ALUMINUM ELECTROLYTIC CAPACITORS
ZS
4.5mmL Chip Type
series
Chip type with 4.5mm height.
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine using carrier tape.
Adapted to the RoHS directive (2002/95/EC).
WX
Smaller
ZT
High
Te m p e rature
ZS
Smaller
Bi-polarized
ZP
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
ZR
Performance Characteristics
– 40 ~ + 85°C
4 ~ 50V
0.1 ~ 220µF
+ 20% at 120Hz, 20°C
–
After 2 minutes' application of rated voltage, leakage current is not more than 0.01 CV or 3 (µA) ,whichever is greater.
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
4
0.50
6.3
0.30
10
0.24
16
0.19
25
0.16
35
0.14
50
0.14
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance ratio
ZT / Z20 (MAX.)
Z– 40°C / Z+20°C
4
7
15
6.3
4
8
10
3
8
16
2
4
25
2
4
35
2
3
50
2
3
Endurance
After 2000 hours' application of rated voltage
at 85°C,capacitors meet the characteristics
requirements listed at right.
Capacitance change
tan
δ
Leakage current
Within
+
20% of initial value
–
200% or less of initial specified value
Initial specified value or less
Shelf Life
Resistance to soldering
heat
Marking
After storing the capacitors under no load at 85°C for 1000 hours, and after performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they will meet the specified value for endurance characteristics listed above.
The capacitors shall be kept on the hot plate maintained at 250°C
Capacitance change
Within
+
10% of initial value
–
for 30 seconds. After removing from the hot plate and restored
tan
δ
Initial specified value or less
at room temperature,they meet the characteristic requirements
Initial specified value or less
Leakage current
listed at right.
Black print on the case top.
Chip Type
Positive
0.5 MAX.
Capacitance
Lot No.
Voltage
Plastic platform
0.3 MAX.
C + 0.2
–
Type numbering system (Example : 16V 10
µ
F)
1
2
3
4
5
6
7
8
9 10 11 12 13 14
U Z S 1 C 1 0 0 MC L 1 GB
Taping code
A+ 0.2 A + 0.2
–
–
φD
A
B
C
E
4
1.8
4.3
4.3
1.0
5
2.1
5.3
5.3
1.3
(mm)
6.3
2.4
6.6
6.6
2.2
Configuration
Capacitance tolerance (+ 20%)
–
Rated Capacitance (10µF)
Rated voltage (16V)
Series name
Type
X2
10
16V
φD
+ 0.5
–
B+ 0.2
–
4.5
Voltage mark for 6.3V is
6V .
+0.1
–0.2
0.5 ~ 0.8
Dimensions
V
Cap. (µF)
Code
4
0G
6.3
0J
E
Negative
10
1A
16
1C
25
1E
35
1V
4
4
4
4
4
4
4
5
6.3
50
1H
1.0
2.0
2.8
4.0
8.4
13
17
20
33
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
0R1
R22
R33
R47
010
2R2
3R3
4R7
100
220
330
470
101
221
4
4
5
6.3
28
33
56
96
4
5
5
6.3
28
37
45
70
5
5
6.3
33
41
52
4
5
6.3
6.3
23
37
49
58
4
5
6.3
6.3
16
27
42
52
4
5
6.3
18
29
46
Case size
φ
D (mm)
Rated
ripple
Rated Ripple (mArms) at 85°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz~
1.50
Taping specifications are given in page 24.
Recommended land size, soldering by reflow are given in page 25, 26.
Please select UR(p.70), UG(p.75) series if high C/V products are reqired.
Please refer to page 3 for the minimum order quantity.
CAT.8100V
