Feed-through modular terminal block - ST 10 RD - 3035662
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Feed-through modular terminal block, nom. voltage: 1000 V, nominal current: 57 A, connection method:
Spring-cage connection, number of connections: 2, cross section:0.2 mm² - 16 mm², AWG: 24 - 6, width: 10.2
mm, color: red, mounting type: NS 35/7,5, NS 35/15
Your advantages
The double bridge shaft not only enables individual chain bridging, but also reducing bridging to spring-cage terminal blocks with smaller cross
sections
The flexible options for reducing bridging in the CLIPLINE complete system can be found in "Accessories for the CLIPLINE complete modular
terminal block system"
Key Commercial Data
Packing unit
Minimum order quantity
GTIN
GTIN
4046356625098
50 pc
50 pc
Technical data
General
Number of levels
Number of connections
Potentials
Nominal cross section
Color
Insulating material
Flammability rating according to UL 94
Area of application
1
2
1
10 mm²
red
PA
V0
Machine building
Plant engineering
Process industry
Rated surge voltage
8 kV
11/04/2018 Page 1 / 5
https://www.phoenixcontact.com/pi/products/3035662
Feed-through modular terminal block - ST 10 RD - 3035662
Technical data
General
Degree of pollution
Overvoltage category
Insulating material group
Maximum power dissipation for nominal condition
Maximum load current
Nominal current I
N
Nominal voltage U
N
Open side panel
3
III
I
1.82 W
65 A (with 16 mm² conductor cross section)
57 A
1000 V
Yes
Dimensions
Width
End cover width
Length
Height NS 35/7,5
Height NS 35/15
10.2 mm
2.2 mm
71.5 mm
50.3 mm
57.8 mm
Connection data
Connection method
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Min. AWG conductor cross section, flexible
Max. AWG conductor cross section, flexible
Conductor cross section flexible, with ferrule without plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve min.
Conductor cross section flexible, with ferrule with plastic sleeve max.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, min.
2 conductors with same cross section, stranded, TWIN ferrules with
plastic sleeve, max.
Connection in acc. with standard
Conductor cross section solid min.
Conductor cross section solid max.
Conductor cross section AWG min.
Conductor cross section AWG max.
Conductor cross section flexible min.
Conductor cross section flexible max.
Spring-cage connection
IEC 60947-7-1
0.2 mm²
16 mm²
24
6
0.2 mm²
10 mm²
24
8
0.25 mm²
0.25 mm²
10 mm²
1.5 mm²
2.5 mm²
IEC/EN 60079-7
1.5 mm²
16 mm²
16
6
1.5 mm²
10 mm²
11/04/2018 Page 2 / 5
Conductor cross section flexible, with ferrule without plastic sleeve max. 10 mm²
https://www.phoenixcontact.com/pi/products/3035662
Feed-through modular terminal block - ST 10 RD - 3035662
Technical data
Connection data
Stripping length
Internal cylindrical gage
18 mm
A6
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
IEC 60947-7-1
V0
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Drawings
Circuit diagram
Approvals
Approvals
Approvals
DNV GL / CSA / PRS / BV / LR / KR / NK / UL Recognized / cUL Recognized / IECEE CB Scheme / VDE Gutachten mit Fertigungsüberwachung /
EAC / EAC / cULus Recognized
Ex Approvals
IECEx / ATEX / EAC Ex
Approval details
DNV GL
http://exchange.dnv.com/tari/
TAE00001CS
CSA
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
600 V
65 A
16-6
http://www.csagroup.org/services-industries/product-listing/
C
600 V
65 A
16-6
13631
11/04/2018 Page 3 / 5
https://www.phoenixcontact.com/pi/products/3035662
Feed-through modular terminal block - ST 10 RD - 3035662
Approvals
PRS
B
600 V
65 A
16-6
http://www.prs.pl/
TE/2156/880590/17
BV
http://www.veristar.com/portal/veristarinfo/generalinfo/
approved/approvedProducts/equipmentAndMaterials
13403/B0 BV
LR
http://www.lr.org/en
04/20034
KR
http://www.krs.co.kr/eng/main/main.aspx
HMB17372-EL002
NK
http://www.classnk.or.jp/hp/en/
09 ME 140
UL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
65 A
16-6
FILE E 60425
cUL Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
B
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
C
600 V
65 A
16-6
FILE E 60425
600 V
65 A
16-6
IECEE CB Scheme
Nominal voltage UN
mm²/AWG/kcmil
http://www.iecee.org/
DE1-51476
800 V
1.5-10
11/04/2018 Page 4 / 5
https://www.phoenixcontact.com/pi/products/3035662
Feed-through modular terminal block - ST 10 RD - 3035662
Approvals
VDE Gutachten mit
Fertigungsüberwachung
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www2.vde.com/de/Institut/Online-Service/
VDE-gepruefteProdukte/Seiten/Online-Suche.aspx
800 V
57 A
1.5-10
40009039
EAC
EAC-Zulassung
EAC
RU C-
DE.A*30.B.01742
cULus Recognized
