1056335-1 Product Details
Live Product Chat
Product Photo
SMA/QMA RF Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
1056335-1
T E I nternal N umber: 1 0 5 6 3 3 5 - 1
Product Highlights:
l
Adapter
l
C onnector Type = SMA
l
Without Snap-Lock
l
Adapter Type = Plug-Plug
l
Body Style = Straight
View all Features
Obsolete
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Adapter
l
C onnector Type
= SMA
l
Adapter Type
= Plug-Plug
l
Body Style
= Straight
l
Body Material
= Stainless Steel
l
Body Finish
= Gold
l
C enter C ontact
= With
l
Retractable C ollar
= Without
l
Safety Wire Holes
= Without
l
Dielectric Material = TFE Fluorocarbon
l
C oupling Nut Material = Stainless Steel
l
C oupling Nut Finish = Gold over Nickel
l
Gasket Material = Silicone Rubber
l
Retaining Ring Material = Beryllium C opper
Mechanical Attachment:
l
Panel Attachment
= Without
Electrical Characteristics:
l
Impedance (?) = 50
l
Frequency = DC - 27 GHz
l
Insulation Resistance (M?) = 5,000
Body Related Features:
l
Snap-Lock = Without
l
Length (mm [in])
= 22.30 [0.878]
Contact Related Features:
l
C enter C ontact Material = Beryllium C opper
l
C enter C ontact Plating = Gold over C opper
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
