15KP SERIES
V
R
: 12 - 240 Volts
P
PK
: 15,000 Watts
FEATURES :
* Excellent Clamping Capability
* Fast Response Time
* Low Zener Impedance
* Low Leakage Current
TRANSIENT VOLTAGE
SUPPRESSOR
AR - L
0.053 (1.35)
0.050 (1.27)
0.250 (6.4)
0.235 (6.0)
MECHANICAL DATA
* Case : Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Lead : Axial lead solderable per MIL-STD-202,
Method 208 guaranteed
* Polarity : Cathode polarity band
* Mounting position : Any
* Weight : 2.73 grams
0.410 (10.4)
0.380 (9.7)
1.00 (25.4)
MIN.
Dimensions in inches and ( millimeter )
MAXIMUM RATINGS
Rating at 25
°
C ambient temperature unless otherwise specified.
Rating
Peak Pulse Power Dissipation (10X1000µs, see Fig.1 )
Steady State Power Dissipation
Peak Forward Surge Current, 8.3ms Single Half Sine Wave
Symbol
P
PK
P
D
I
FSM
Value
15,000
7.0
200
- 55 to + 150
Unit
Watts
Watts
Amps.
°C
(Uni-directional devices only)
Operating and Storage Temperature Range
T
J
, T
STG
This pulse is a standard test waveform used for protection devices.
Fig. 1
I
PP
0.9 I
PP
Current
(Peak Value)
0.5 I
PP
0.1 I
PP
Time
T1 x 1.25 = 10µs
1000µs
UPDATE : AUGUST 16, 2001
ELECTRICAL CHARACTERISTICS
Rating at 25
°
C ambient temperature unless otherwise specified
Reverse
Breakdown
Stand Off
Voltage @ I
T
Part
Part
Voltage
Number
Number
V
R
V
BR
(V)
I
T
(Uni-directional)
(Bi-directional)
(V)
Min.
(mA)
15KP75
15KP75A
15KP78
15KP78A
15KP85
15KP85A
15KP90
15KP90A
15KP100
15KP100A
15KP110
15KP110A
15KP120
15KP120A
15KP130
15KP130A
15KP150
15KP150A
15KP160
15KP160A
15KP170
15KP170A
15KP180
15KP180A
15KP200
15KP200A
15KP220
15KP220A
15KP240
15KP240A
15KP75C
15KP75CA
15KP78C
15KP78CA
15KP85C
15KP85CA
15KP90C
15KP90CA
15KP100C
15KP100CA
15KP110C
15KP110CA
15KP120C
15KP120CA
15KP130C
15KP130CA
15KP150C
15KP150CA
15KP160C
15KP160CA
15KP170C
15KP170CA
15KP180C
15KP180CA
15KP200C
15KP200CA
15KP220C
15KP220CA
15KP240C
15KP240CA
75
75
78
78
85
85
90
90
100
100
110
110
120
120
130
130
150
150
160
160
170
170
180
180
200
200
220
220
240
240
83.3
83.3
86.7
86.7
94.4
94.4
100
100
111
111
122
122
133
133
144
144
167
167
178
178
189
189
200
200
222
222
245
245
267
267
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
Maximum
Reverse Leakage
@ V
R
I
R
(µA)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Maximum
Clamping
Voltage @ I
PP
V
C
(V)
135
122
140
126
152
137
160
146
179
162
196
178
214
193
231
209
268
243
287
259
304
275
321
287
356
325
393
347
428
387
Maximum
Peak Pulse
Current
I
PP
(A)
111
123
107
119
99
109
94
103
84
93
77
84
70
78
65
72
56
62
52
58
49
55
47
52
42
46
38
43
35
39
Max. Voltage
Temperature
Variation
of V
BR
(mV/
°
C)
100
89
104
93
113
102
120
110
134
123
147
133
161
146
174
158
202
184
216
196
229
208
242
220
296
274
297
273
324
300
Note:
Suffix " A " denotes 5% tolerance device , no suffix denotes a 10% tolerance device.
* Prefered Voltages.
Fig. 2 - Peak Pulse Power vs. Pulse Time
1,000
Fig. 3 - Typical Capacitance vs. Breakdown Voltage
10,000
Pp Peak Pulse Power - kW
C - capacitance (pF)
100
1,000
10
10
Measued at
Stad-off Voltage
1.0
100ns
1µs
10µs
100µs
1ms
10ms
1
1V
10V
100V
1,000V
td Pulse Time - sec
V
BR
- Breakdown Voltage - Volts
