M83513/03F14N Product Details
Microminiature D Connectors
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
No Image Available
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
M83513/03F14N
(915320143)
TE Internal Number: 915320143
Product Highlights:
Connector
Connector Design = Cable Connector
Connector Style = Plug
Contact Type = Pin
Product Series = MCK (Full Metal)
View all Features
Superseded
Search for Replacement Parts
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Connector
Connector Design = Cable Connector
Product Series = MCK (Full Metal)
Mechanical Attachment:
Mounting Hardware = None
Dimensions:
Lead Length (mm [in]) = 1828.80 [72.000]
Body Features:
Shell Plating = Nickel, Electroless
Wire Size (AWG/CM) = 26 AWG
Wire Type = 19 strand per MILC22759/11
Insulation Color = 10 solid color repeating per M85513
Contact Features:
Contact Type = Pin
Contact Style = Wire Termination
Housing Features:
Connector Style = Plug
Housing Material = Polyphenylene Sulfide (PPS)
Configuration Features:
Number of Positions = 37
Industry Standards:
Government/Industry Qualification = No
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Wave solder capable to 240°C, Wave
solder capable to 260°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS compliant
Other:
Brand = Microdot
Comment = Also available in commercial grade.
