALE	FEMALE
Contact material	COPPER ALLOY	NOT SPECIFIED
DIN compliance	NO	NO
empty shell	NO	NO
Filter function	NO	NO
IEC compliance	NO	NO
insulator material	POLYPHENYLENE SULFIDE	POLYPHENYLENE SULFIDE
MIL compliance	NO	YES
Mixed contacts	NO	NO
Installation type	CABLE	CABLE
Options	GENERAL PURPOSE	GENERAL PURPOSE
Shell surface	NICKEL	NICKEL
Shell material	METAL	METAL
Housing size	A	A
Total number of contacts	9	9
