M83513/04B07C Product Details
Microminiature D Connectors
Not EU RoHS or ELV Compliant
No Image Available
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
M83513/04B07C
(515320136)
TE Internal Number: 515320136
Product Highlights:
Connector
Connector Design = Cable Connector
Connector Style = Receptacle
Contact Type = Socket
Product Series = MCK (Full Metal)
View all Features
Superseded
Search for Replacement Parts
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
METAL SHELL ''D'' CONNECTOR, RCPT MCK PER MILC83513 (PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Connector
Connector Design = Cable Connector
Product Series = MCK (Full Metal)
Mechanical Attachment:
Mounting Hardware = None
Dimensions:
Lead Length (mm [in]) = 12.70 [0.500]
Body Features:
Shell Plating = Cadmium, Yellow Chromate
Wire Size (AWG/CM) = 25 AWG
Wire Type = Solid Copper Tin Dipped, Gold Plated
Contact Features:
Contact Type = Socket
Contact Style = Wire Termination
Housing Features:
Connector Style = Receptacle
Housing Material = Polyphenylene Sulfide (PPS)
Configuration Features:
Number of Positions = 15
Industry Standards:
Government/Industry Qualification = No
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Not suitable for lead free processing
Other:
Brand = Microdot
Comment = Also available in commercial grade.
