111949-1 Product Details
Live Product Chat
Product Photo
Pin and Pinless Headers (AMP-LATCH)
Not EU R oHS or ELV C om plia nt
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
111949-1
T E I nternal N umber: 1 1 1 9 4 9 - 1
Product Highlights:
l
C onnector Type = Pin Header
l
Low Profile
l
Number of Positions = 10
l
2.54 x 2.54 mm C enterline, Matrix
l
PC B Mount Angle = Vertical
View all Features
Obsolete
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
C onnector Type = Pin Header
l
Profile
= Low
l
Number of Positions
= 10
l
PC B Mount Angle
= Vertical
l
PC B Retention Feature
= No
l
Mating Polarization Type
= None
l
Mating C onnector Lock
= Without
l
Housing Style
= 4-Sided
l
Ejection Latches
= Without
l
Post Size (mm [in]) = 0.64 [.025]
l
PC B Mount Style = Through Hole
l
Board Standoff = With
l
[Shrouded] End Dimension (mm [in]) = 3.81 [0.150]
l
Mounting Ears = Without
Mechanical Attachment:
l
Panel Attachment = Without
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.05 [0.120]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
C enterline, Matrix (mm [in])
= 2.54 x 2.54 [.100 x .100]
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold Flash
l
C ontact Shape = Square
l
C ontact Base Material = C opper Alloy
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Not suitable for lead free processing
Conditions for Usage:
l
Temperature Rating
= Standard
Other:
l
Brand = AMP
