ALUMINUM ELECTROLYTIC CAPACITORS
CJ
Chip Type, High Reliability.
Low temperature ESR specification.
series
Chip type, high temperature range, for +125°C use.
Added ESR specification after the test at – 40°C
(
φ
6.3 sizes provide only for the first stage. )
Applicable to automatic mounting machine using carrier tape.
Adapted to the RoHS directive (2002/95/EC).
CJ
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
Added ESR specification
at – 40°C
UB
Performance Characteristics
– 40 ~ +125°C
10 ~ 50V
10 ~ 470µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage, leakage current is not more than 0.03CV or 4(µA) , whichever is greater.
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
10
0.32
16
0.24
10
12
25
0.21
16
8
25
6
35
0.18
35
4
50
0.18
50
4
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio
ZT / Z20 (MAX.)
Z– 40°C / Z+20°C
Endurance
After 2000 hours' application of rated voltage at
125°C, capacitors meet the characteristic
requirements listed at right.
Capacitance change
tan
δ
Leakage current
Within ±30% of initial value
300% or less of intial specified value
Initial specified value or less
Shelf Life
Resistance to soldering
heat
Marking
After storing the capacitors under no load at 125°C for 1000 hours, and after performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they will meet the specified value for endurance characteristics listed above.
The capacitors shall be kept on the hot plate maintained at 250°C
Capacitance change
Within ±10% of initial value
for 30 seconds. After removing from the hot plate and restored
tan
δ
Initial specified value or less
at room temperature, they meet the characteristic requirements
Leakage current
Initial specified value or less
listed at right.
Black print on the case top.
Chip Type
Series
D± 0.5
C±0.2
B±0.2
0.5MAX.
Voltage( C : 16V )
(φ6.3
×
8.7)
Plastic platform
0.3MAX.
Positive
A±0.2 A±0.2
Type numbering system (Example : 10V 100
µ
F)
UC J 1 A 1 0 1 MCL 1GS
Taping code
Configuration
Capacitance tolerance (±20%)
Rated Capacitance (100
m
F)
Rated voltage (10V)
Series name
Type
1 2 3 4 5 6 7 8 9 10 11 12 13 14
A2
47C
CJ
Lot No.
Voltage( V : 35V )
Trade mark
Capacitance
f
L±0.3
Plastic platform
0.3MAX.
D± 0.5
B±0.2
H
C±0.2
0.5MAX.
(φ8
×
10,
φ10 ×
10)
E
Negative
Positive
A±0.2 A±0.2
f ´
Series
f
Lot No.
Capacitance
L±0.5
H
16
1C
Negative
A
B
C
E
L
H
25
1E
A2
100V
CJ
D L
6.3
´
8.7
8
´
10 10
´
10
2.4 2.9 3.2
6.6 8.3 10.3
6.6 8.3 10.3
2.2 3.1 4.5
8.7 10 10
0.5 ~ 0.8 0.8 ~ 1.1 0.8 ~ 1.1
(mm)
Dimensions
Cap.(µF)
V
Code
10
1A
E
10
22
33
47
100
220
330
470
100
220
330
470
101
221
331
471
6.3
×
8.7
8
×
10
10
×
10
10
×
10
14
2.0
1.5
1.5
-
95
6.0 250
4.5 400
4.5 400
6.3
×
8.7
8
×
10
10
×
10
10
×
10
14
2.0
1.5
1.5
-
95
6.0 250
4.5 400
4.5 400
6.3
×
8.7
6.3
×
8.7
6.3
×
8.7
8
×
10
10
×
10
10
×
10
14
14
14
2.0
1.5
1.5
6.3
×
8.7
-
95 6.3
×
8.7
-
95 6.3
×
8.7
-
95 6.3
×
8.7
6.0 250 10
×
10
4.5 400 10
×
10
4.5 400
35
1V
14
14
14
14
1.5
1.5
-
95 6.3
×
8.7
-
95 6.3
×
8.7
-
8
×
10
95
-
95 10
×
10
4.5 400 10
×
10
4.5 400
Case size
φ
D
×
L
(mm)
50
1H
14
14
2.0
1.5
1.5
95
-
95
-
6.0 200
4.5 330
4.5 330
Rated
ripple
after
Initial torture
test
ESR
Max. ESR (
Ω
) at -40°C 100kHz, Rated Ripple (mArms) at 125°C 100kHz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.35
120 Hz
0.50
300 Hz
0.64
1 kHz
0.83
10 kHz~
1.00
Taping specifications are given in page 24.
Recommended land size, soldering by reflow are given in page 25, 26.
Please refer to page 3 for the minimum order quantity.
