INTERCONNECTS
SERIES 335, 364, 435, 464 • .100” GRID (.018” DIA. PINS),
LOW PROFILE • SINGLE AND DOUBLE ROW STRIPS
•
Series 335 and 435 single and double row PCB
.100
Number of Pins
X .100"
interconnects o er a .070” pro le, the lowest
available
.018 DIA.
.125
.070
•
Series 364 and 464 single and double row PCB
.050
interconnects o er .085” pro le above board
.018 DIA.
.104
•
Series 335 and 435 use MM #3516 pins. See
page 212 for details
.100
•
Series 364 and 464 use MM #6458 pins. See
page 213 for details
FIG. 1
.200
.100
Number of Pins
X .100" / 2
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
ORDERING INFORMATION
Series 335...160
.050
.125
.070
.104
.018 DIA.
Single Row .070” Pro le Pin Header
335 XX 1_ _ 00 160000
FIG. 1
Series 435...160
Specify number of pins
.100
01-32
FIG. 2
.100
Double Row .070” Pro le Pin Header
435 XX 2_ _ 00 160000
FIG. 2
Series 364...580
.050
Number of Pins
X .100"
Specify number of pins
04-72
.018 DIA.
.125
.085
Single Row .085” Pro le Pin Header
364 10 1_ _ 00 580000
FIG. 3
Series 464...580
.018 DIA.
.120
Specify number of pins
01-32
Double Row .085” Pro le Pin Header
464 10 2_ _ 00 580000
.100
FIG. 3
.200
FIG. 4
Specify number of pins
04-72
PAGE 78 | INTERCONNECTS
.100
Number of Pins
X .100" / 2
.125
.085
.120
.050
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
10
10
µ”
Au
For
Electrical, Mechanical
& Enviromental Data,
See page 264
.018 DIA.
.100
FIG. 4
SPECIFY PLATING CODE XX=
Pin Plating
90
200
µ”
Sn/Pb
40
200
µ”
Sn
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
