1N4682 TR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> 1N4682 TR

1N4682 TR: DescriptionDIODE ZENER 2.7V 500MW DO35; Categorysemiconductor Discrete semiconductor; File Size738KB，6 Pages; ManufacturerCentral Semiconductor; Environmental Compliance

Download Datasheet Parametric View All

1N4682 TR Overview

DIODE ZENER 2.7V 500MW DO35

1N4682 TR Parametric

Parameter Name	Attribute value
Voltage - Zener (nominal) (Vz)	2.7V
Tolerance	±5%
Power - Max	500mW
Current at different Vr - Reverse leakage current	1µA @ 1V
Voltage at different If - Forward (Vf	1.5V @ 100mA
Operating temperature	-65°C ~ 200°C（TJ）
Installation type	Through hole
Package/casing	DO-204AH, DO-35, axial
Supplier device packaging	DO-35

Preview

Download Datasheet

View All

1N4678 THRU 1N4717

SILICON ZENER DIODE

LOW LEVEL

500mW, 1.8 THRU 43 VOLT

5% TOLERANCE

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR 1N4678 series

devices are silicon Zener diodes designed for

applications requiring an extremely low operating

current (50μA), and low leakage.

MARKING: Devices shall either be marked with the

preﬁx ‘C’ followed by the full part number or by the

marking code in the Electrical Characteristics Table.

DO-35 CASE

MAXIMUM RATINGS:

(TL=75°C)

Power Dissipation

Operating and Storage Junction Temperature

SYMBOL

TJ, Tstg

500

-65 to +200

UNITS

°C

ELECTRICAL CHARACTERISTICS:

(TA=25°C) VF=1.5V MAX @ IF=100mA (for all types)

Zener

Voltage

VZ @ IZT

MIN

1N4678

1N4679

1N4680

1N4681

1N4682

1N4683

1N4684

1N4685

1N4686

1N4687

1N4688

1N4689

1N4690

1N4691

1N4692

1N4693

1N4694

1N4695

1N4696

1N4697

1.710

1.900

2.090

2.280

2.565

2.850

3.135

3.420

3.705

4.085

4.465

4.845

5.320

5.890

6.460

7.125

7.790

8.265

8.645

9.500

NOM

1.8

2.0

2.2

2.4

2.7

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

8.7

9.1

MAX

1.890

2.100

2.310

2.520

2.835

3.150

3.465

3.780

4.095

4.515

4.935

5.355

5.880

6.510

7.140

7.875

8.610

9.135

9.555

10.50

Test

Current

IZT

μA

Maximum

Reverse Leakage

Current

μA

7.5

5.0

4.0

2.0

1.0

0.8

7.5

5.0

4.0

1.0

@ VR

1.0

1.5

2.0

3.0

4.0

5.0

5.1

5.7

6.2

6.6

6.9

7.6

Maximum

Voltage

Change*

ΔVZ

0.70

0.75

0.80

0.85

0.90

0.95

0.97

0.99

0.97

0.96

0.95

0.90

0.75

0.50

0.10

0.08

0.10

Maximum

Regulator

Current

IZM

120.0

110.0

100.0

95.0

90.0

85.0

80.0

75.0

70.0

65.0

60.0

55.0

50.0

45.0

35.0

31.8

29.0

27.6

26.2

24.8

C4678

C4679

C4680

C4681

C4682

C4683

C4684

C4685

C4686

C4687

C4688

C4689

C4690

C4691

C4692

C4693

C4694

C4695

C4696

C4697

Type

Marking

Code

* ΔVZ=VZ @ 100μA Minus VZ @ 10μA
