DUAL-IN-LINE SOCKETS
OPEN FRAME / SOLDER TAIL
WWW.PRECIDIP.COM
TEL +41 32 421 04 00
SALES@PRECIDIP.COM
Open frame standard low profile DIL Sockets.
TECHNICAL SPECIFICATIONS
(FOR GENERAL SPECS, SEE PAGE 127)
INSUL ATOR
FL AMMABILIT Y
SLEEVE
CONTACT CLIP (4 FINGER)
ACCEPTED PIN Ø
FORCES
MECHANICAL LIFE
RATED CURRENT
CONTACT RESISTANCE
DIELECTRIC STRENGTH
Black glass filled polyester PCT-GF30-FR
UL 94V-O
Brass CuZn36Pb3 (C36000)
Beryllium copper (C17200)
0.40 to 0.56 mm
2 N typ. insertion
1 N typ. withdrawal
(polished steel gauge Ø 0.43 mm)
Min. 100 cycles
1A
Max. 10 m
Min. 1’000 V
RMS
ORDERING INFORMATION ROHS COMPLIANT PARTS
PP PL ATING CODE
SLEEVE
CLIP
Other plating on request (see page 178 for plating specs).
87
83
Tin
Tin
Flash gold
0.75 μm gold
NO. OF POLES
A
B
C
SEE PAGE 128
ORDER CODES
10
4
6
8
10
12
14
16
18*
20*
22*
24*
28
20
22
24
28
32
10
24*
28*
32*
36
40*
42
48*
50
52
50
52
64
12.6
5.0
7.6
10.1
12.6
15.2
17.7
20.3
22.8
25.3
27.8
30.4
35.5
25.4
27.8
30.4
35.5
40.6
12.7
30.5
35.5
40.6
45.7
50.8
53.3
60.9
63.5
66.0
5.08
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
7.62
10.16
10.16
10.16
10.16
10.16
15.24
15.24
15.24
15.24
15.24
15.24
15.24
15.24
15.24
15.24
7.6
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
10.1
12.6
12.6
12.6
12.6
12.6
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
17.7
25.3
25.3
25.3
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
Fig. 11
Fig. 12
Fig. 13
Fig. 14
Fig. 15
Fig. 16
Fig. 17
Fig. 18
Fig. 19
Fig. 20
Fig. 21
Fig. 22
Fig. 23
Fig. 24
Fig. 25
Fig. 26
Fig. 27
Fig. 28
Fig. 29
Fig. 30
Fig. 31
110-PP-210-41-001101
110-PP-304-41-001101
110-PP-306-41-001101
110-PP-308-41-001101
110-PP-310-41-001101
110-PP-312-41-001101
110-PP-314-41-001101
110-PP-316-41-001101
110-PP-318-41-001101
110-PP-320-41-001101
110-PP-322-41-001101
110-PP-324-41-001101
110-PP-328-41-001101
110-PP-420-41-001101
110-PP-422-41-001101
110-PP-424-41-001101
110-PP-428-41-001101
110-PP-432-41-001101
110-PP-610-41-001101
110-PP-624-41-001101
110-PP-628-41-001101
110-PP-632-41-001101
110-PP-636-41-001101
110-PP-640-41-001101
110-PP-642-41-001101
110-PP-648-41-001101
110-PP-650-41-001101
110-PP-652-41-001101
110-PP-950-41-001101
110-PP-952-41-001101
110-PP-964-41-001101
OPTIONS
1
Insulators without center bar
*
Open frame insulators 318, 320, 322, 324, 624, 628, 632, 640
and 648 available on special request without center bars; add
suffix 151 to the part number. Example
110-83-628-41-001101
becomes
110-83-628-41-001151
2
Sockets with increased solder tail length of 4.2 mm
allowing application on multilayer PCBs up to 3.4 mm
thickness replace
110-..-...-..-......
by
111-..-...-..-......
3
Sockets with soft brass pin series
110-..-...-..-005101,
please consult
4
For DIL Sockets with closed frame insulators
replace
110-...
by
210-...
Please consult for available pin numbers
63.5 22.86
66.0 22.86
81.2 22.86
Due to technical progress, all information provided is subject to change without prior notice.
129
