WTE
POWER SEMICONDUCTORS
U16D05C – U16D60C
Pb
16A GLASS PASSIVATED DUAL SUPEFAST RECTIFIER
Features
!
!
!
!
!
!
Glass Passivated Die Construction
Super-Fast Switching
Low Forward Voltage Drop
Low Reverse Leakage Current
S
High Surge Current Capability
Plastic Material has UL Flammability
R
Classification 94V-O
L
N
M
A
B
H
TO-3P
Dim
Min
Max
3.20
3.50
A
4.70
5.30
B
—
23.00
C
19.00
—
D
2.80
3.20
E
0.45
0.85
G
—
16.20
H
1.70
2.70
J
3.15 Ø
3.65 Ø
K
—
4.50
L
5.25
5.65
M
1.10
1.40
N
—
2.50
P
11.70
12.70
R
5.00
6.00
S
All Dimensions in mm
J
K
PIN1
2
3
P
Mechanical Data
!
!
!
!
!
!
!
Case: TO-3P, Molded Plastic
Terminals: Plated Leads Solderable per
MIL-STD-750, Method 2026
Polarity: See Diagram
Weight: 5.6 grams (approx.)
Mounting Position: Any
Mounting Torque: 11.5 cm-kg (10 in-lbs) Max.
Lead Free: For RoHS / Lead Free Version,
Add “-LF” Suffix to Part Number, See Page 4
C
PIN 1 -
+
Case, PIN 2
G
D
E
PIN 3 -
Maximum Ratings and Electrical Characteristics
Single Phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
U16D
05C
50
35
@T
A
=25°C unless otherwise specified
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
@T
C
= 100°C
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
U16D
10C
100
70
U16D
15C
150
105
U16D
20C
200
140
U16D
30C
300
210
U16D
40C
400
280
U16D
50C
500
350
U16D
60C
600
420
Unit
V
V
A
16
Non-Repetitive Peak Forward Surge Current 8.3ms
Single half sine-wave superimposed on rated load
(JEDEC Method)
Forward Voltage
Peak Reverse Current
At Rated DC Blocking Voltage
Reverse Recovery Time (Note 1)
Typical Junction Capacitance (Note 2)
Operating and Storage Temperature Range
@I
F
= 8.0A
@T
A
= 25°C
@T
A
= 100°C
I
FSM
V
FM
I
RM
t
rr
C
j
T
j
, T
STG
35
120
0.975
200
1.3
10
500
50
70
-55 to +150
1.7
A
V
µA
nS
pF
°C
Note: 1. Measured with IF = 0.5A, IR = 1.0A, IRR = 0.25A. See figure 5.
2. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.
U16D05C – U16D60C
1 of 4
© 2006 Won-Top Electronics
16
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
20
I
(AV)
, AVERAGE FORWARD CURRENT (A)
100
05C - 20C
30C - 40C
10
12
8
50C - 60C
1.0
4
Pulse width = 300
µ
s
2% duty cycle
0
0
50
100
150
T
C
, CASE TEMPERATURE (
°
C)
Fig. 1 Forward Current Derating Curve
0.1
0
0.6
1.2
1.8
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
300
400
8.3 ms single half-sine-wave
JEDEC method
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
T
j
= 25
°
C
f = 1.0MHz
200
C
j
, CAPACITANCE (pF)
100
U16D05C -
U16D40C
100
U16D50C -
U16D60C
0
1
10
NUMBER OF CYCLES AT 60Hz
Fig. 3 Maximum Non-Repetitive Surge Current
100
10
0.1
1.0
10
100
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Junction Capacitance
t
rr
+0.5A
50
Ω
NI (Non-inductive)
10
Ω
NI
Device
Under
Test
(-)
Pulse
Generator
(Note 2)
0A
(+)
50V DC
Approx
-0.25A
(-)
1.0
Ω
NI
Oscilloscope
(Note 1)
(+)
Notes:
1. Rise Time = 7.0ns max. Input Impedance = 1.0M
Ω
, 22pF.
2. Rise Time = 10ns max. Input Impedance = 50
Ω
.
-1.0A
Set time base for 5/10ns/cm
Fig. 5 Reverse Recovery Time Characteristic and Test Circuit
U16D05C – U16D60C
2 of 4
© 2006 Won-Top Electronics
MARKING INFORMATION
U16DxxC
U16DxxC
xx
Polarity
= Device Number
= 05, 10, 15, 20, 30, 40, 50 or 60
= As Marked on Body
PACKAGING INFORMATION
BULK
Tube Size
L x W x H (mm)
505 x 46 x 6.5
Quantity
(PCS)
30
Inner Box Size
L x W x H (mm)
520 x 145 x 95
Quantity
(PCS)
1,200
Carton Size
L x W x H (mm)
540 x 306 x 115
Quantity
(PCS)
2,400
Approx. Gross Weight
(KG)
18.0
Note:
1. Anti-static tube, water clear color.
RECOMMENDED SCREW MOUNTING ARRANGEMENT
Recommended isolated mounting when
screw is at heatsink potential. 6-32
hardware is used.
A conical washer should be used to
apply proper force to the device. Screw
should not be tightened with any type of
air-forced torque or equipment that may
cause high impact on device package.
The interface should apply a layer of
thermal grease or a highly conductive
thermal pad for better heat dissipation.
6-32 HEX Head Screw
Plain Washer
Rectifier
Insulator
Heatsink
Conical Washer
6-32 HEX Nut
U16D05C – U16D60C
3 of 4
© 2006 Won-Top Electronics
ORDERING INFORMATION
Product No.
U16D05C
U16D10C
U16D15C
U16D20C
U16D30C
U16D40C
U16D50C
U16D60C
1.
2.
Package Type
TO-3P
TO-3P
TO-3P
TO-3P
TO-3P
TO-3P
TO-3P
TO-3P
Shipping Quantity
30 Units/Tube
30 Units/Tube
30 Units/Tube
30 Units/Tube
30 Units/Tube
30 Units/Tube
30 Units/Tube
30 Units/Tube
Shipping quantity given is for minimum packing quantity only. For minimum
order quantity, please consult the Sales Department.
To order RoHS / Lead Free version (with Lead Free finish), add “-LF” suffix
to part number above. For example, U16D05C-LF.
