1600 SERIES
Dual and Quad Data-bus Isolators
SELECTION GUIDE
Interwinding
Capacitance (typ)
100kHz
Primary
Inductance (typ)
10kHz, 250mV
Pulse Width
(max)
Turns Ratio
Order Code
Type
1600
1601
1620
Function
uS
5
5
3.4
3.4
2.6
2.6
5
5
1:1
1:1
1:2
1:2
1:3
1:3
1:1.5
1:1.5
mH
3
3
1.5
1.5
1
1
2
2
pF
60
60
45
45
34
34
40
40
2
1
2
1
2
1
2
1
Quad Isolator
Dual Isolator
Quad Isolator
Dual Isolator
Quad Isolator
Dual Isolator
Quad Isolator
Dual Isolator
5V to 5V Logic Isolation
5V to 5V Logic Isolation
5V to 10V Logic Isolation
5V to 10V Logic Isolation
5V to 15V Logic Isolation
5V to 15V Logic Isolation
3.3V to 5V Logic Isolation
3.3V to 5V Logic Isolation
FEATURES
■
Logic Translation
■
Bi-Directional
■
Invert / Non-Invert
■
TTL-CMOS Convert
■
3V-5V convert
■
Toroidal construction
■
Low Profile
■
Dual or Quad packs
■
700VDC Isolation
DESCRIPTION
TThe 1600 series are dual or quad isolation
transformer packs for use in digital circuits.
They are particularly suited to isolating
microprocessor bus connections and
performing logic level translation.
Being completely passive, power savings
are offered over opto-coupled or emitter
follower solutions.
1621
1630
1631
1635
1636
SWITCHING CHARACTERISTICS, 5V LOGIC
Parameter
Conditions
MAX
Units
Propagation delay, t
PD
Low-level pulse width
1
, t
LPW
High-level pulse width
1
, t
HPW
LSTTL Buffer drive
Other terminal to VCC
Other terminal to GND
5.0
5.0
5.0
ABSOLUTE MAXIMUM RATINGS
Operating free air temperature range
Storage temperature range
Lead Temperature 1.5mm from case for 10 seconds
Isolation voltage (flash tested for 1 second)
Insulation resistance at 500VDC
0°C to 70°C
--40°C to 125°C
300°C
700VDC
>10GΩ
NON-INVERTED +VE GOING PULSE
1
2
0V
Quad-Bus
Isolator
16
15
0V
NON-INVERTED –VE GOING PULSE
+5V
1
2
16
15
+5V
Quad-Bus
Isolator
INVERTED +VE GOING PULSE
+5V
1
2
0V
Quad-Bus
Isolator
16
15
INVERTED –VE GOING PULSE
+5V
1
2
16
15
0V
Quad-Bus
Isolator
www.cdpoweronline.com
1 The maximum pulse width limit to be applied to the repetition curve.
All specifications typical at T
A
=25°C
Package
Style
ns
µs
µs
1600 SERIES
Dual and Quad Data-bus Isolators
MECHANICAL DIMENSIONS (PACKAGE STYLE 1)
12.90
MECHANICAL DIMENSIONS (PACKAGE STYLE 2)
22.50
6.86
6.86
5.80
5.80
4.50
0.64±0.15
2.54
10.16
8.00
0.50±0.05
4.50
0.64±0.15
2.54
17.78
8.00
0.50±0.05
0.25±0.05
8.65
10 PIN DIL (TOP VIEW)
10 9
7 6
N
1
1
2
4
N
1
5
1
8.65
0.25±0.05
16 PIN DIL (TOP VIEW)
16 15 14 13 12 11 10 9
N
1
2
3
N
1
4
5
N
1
6
7
N
1
8
All dimensions in mm (±0.25mm unless otherwise stated)
All dimensions in mm (±0.25mm unless otherwise stated)
REPETITION RATE VERSUS PULSE WIDTH CURVE
t
PW
10
max
t
PW
(µs)
1
Operating Region
0.1
t
PW
t
T
C&D Technologies (NCL) Ltd
Tanners Drive, Blakelands North
Milton Keynes MK14 5BU, England
Tel: +44 (0)1908 615232
Fax: +44 (0)1908 617545
email: info@cdtechno-ncl.com
www.cdpoweronline.com
C&D Technologies Inc.
3400 E Britannia Drive, Tucson,
Arizona 85706, USA
Tel: +1 (800) 547-2537
Fax: +1 (520) 741-4598
email: sales@cdtechno.com
0.1
1
t
T
(µs)
10
100
C&D Technologies (NCL) Limited reserve the right to alter or improve the
specification, internal design or manufacturing process at any time, without
notice. Please check with your supplier or visit our web site to ensure that
you have the current and complete specification for your product before use.
© C&D Technologies (NCL) Limited 2000
NMP 1600.2
No part of this publication may be copied, transmitted or stored in a
retrieval system or reproduced in any way including, but not limited to,
photography, photocopy, magnetic or other recording means, without prior
written permission from C&D Technologies (NCL) Limited.
Instructions for use are available from www.cdpoweronline.com
