ALUMINUM ELECTROLYTIC CAPACITORS
CB
Chip Type, Long Life Assurance
series
Chip type with load life of 7000 hours at +105
°C
.
Applicable to automatic mounting machine using carrier tape.
Adapted to the RoHS directive (2002/95/EC).
CB
Low
Impedance
Long Life
UL
CW
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
Performance Characteristics
– 25 ~ +105°C
6.3 ~ 50V
0.1 ~ 1000µF
± 20% at 120Hz, 20°C
After 2 minutes' application of rated voltage, leakage current is not more than 0.03 CV or 4 (µA) , whichever is greater.
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
6.3
0.32
10
0.28
6.3
4
16
0.26
10
3
25
0.16
16
2
25
2
35
0.14
35
2
50
0.14
50
2
Measurement frequency : 120Hz
Rated voltage (V)
Stability at Low Temperature
Impedance ratio
ZT / Z20 (MAX.)
Z– 25°C / Z+20°C
Endurance
After 7000 hours' application of rated voltage
at 105°C , capacitors meet the characteristic
requirements listed at right.
Capacitance change
tan
δ
Leakage current
Within ±30% of initial value
300% or less of initial specified value
Initial specified value or less
Shelf Life
Resistance to soldering
heat
Marking
After storing the capacitors under no load at 105°C for 1000 hours, and after performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they will meet the specified value for endurance characteristics listed above.
The capacitors shall be kept on the hot plate maintained at 250°C
Capacitance change
Within ±10% of initial value
for 30 seconds. After removing from the hot plate and restored
tan
δ
Initial specified value or less
at room temperature, they meet the characteristic requirements
Leakage current
Initial specified value or less
listed at right.
Black print on the case top.
Chip Type
(φ4 ~ 6.3)
Voltage ( C : 16V )
Series
Plastic platform
0.3MAX.
φD±0.5
C
±0.2
0.5MAX.
Positive
Type numbering system (Example : 16V 100
µ
F)
UCB 1 C 1 0 1 MC L 1 GS
Capacitance tolerance (±20%)
Rated Capacitance (100µF)
Rated voltage (16V)
Series name
Type
1 2 3 4 5 6 7 8 9 10 11 12 13 14
L
±0.3
Lot No.
Capacitance
H
Negative
Taping code
Configuration
f
D
Code
4 ~ 6.3 CL
8
¥
10 NL
A
±
0.2 A
±0.2
A2
100C
CB
B
±
0.2
E
(φ8 ~ 10 )
0.5MAX.
Voltage ( V : 35V )
Trade mark
Plastic platform
Series
φD±0.5
0.3MAX.
C±0.2
Positive
f
D
´
L
L±0.5
Lot No.
Capacitance
Pressure relief vent
H
Negative
A
B
C
E
L
H
(mm)
4
´
7
5
´
7 6.3
´
7 6.3
´
8.7 8
´
10 10
´
10
1.8
2.1
2.4
2.4
2.9
3.2
4.3
5.3
6.6
6.6
8.3
10.3
4.3
5.3
6.6
6.6
8.3
10.3
4.5
1.0
1.3
2.2
2.2
3.1
10
7.0
7.0
7.0
8.7
10
0.5 ~ 0.8 0.5 ~ 0.8 0.5 ~ 0.8 0.5 ~ 0.8 0.8 ~ 1.1 0.8 ~ 1.1
Voltage
V
6.3
Code
j
10
A
16
C
25
E
35
V
50
H
Dimension table in next page.
A±0.2 A±0.2
A2
220V
CB
B±0.2
E
CAT.8100V
ALUMINUM ELECTROLYTIC CAPACITORS
CB
Cap.(µF)
series
Dimensions
V
Code
6.3
0J
10
1A
16
1C
25
1E
4
×
7
4
×
7
4
×
7
4
×
7
4
×
7
4
×
7
4
×
7
4
×
7
35
1V
1.0
2.6
3.2
3.8
6.2
11
14
15
25
42
57
8
×
10
8
×
10
10
×
10
10
×
10
50
1H
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
0R1
R22
R33
R47
010
2R2
3R3
4R7
100
220
330
470
101
221
331
471
102
10
×
10
5
×
7
6.3
×
7
6.3
×
8.7
8
×
10
4
×
7
4
×
7
18
30
6.3
×
7
5
×
7
6.3
×
7
22
5
×
7
5
×
7
35
6.3
×
7
6.3
×
8.7
48
63
116
6.3
×
8.7
77
92
151
36
60
101
160
8
×
10
50
81
6.3
×
8.7
8
×
10
141
10
×
10
216
254
313
Case size
Rated
φ
D
×
L (mm)
ripple
Rated Ripple (mArms) at 105°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz~
1.50
Taping specifications are given in page 24.
Recommended land size, soldering by reflow are given
in page 25, 26.
Please refer to page 3 for the minimum order quantity.
CAT.8100V
