DP SERIES, 40-60AMP
REV. DATE
05/18/11
support@crydom.com
support-europe@crydom.com
For Technical Support:
C
L
1.38
35.1
1.15
29.1
4.09
104
.79
20.1
R.10
2.5
MOUNTING SLOTS
(4PL)
2.20
55.9
.95
24.1
PIN TERMINAL
4 POS
C
L
2.89
73.5
1.87
47.6
C
L
.44
11.2
C
L
3.62
91.9
SCREW TERMINAL
1/4-20
Tolerances: ± 0.02 in / 0.5 mm. All dimensions are in: inches [millimeters]
